SIPLACE GEM for S25, HS50 SW Version GEM 502.01
HOST Interface Manual
©Siemens AG, all rights reserved page 217 of 236
&(,' 1DPH 'HVFULSWLRQ
event is never reported
directly to the host, but
instead it is directed to the
end of the spool file
Process State Model
1000010 Init2Process The Siplace change its
processing state from
„Machine Initialization“ to
„Processing“
1
1000011 Process2Init The Siplace change its
processing state from
„Processing“ to „Machine
Initialization“
1
1000012 Process2SingleFunction The Siplace change its
processing state from
„Processing“ to „Single
Function“
1
1000013 SingleFunction2Process The Siplace change its
processing state from
„Single Function“ to
„Processing“
1
1000014 Init2SingleFunction The Siplace change its
processing state from
„Machine Initialization“ to
„Single Function“
1
1000015 SingleFunction2Init The Siplace change its
processing state from
„Single Function“ to
„Machine Initialization“
1
1000020 Proc1PPChangeEvent Board with a new
processing program enters
Processing 1 Area
1
1000021 Proc2PPChangeEvent Board with a new
processing program enters
Processing 2 Area
1
Process Program Management
1000017 GemBadDownloadEvent Error in downloaded
program
1
1001018 FM_GEM_INIT GEM: Error upon
initialization of GEM
interface to host*
1001019 FM_GEM_INIT_MC GEM: Error upon
initialization of interface to
MC*
1001020 FM_GEM_INIT_GUI GEM: Error upon
initialization of interface to
user interface*
1001021 FM_GEM_SIPLACE GEM: Error in SIPLACE
GEM software*
SIPLACE GEM for S25, HS50 SW Version GEM 502.01
HOST Interface Manual
Page 218 of 236 ©Siemens AG, all rights reserved
&(,' 1DPH 'HVFULSWLRQ
1001022 FM_GEM_OP_MELDUNG GEM: Most recent operator
message could not be sent
to the host*
1001023 FM_GEM_VERB_GUI GEM: Faulty connection
between GEM interface and
user interface*
1001024 FM_GENERAL General Error Event
Error messages can be
reported either with specific
error events (an Error Event
with a CEID for each
individual error) or with the
General Error Event that
reports all errors.
The General Error Event
has an error code
<LASTERRORCODE>,
which contains the CEID of
the specific Error Event.
The SV <LASTFMTEXT>
which contains the error
text of the specific Error
Event is also available.
44
* Depending on the collection event, some of the status variables <ERRORTYPE>,
<GANTRYONERROR>, <SEGMENTONERROR>, <TRACKONERROR>,
<ERRORINFO1> and <ERRORINFO2> will be updated at each of these GEM-
kernel collection events.
2SHUDWRU
&(,' 1DPH 'HVFULSWLRQ
1120001 EmergencyStop Emergency stop pressed or Cover
opened
1
1120002 StopButton Stop button pressed 1
1120003 StartButton Start button pressed 1
1120007 GUIStart Message from GUI: Start. 1
1120008 GUISTOP Message from GUI: Stop. 1
1120009 GUIContinue Message from GUI: Continue. 1
1120010 GUIAbort Message from GUI: Abort. 1
1120096 ToGUINewSetUp Message to GUI: NewSetUp 1
1120097 ToGUIPPname Message to GUI: Placement
Program Name
1
1120098 ToGUIActionText Message to GUI: Send
<GUIACTIONTEXT>
1
1120100 ToGUIStateText Message to GUI: Send
<GUISTATETEXT>
1
SIPLACE GEM for S25, HS50 SW Version GEM 502.01
HOST Interface Manual
©Siemens AG, all rights reserved page 219 of 236
&(,' 1DPH 'HVFULSWLRQ
1120103 ToGUIMachineReady Message to GUI: Machine ready to
process
1
1120104 ToGUIStopButton Message to GUI: Stop button
pressed
1
1120105 ToGUIEmergencyButton Message to GUI: Emergency button
pressed
1
1120117 ToGUIBarcodeError Message to GUI: PCB-Barcode error 1
1120216 ToGUICtrlModeChanged Control Mode change (Stand-alone,
GEM-Host or LCU) is completed.
1
1120258 ToGUIRefRunReady Machine is ready to start reference
run
1
1120259 ToGUInewjobname display new jobname 1
1120300 MessageFromGuiGeneral General Event for all Messages from
GUI
Messages from GUI can be reported
either with specific events (one
event with one CEID for each
individual message) or with the
Event MessageFromGuiGeneral.
The variable 1122007
<GUIMESSAGENUMBER >
contains the CEID of the specific
GUI message.
45
1120301 MessageToGuiGeneral General Event for all Messages to
GUI
Messages to GUI can be reported
either with specific events (one
event with one CEID for each
individual message) or with the
Event MessageToGuiGeneral.
The variable 1122007 <
GUIMESSAGENUMBER> contains
the CEID of the specific Message To
Gui.
45
&$1%XV
CEID Name Description
1211001 FM_CAN_INI_APL CAN bus: Initialization faulty*
1211002 FM_CAN_SND_OVL CAN bus: transmission source
overflow*
1211003 FM_CAN_NO_CAR CAN bus: reception job before
transmission job*
1211004 FM_CAN_RCV_TOUT CAN bus: reception call aborted
with timeout*
