SIPLACE GEM for S25, HS50 SW Version GEM 502.01
HOST Interface Manual
©Siemens AG, all rights reserved page 199 of 236
CEID Name Description
311025 FM_S_TIMEOUT 38 S axis: does not reach required
position*
311026 FM_Z_SP_TIMEOUT 61 SP/Z axis: does not reach required
position*
311027 FM_D_TIMEOUT 8 SP/D axis: does not reach required
position*
311033 FM_Z_SP_TIMEOUT_PROXIMI
TY SWITCH
20 SP/Z axis: top Proximity switch
does not respond*
311040 FM_Z_SP_PROXIMITY
SWITCH_NICHT_FREI
SP/Z axis: top Proximity switch is not
released*
311044 FM_X_POS_PROXIMITY
SWITCH
X axis: Proximity switch for position
monitoring is off*
311045 FM_Y_POS_PROXIMITY
SWITCH
Y axis: Proximity switch for position
monitoring is off*
311046 FM_S_POS_PROXIMITY
SWITCH
S axis: Proximity switch for position
monitoring is off*
311047 FM_Z_SP_POS_PROXIMITY
SWITCH
SP/Z axis: Proximity switch for
position monitoring is off*
311048 FM_D_POS_PROXIMITY
SWITCH
SP/D axis: Proximity switch for
position monitoring is off*
311051 FM_X_ERROR_BIT X axis: Error bit set*
311052 FM_Y_ERROR_BIT Y axis: Error bit set*
311053 FM_S_ERROR_BIT S axis: Error bit set*
311054 FM_Z_SP_ERROR_BIT SP/Z axis: Error bit set*
311055 FM_D_ERROR_BIT SP/D axis: Error bit set*
311058 FM_X_WARTE_DAIN X axis: No DAIN acknowledgment*
311059 FM_Y_WARTE_DAIN Y axis: No DAIN acknowledgment*
311060 FM_S_WARTE_DAIN S axis: No DAIN acknowledgment*
311061 FM_Z_SP_WARTE_DAIN SP/Z axis: No DAIN acknowledgment*
311062 FM_D_WARTE_DAIN SP/D axis : No DAIN
acknowlegdment*
311086 FM_X_AK_UNG X axis: command currently invalid*
311087 FM_Y_AK_UNG Y axis: command currently invalid*
311088 FM_S_AK_UNG S axis: command currently invalid*
311089 FM_Z_SP_AK_UNG SP/Z axis: command currently invalid*
311090 FM_D_AK_UNG SP/D axis: command currently invalid*
311093 FM_X_AK_UNDEF X axis: command not defined*
311094 FM_Y_AK_UNDEF Y axis: command not defined*
311095 FM_S_AK_UNDEF S axis: command not defined*
311096 FM_Z_SP_AK_UNDEF SP/Z axis: command not defined*
311097 FM_D_AK_UNDEF SP/D axis: command not defined*
SIPLACE GEM for S25, HS50 SW Version GEM 502.01
HOST Interface Manual
Page 200 of 236 ©Siemens AG, all rights reserved
CEID Name Description
311100 FM_X_POSART_UNDEF X axis: positioning type not defined*
311101 FM_Y_POSART_UNDEF Y axis: positioning type not defined*
311102 FM_S_POSART_UNDEF S axis: positioning type not defined*
311103 FM_Z_SP_POSART_UNDEF SP/Z axis: positioning type not
defined*
311104 FM_D_POSART_UNDEF SP/D axis: positioning type not
defined*
311107 FM_X_VERFAHRBEREICH X axis: destination position outside
travel range*
311108 FM_Y_VERFAHRBEREICH Y axis: destination position outside
travel range*
311109 FM_S_VERFAHRBEREICH S axis: destination position outside
travel range*
311110 FM_Z_SP_VERFAHRBEREICH SP/Z axis: destination position outside
travel range*
311111 FM_D_VERFAHRBEREICH SP/D axis: destination position outside
travel range*
311114 FM_X_REFMODE_UNDEF X axis: reference point type not
defined*
