SIPLACE GEM for S25, HS50 SW Version GEM 502.01
HOST Interface Manual
©Siemens AG, all rights reserved page 205 of 236
CEID Name Description
311288 FM_GUI_TEXT_PORTAL_ERR_
ACHSSTATUS
Unable to determine state of a gantry
axis
311289 FM_GUI_TEXT_PORTAL_ERR_
SET_PORTAL_PARA
Unable to set axis parameters
311290 FM_GUI_TEXT_PORTAL_ERR_
ACHSKOMMANDO
Axis command failed
311291 FM_GUI_TEXT_PORTAL_ERR_
ACHS_NICHT_REF
Gantry axis/axes not referenced
311292 FM_GUI_TEXT_PORTAL_ERR_
ACHS_WARTEPOS
Gantry axis/axes fail to reach setpoint
position
311293 FM_GUI_TEXT_F_HW_SICHER
UNG
Motor control voltage failure, 30V fuse
defective
311294 FM_AX_TEMP_NOK Motor temerature too high
311295 FM_AX_CRASH_WARNING Crash warning activated
311296 FM_AX_ADJUSTMENT_NOK Axis adjustment not OK
* Depending on the collection event, some of the status variables <ERRORTYPE>,
<GANTRYONERROR>, <SEGMENTONERROR>, <TRACKONERROR>,
<ERRORINFO1> and <ERRORINFO2> will be updated at each of these axis
collection events.
)LGXFLDOV
CEID Name Description
410002 PCBfiducal PCB <FIDUCIALDATA> recognized
Variables HEADID (VID 1022030),
GANTRYID (2012028) and
GANTRYDROUPID (2012029)
are valid.
13
410003 FeederFiducial Feeder / MTC - <FIDUCIALDATA>
recognized
Variables HEADID (VID 1022030),
GANTRYID (2012028) and
GANTRYDROUPID (2012029)
are valid.
13
411001 FM_LAGE_DETERMINANTE 94 DETERMINANT not correct during
position recognition*
411002 FM_LAGE_MARKE_FEHLT 95 Fiducial missing in position
recognition*
411005 FM_FLE_N_MOEGL Limited conveyor position recognition*
411006 FM_FLE_N_MOEGL_SPUR Conveyor position recognition not
possible*
411009 FM_PORTALUNRUHE_X X-axis moving during measurement*
411010 FM_PRTALUNRUHE_Y Y-axis moving during measurement*
SIPLACE GEM for S25, HS50 SW Version GEM 502.01
HOST Interface Manual
Page 206 of 236 ©Siemens AG, all rights reserved
CEID Name Description
411011 FM_INKHISTO_KEINE_DATEI Parameter file for inkspot not available
411012
FM_INKHISTO_DATEI_DEFEKT
Incorrect parameters in inkspot file
411013 FM_INKHISTO_KONTRAST_Z
U_KLEIN
Inkspot contrast too low
411014 FM_INKHISTO_HELLIG_IM_GR
ENZB
Inkspot brightness at the limits
* Depending on the collection event, some of the status variables <ERRORTYPE>,
<GANTRYONERROR>, <SEGMENTONERROR>, <TRACKONERROR>,
<ERRORINFO1> and <ERRORINFO2> will be updated at each of these fiducials
collection events.
9LVLRQ
CEID Name Description
511002 FM_ANZ_FOV Component too large for opt. multiple
measurement*
511003 FM_MVS_EPROM_VERSION Incorrect Eprom version in MVS*
511030 FM_OPT_OHNE_RESULT Vision system not providing meas.
results*
511031 FM_OPT_TEILUNGS_KONTR Spacing of a pin group outside
tolerance*
511032 FM_OPT_LEAD_TIP_NK Lead tip: component outside
tolerance*
511033 FM_OPT_LEAD_TIP_NV Lead tip: evaluation not possible*
511034 FM_OPT_LEAD_TIP_NR Lead tip: no result*
511035 FM_OPT_LAGE_X_TOL_DEF Component outside feed tolerance*
511036 FM_OPT_LAGE_X_TOL_S Component outside feed tolerance
(size) *
511037 FM_OPT_LAGE_X_TOL_R Component outside feed tolerance
(row) *
511038 FM_OPT_LAGE_X_TOL_C Component outside feed tolerance
(corner) *
511039 FM_OPT_LAGE_X_TOL_L Component outside feed tolerance
(lead) *
511040 FM_OPT_LAGE_X_TOL_G Component outside feed tolerance
(grid) *
511041 FM_OPT_LAGE_X_TOL_B Component outside feed tolerance
(ball) *
511042 FM_OPT_LAGE_Y_TOL_DEF Component outside feed tolerance*
511043 FM_OPT_LAGE_Y_TOL_S Component outside feed tolerance
(size) *
511044 FM_OPT_LAGE_Y_TOL_R Component outside feed tolerance
(row) *
SIPLACE GEM for S25, HS50 SW Version GEM 502.01
HOST Interface Manual
©Siemens AG, all rights reserved page 207 of 236
CEID Name Description
511045 FM_OPT_LAGE_Y_TOL_C Component outside feed tolerance
(corner) *
511046 FM_OPT_LAGE_Y_TOL_L Component outside feed tolerance
(lead) *
511047 FM_OPT_LAGE_Y_TOL_B Component outside feed tolerance
(ball) *
511048 FM_OPT_LAGE_Y_TOL_G Component outside feed tolerance
(grid) *
511049 FM_OPT_QUAL_FAKTOR_DEF Quality too low during optical
centering*
511050 FM_OPT_QUAL_FAKTOR_S Quality too low during opt. centering
(s) *
511051 FM_OPT_QUAL_FAKTOR_R Quality too low during opt. centering
(r) *
511052 FM_OPT_QUAL_FAKTOR_C Quality too low during opt. centering
(c) *
511053 FM_OPT_QUAL_FAKTOR_L Quality too low during opt. centering (l)
*
511054 FM_OPT_QUAL_FAKTOR_G Quality too low during opt. centering
(g) *
511055 FM_OPT_QUAL_FAKTOR_B Quality too low during opt. centering
(b) *
511056 FM_OPT_DIM_L_TOL_DEF Component length outside tolerance*
511057 FM_OPT_DIM_L_TOL_S Component length outside tolerance
(s) *
511058 FM_OPT_DIM_L_TOL_R Component length outside tolerance
(r) *
511059 FM_OPT_DIM_L_TOL_C Component length outside tolerance
(c) *
511060 FM_OPT_DIM_L_TOL_L Component length outside tolerance
(l) *
511061 FM_OPT_DIM_L_TOL_G Component length outside tolerance
(g) *
511062 FM_OPT_DIM_L_TOL_B Component length outside tolerance
(b) *
511063 FM_OPT_DIM_B_TOL_DEF Component width outside tolerance*
511064 FM_OPT_DIM_B_TOL_S Component width outside tolerance
(s) *
511065 FM_OPT_DIM_B_TOL_R Component width outside tolerance
(r) *
511066 FM_OPT_DIM_B_TOL_C Component width outside tolerance
(c) *
511067 FM_OPT_DIM_B_TOL_L Component width outside tolerance
(l) *
511068 FM_OPT_DIM_B_TOL_G Component width outside tolerance
