SIPLACE GEM for S25, HS50 SW Version GEM 502.01 HOST Inter face Manual ©Siemens AG, all rights reserved page 203 of 236 CEID Name De script ion interrogation* 311222 FM_AX_ANFR AGE_FUNC Axis error : Com m unication durin…
SIPLACE GEM for S25, HS50 SW Version GEM 502.01
HOST Interface Manual
Page 202 of 236 ©Siemens AG, all rights reserved
CEID Name Description
311183 FM_Y_DA_TEST Y axis: testing DA outputs faulty*
311184 FM_S_DA_TEST S axis: testing DA outputs faulty*
311185 FM_Z_SP_DA_TEST SP/Z axis: testing DA outputs faulty*
311186 FM_D_DA_TEST SP/D axis: testing DA outputs faulty*
311189 FM_X_ZAEHLSPUREN_TEST X axis: testing counting tracks faulty*
311190 FM_Y_ZAEHLSPUREN_TEST Y axis: testing counting tracks faulty*
311191 FM_S_ZAEHLSPUREN_TEST S axis: testing counting tracks faulty*
311192 FM_Z_SP_ZAEHLSPUREN_TES
T
SP/Z axis: testing counting tracks
faulty*
311193 FM_D_ZAEHLSPUREN_TEST SP/D axis: testing counting tracks
faulty*
311196 FM_X_DA_ABGLEICH_TEST X axis: DA calibration faulty*
311197 FM_Y_DA_ABGLEICH_TEST Y axis: DA calibration faulty*
311198 FM_S_DA_ABGLEICH_TEST S axis: DA calibration faulty*
311199 FM_Z_SP_DA_ABGLEICH_TES
T
SP/Z axis: DA calibration faulty*
311200 FM_D_DA_ABGLEICH_TEST SP/D axis: DA calibration faulty*
311203 FM_X_UNDEFINIERT X axis: error number undefined*
311204 FM_Y_UNDEFINIERT Y axis: error number undefined*
311205 FM_S_UNDEFINIERT S axis: error number undefined*
311206 FM_Z_SP_UNDEFINIERT SP/Z axis: error number undefined*
311207 FM_D_UNDEFINIERT SP/D axis: error number undefined*
311210 FM_AX_STD_DATEN Axis error: standard data not read*
311211 FM_AX_MA_DATEN Axis error: MA data not OK*
311212 FM_AX_STD_FILE Axis error: Standard data file not
found*
311213 FM_AX_MA_FILE Axis error: standard data file not
found*
311214 FM_AX_KMD_ENDE Axis error: no end flag before new
command*
311215 FM_AX_KMD_DAIN Axis error: no DAIN flag before new
command*
311216 FM_AX_KMD_ENDE_SET Axis error: Command end, but bit set*
311217 FM_AX_KMD_DAIN_SET Axis error: Command DAIN, but bit
set*
311218 FM_AX_ANFRAGE_ID Axis error: no ID for MBX inquiry*
311219 FM_AX_ANFRAGE_VERSION Axis error: communication during
version interrogation*
311220 FM_AX_VERSION_AXH Axis error: Wrong AX_Version user or
wrong configuration*
311221 FM_AX_ANFRAGE_ADR Axis error: Communication during axis
SIPLACE GEM for S25, HS50 SW Version GEM 502.01
HOST Interface Manual
©Siemens AG, all rights reserved page 203 of 236
CEID Name Description
interrogation*
311222 FM_AX_ANFRAGE_FUNC Axis error: Communication during
function address interrogation*
311227 FM_X_INIT_SCHRITTM X axis: Step motor initialisation
incorrect*
311228 FM_Y_INIT_SCHRITTM Y axis: Step motor initialisation
incorrect*
311229 FM_S_INIT_SCHRITTM S axis: Step motor initialisation
incorrect*
311230 FM_Z_SP_INIT_SCHRITTM RV/Z axis: Step motor initialisation
incorrect*
311231 FM_D_INIT_SCHRITTM RV/D axis: Step motor initialisation
incorrect*
311234 FM_X_TACHOBRUCH X axis: Tachometer defective*
311235 FM_Y_TACHOBRUCH Y axis: Tachometer defective*
311236 FM_S_TACHOBRUCH S axis: Tachometer defective*