311115 FM_Y_REFMODE_UNDEF X axis: reference point type not
defined*
311116 FM_S_REFMODE_UNDEF S axis: reference point type not
defined*
311117 FM_Z_SP_REFMODE_UNDEF SP/Z axis: reference point type not
defined*
311118 FM_D_REFMODE_UNDEF SP/D axis: reference point type not
defined*
311121 FM_X_ZAEHLFEHLER X axis: counting error*
311122 FM_Y_ZAEHLFEHLER Y axis: counting error*
311123 FM_S_ZAEHLFEHLER S axis: counting error*
311124 FM_Z_SP_ZAEHLFEHLER SP/Z axis: counting error*
311125 FM_D_ZAEHLFEHLER SP/D axis: counting error*
311128 FM_X_REF_NICHT_GEF X axis: correct zero pulse not found*
311129 FM_Y_REF_NICHT_GEF Y axis: correct zero pulse not found*
311130 FM_S_REF_NICHT_GEF S axis: correct zero pulse not found*
311131 FM_Z_SP_REF_NICHT_GEF SP/Z axis: correct zero pulse not
found*
311132 FM_D_REF_NICHT_GEF SP/D axis: correct zero pulse not
found*
311135 FM_X_SERVO_FREI 63 X axis: disabled*
311136 FM_Y_SERVO_FREI 64 Y axis: disabled*
311137 FM_S_SERVO_FREI 67 S axis: disabled*
SIPLACE GEM for S25, HS50 SW Version GEM 502.01
HOST Interface Manual
©Siemens AG, all rights reserved page 201 of 236
CEID Name Description
311138 FM_Z_SP_SERVO_FREI 68 SP/Z axis: disabled*
311139 FM_D_SERVO_FREI 66 SP/D axis: disabled*
311141 FM_X_DECODE X axis: error during command
decoding*
311142 FM_Y_DECODE Y axis: error during command
decoding*
311143 FM_S_DECODE S axis: error during command
decoding*
311144 FM_Z_SP_DECODE SP/Z axis: error during command
decoding*
311145 FM_D_DECODE SP/D axis: error during command
decoding*
311148 FM_X_KLEMMT_REF X axis jamming*
311149 FM_Y_KLEMMT_REF Y axis jamming*
311150 FM_S_KLEMMT_REF S axis jamming*
311151 FM_Z_SP_KLEMMT_REF SP/Z axis jamming*
311152 FM_D_KLEMMT_REF SP/D axis jamming*
311154 FM_X_ENDSCHALTER X axis: limit switch actuated*
311155 FM_Y_ENDSCHALTER Y axis: limit switch actuated*
311156 FM_S_ENDSCHALTER S axis: limit switch actuated*
311157 FM_Z_SP_ENDSCHALTER SP/Z axis: limit switch actuated*
311158 FM_D_ENDSCHALTER SP/D axis: limit switch actuated*
311161 FM_X_SERVO_STOERUNG X axis: servo card reports fault*
311162 FM_Y_SERVO_STOERUNG Y axis: servo card reports fault*
311163 FM_S_SERVO_STOERUNG S axis: servo card reports fault*
311164 FM_Z_SP_SERVO_STOERUNG SP/Z axis: servo card reports fault*
311165 FM_D_SERVO_STOERUNG SP/D axis: servo card reports fault*
311168 FM_X_SERVO_STROMBEGR X axis: I rms current limiting*
311169 FM_Y_SERVO_STROMBEGR Y axis: I rms current limiting*
311170 FM_S_SERVO_STROMBEGR S axis: I rms current limiting*
311171 FM_Z_SP_SERVO_STROMBEG
R
SP/Z axis: I rms current limiting*
311172 FM_D_SERVO_STROMBEGR SP/D axis: I rms current limiting*
311175 FM_X_SELBSTTEST X axis: Self-test unsuccessful*
311176 FM_Y_SELBSTTEST Y axis: Self-test unsuccessful*
311177 FM_S_SELBSTTEST S axis: Self-test unsuccessful*
311178 FM_Z_SP_SELBSTTEST SP/Z axis: Self-test unsuccessful*
311179 FM_D_SELBSTTEST SP/D axis: Self-test unsuccessful*
311182 FM_X_DA_TEST X axis: testing DA outputs faulty*
