SIPLACE GEM for S25, HS50 SW Version GEM 502.01
HOST Interface Manual
©Siemens AG, all rights reserved page 41 of 236
Variable Name VID
CONFIGALARMS 1002018
WBITS5 1002019
ALARMID 1002013
ALARMSERIAL 1002015
ALARMSENABLED 1002020
ALARMSSET 1002021
ALARMSTATE 1002014
 5HODWHG&ROOHFWLRQ(YHQWV
Each alarm defined on the SIPLACE has two unique collection events associated with it, a
"Going-On" event, and a "Going-Off" event. The CEIDs are listed in "Appendix B --
Collection Events".
SIPLACE GEM for S25, HS50 SW Version GEM 502.01
HOST Interface Manual
Page 42 of 236 ©Siemens AG, all rights reserved
 0DWHULDO0RYHPHQW
The Events and Variables from the Material Movement depend on the structure of the
machine at hand. The following diagram shows the individual areas of the PCB conveyor:
&RQYH\RU+6
&RQYH\RU6
 5HODWHG9DULDEOHV
The following table lists the variables which are relevant to material movement. 'TWIN'
variables are required for the dual conveyor.
For a more complete description of these variables, see "Appendix A -- Variables".
Variable Name VID HS50 S25
INPUTCONVEYORSTATE 612011
✔ ✔
FIRSTPROCESSINGCONVEYORSTATE 612012
✔ ✔
INTERMEDIATECONVEYORSTATE 612013
✔
SECONDPROCESSINGCONVEYORSTATE 612014
✔
OUTPUTCONVEYORSTATE 612015
✔ ✔
TWININPUTCONVEYORSTATE 612021
✔ ✔
TWINFIRSTPROCESSINGCONVEYORSTATE 612022
✔ ✔
TWININTERMEDIATECONVEYORSTATE 612023
✔
TWINSECONDPROCESSINGCONVEYORSTATE 612024
✔
TWINOUTPUTCONVEYORSTATE 612025
✔ ✔
TRANSPORTWIDTH 612007
✔ ✔
TWINTRANSPORTWIDTH 612017
✔ ✔
 5HODWHG&ROOHFWLRQ(YHQWV
There are 5 CEID related to then Material Movement Capability. For a more complete
listing of these collection events, please see "Appendix B -- Collection Events".
Input
Conveyor
First
Processing
Conveyor
Intermediate
Conveyor
Output
Conveyor
Second
Processing
Conveyor
Input
Conveyor
First
Processing
Conveyor
Output
Conveyor
SIPLACE GEM for S25, HS50 SW Version GEM 502.01
HOST Interface Manual
©Siemens AG, all rights reserved page 43 of 236
The Events with a '2' at the end of the Event name (e.g., PCBreachedOutputConveyor2)
refer to the 2
nd
belt of a dual conveyor.
Collection Event CEID HS50 S25
PCBreachedInputConveyor 610031
✔ ✔
PCBreachedFirstProcessingConveyor 610061
✔ ✔
PCBreachedIntermediateConveyor 610062
✔
PCBreachedSecondProcessingConveyor 610063
✔
PCBreachedOutputConveyor 610033
✔ ✔
PCBreachedInputConveyor2 610034
✔ ✔
PCBreachedFirstProcessingConveyor2 610066
✔ ✔
PCBreachedIntermediateConveyor2 610067
✔
PCBreachedSecondProcessingConveyor2 610068
✔
PCBreachedOutputConveyor2 610036
✔ ✔
TransportWidthMeasured 610037
✔ ✔
TransportWidthMeasured2 610044
✔ ✔
TakeOutInConv 610051
✔ ✔
TakeOutProcessing1Conv 610069
✔ ✔
TakeOutIntermediateConv 610070
✔
TakeOutProcessing2Conv 610071
✔
TakeOutOutConv 610052
✔ ✔
TakeOutInConv2 610053
✔ ✔
TakeOutProcessing1Conv2 610072
✔ ✔
TakeOutIntermediateConv2 610073
✔
TakeOutProcessing2Conv2 610074
✔
TakeOutOutConv2 610054
✔ ✔