311237 FM_Z_SP_TACHOBRUCH RV/Z axis: Tachometer defective*
311238 FM_D_TACHOBRUCH RV/D axis: Tachometer defective*
311241 FM_X_SERVO_FREI_VC X axis: Faulty servo activation
(counting track error) *
311242 FM_Y_SERVO_FREI_VC Y axis: Faulty servo activation
(counting track error) *
311243 FM_S_SERVO_FREI_VC S axis: Faulty servo activation
(counting track error) *
311244 FM_Z_SP_SERVO_FREI_VC RV/Z axis: Faulty servo activation
(counting track error) *
311245 FM_D_SERVO_FREI_VC RV/D axis: Faulty servo activation
(counting track error) *
311248 FM_X_NOREF_I_EFF X-axis: Not referenced *
311249 FM_Y_NOREF_I_EFF Y-axis: Not referenced *
311250 FM_S_NOREF_I_EFF S--axis: Not referenced *
311251 FM_Z_SP_NOREF_I_EFF RV/Z--axis: Not referenced *
311252 FM_D_NOREF_I_EFF RV/D-axis: Not referenced *
311255 FM_X_ZAEHLF_KOMMUTF X-axis: counting error (machine stop
or commutation)*
311256 FM_Y_ZAEHLF_KOMMUTF Y-axis: counting error (machine stop)*
311257 FM_S_ZAEHLF_KOMMUTF S-axis: counting error (machine stop
or commutation)*
311258 FM_Z_SP_ZAEHLF_KOMMUTF RV/Z-axis: counting error (machine
stop or commutation) *
311259 FM_D_ZAEHLF_KOMMUTF RV/D-axis: counting error (machine
stop or commutation) *
SIPLACE GEM for S25, HS50 SW Version GEM 502.01
HOST Interface Manual
Page 204 of 236 ©Siemens AG, all rights reserved
CEID Name Description
311260 FM_Z_IC_ZAEHLF_KOMMUTF IC/Z-axis: counting error (machine
stop or commutation) *
311262 FM_ABH_BO_AUS Bero for Z-axis top position not
released
311263 FM_CAN_MSG_Z_ACHSE_OB_
SP
RV/Z axis: light barrier z-top not
covered
311264 FM_CAN_MSG_START_STERN S axis: must not be rotated
311265 FM_CAN_MSG_START_XY Due to Z axis, portal must not be
moved
311266 FM_CAN_MSG_EINSCHWENK
EN
RV/D axis: Cannot be swung in
311267 FM_CAN_MSG_AUSSCHWENK
EN
RV/D axis: Cannot be swung out
311268 FM_CAN_MSG_ABHOLEN_SP RV: bottom Z light barrier did not
respond at pick-up
311269 FM_CAN_MSG_BESTUECKEN_
SP
RV: bottom Z light barrier did not
respond during placement
311272 FM_GUI_TEXT_MA_ERR_X_AC
HSE_SERVO_FREI
x-axis servo disabled
311273 FM_GUI_TEXT_MA_ERR_Y_AC
HSE_SERVO_FREI
y-axis servo disabled
311276 FM_GUI_TEXT_MA_ERR_WAR
TE_ACHSEN_IN_POS
Axes fail to respond to command
(WARTE_ACHSE_IN_POS)
311277 FM_GUI_TEXT_MA_ERR_ACH
SEN_IN_POS_TIMEOUT
Axes fail to reach position at creep
speed
311278 FM_GUI_TEXT_MA_ERR_ACH
SEN_IN_POSITION
Axes fail to respond to command
(ACHSE_IN_POS)
311279 FM_GUI_TEXT_MA_ERR_SCH
ALTE_SERVOS
Axes fail to respond to command
(SCHALTE_SERVO)
311280 FM_GUI_TEXT_MA_ERR_PRO
G_ACHSEN
Axes fail to respond to command
(PROG_ACHSEN)
311281 FM_GUI_TEXT_MA_ERR_BREA
K_AN_ACHSEN
Axes fail to respond to command
(BREAK)
311282 FM_GUI_TEXT_MA_ERR_STAR
TTASTE_ACHSEN
Axes fail to respond to command
(STARTTASTE_ACHSE_OBEN)
311283 FM_GUI_TEXT_MA_ERR_STER
N_ACHSE_SERV
Star axis servo disabled
311284 FM_GUI_TEXT_MA_ERR_D_AC
HSE_SERVO_FREI
d-axis servo disabled
311285 FM_GUI_TEXT_MA_ERR_Z_AC
HSE_SERVO_FREI
z-axis servo disabled
311286 FM_GUI_TEXT_MA_ERR_KOPF
_ACHSFEHLER
Unable to execute axis function
311287 FM_GUI_TEXT_PORTAL_ERR_
ACHSFEHLER
Unable to execute axis function
