SIPLACE GEM for S25, HS50 SW Version GEM 502.01
HOST Interface Manual
Page 42 of 236 ©Siemens AG, all rights reserved
0DWHULDO0RYHPHQW
The Events and Variables from the Material Movement depend on the structure of the
machine at hand. The following diagram shows the individual areas of the PCB conveyor:
&RQYH\RU+6
&RQYH\RU6
5HODWHG9DULDEOHV
The following table lists the variables which are relevant to material movement. 'TWIN'
variables are required for the dual conveyor.
For a more complete description of these variables, see "Appendix A -- Variables".
Variable Name VID HS50 S25
INPUTCONVEYORSTATE 612011
✔ ✔
FIRSTPROCESSINGCONVEYORSTATE 612012
✔ ✔
INTERMEDIATECONVEYORSTATE 612013
✔
SECONDPROCESSINGCONVEYORSTATE 612014
✔
OUTPUTCONVEYORSTATE 612015
✔ ✔
TWININPUTCONVEYORSTATE 612021
✔ ✔
TWINFIRSTPROCESSINGCONVEYORSTATE 612022
✔ ✔
TWININTERMEDIATECONVEYORSTATE 612023
✔
TWINSECONDPROCESSINGCONVEYORSTATE 612024
✔
TWINOUTPUTCONVEYORSTATE 612025
✔ ✔
TRANSPORTWIDTH 612007
✔ ✔
TWINTRANSPORTWIDTH 612017
✔ ✔
5HODWHG&ROOHFWLRQ(YHQWV
There are 5 CEID related to then Material Movement Capability. For a more complete
listing of these collection events, please see "Appendix B -- Collection Events".
Input
Conveyor
First
Processing
Conveyor
Intermediate
Conveyor
Output
Conveyor
Second
Processing
Conveyor
Input
Conveyor
First
Processing
Conveyor
Output
Conveyor
SIPLACE GEM for S25, HS50 SW Version GEM 502.01
HOST Interface Manual
©Siemens AG, all rights reserved page 43 of 236
The Events with a '2' at the end of the Event name (e.g., PCBreachedOutputConveyor2)
refer to the 2
nd
belt of a dual conveyor.
Collection Event CEID HS50 S25
PCBreachedInputConveyor 610031
✔ ✔
PCBreachedFirstProcessingConveyor 610061
✔ ✔
PCBreachedIntermediateConveyor 610062
✔
PCBreachedSecondProcessingConveyor 610063
✔
PCBreachedOutputConveyor 610033
✔ ✔
PCBreachedInputConveyor2 610034
✔ ✔
PCBreachedFirstProcessingConveyor2 610066
✔ ✔
PCBreachedIntermediateConveyor2 610067
✔
PCBreachedSecondProcessingConveyor2 610068
✔
PCBreachedOutputConveyor2 610036
✔ ✔
TransportWidthMeasured 610037
✔ ✔
TransportWidthMeasured2 610044
✔ ✔
TakeOutInConv 610051
✔ ✔
TakeOutProcessing1Conv 610069
✔ ✔
TakeOutIntermediateConv 610070
✔
TakeOutProcessing2Conv 610071
✔
TakeOutOutConv 610052
✔ ✔
TakeOutInConv2 610053
✔ ✔
TakeOutProcessing1Conv2 610072
✔ ✔
TakeOutIntermediateConv2 610073
✔
TakeOutProcessing2Conv2 610074
✔
TakeOutOutConv2 610054
✔ ✔
SIPLACE GEM for S25, HS50 SW Version GEM 502.01
HOST Interface Manual
Page 44 of 236 ©Siemens AG, all rights reserved
(TXLSPHQW7HUPLQDO6HUYLFHV
The SIPLACE supports exchange of free text messages with the Host (SECS Stream 10).
This Equipment accepts the following messages from the Host, and responds accordingly
if the W-Bit is set to 1:
S10F3 /* Single Line Data */
S10F5 /* Multi-Line Data */
S10F9 /* Broadcast */
The message text will be displayed on the Equipment's CRT. Collection Event S10Ack
(CEID 1000002) occurs once the operator has acknowledged the message and an Event
Report will be sent to the Host (if enabled).
The S10F3 and S10F9 are restricted to a single TEXT data item, but S10F5 can contain
multiple TEXT data items. Each TEXT data item is limited to 160 characters. Each data
item in S10F5 will be displayed on a separate line at the equipment.
If the Operator has not acknowledged an existing message when the Host sends another
message, the new message will be displayed and the old one discarded.
The Host can send a message with a 0-length text to clear the Operator text display.
Also, the Equipment allows the operator to send a single block message to the Host via
S10F1. The maximum length of this text is 160 characters. The S10F2 response from
the Host is ignored.
5HODWHG9DULDEOHV
There are no relevant variable for the Equipment Terminal Capability.
5HODWHG&ROOHFWLRQ(YHQWV
There is one CEID related to the Equipment Terminal Capability. For a more complete
listing of these collection events, please see "Appendix B -- Collection Events".
Collection Event CEID
HostMsgAckr 1000002
