SIPLACE GEM for S25, HS50 SW Version GEM 502.01
HOST Interface Manual
Page 94 of 236 ©Siemens AG, all rights reserved
 6)'HILQH9DULDEOH/LPLWV$WWULEXWHV
S2F45 W * H -> E
<L [2]
<U4 DATAID>
<L
<L [2]
<U4 VID> * Variable ID
<L
<L [2]
<B [1] LIMITID>
<L [2]
<UPPERDB>
<LOWERDB>
>
>
>
...
>
...
>
> .
With this message, the Host defines a set of limits for a single variable or a series of
variables.
DATAID may be any value, and is ignored by the Equipment.
VID must specify the Variable ID of a Variable for which Limits Monitoring is allowed.
LIMITID must be between 0x01 and 0x07. It specifies one of the seven allowable limits
for the variable.
UPPERDB and LOWERDB must match the value format of the specified variable
The Host may undefine all limits for all VIDs:
S2F45 W * H -> E
<L [2]
<U4 DATAID>
<L>
> .
SIPLACE GEM for S25, HS50 SW Version GEM 502.01
HOST Interface Manual
©Siemens AG, all rights reserved page 95 of 236
The Host may undefine all limits for a specific VID:
S2F45 W * H -> E
<L [2]
<U4 DATAID>
<L
<L [2]
<U4 VID>
<L>
>
...
>
> .
The Host may undefine a specific limit for a specific VID:
S2F45 W * H -> E
<L [2]
<U4 DATAID>
<L
<L [2]
<U4 VID>
<L
<L [2]
<B [1] LIMITID>
<L>
>
>
...
>
...
>
> .
 6)9DULDEOH/LPLW$WWULEXWH$FNQRZOHGJH
This message acknowledges the successful setting of limits as defined in the Host-
generated S2F45.
S4F46 * H <- E
<L [2]
<B [1] * VLAACK
<L>
> .
SIPLACE GEM for S25, HS50 SW Version GEM 502.01
HOST Interface Manual
Page 96 of 236 ©Siemens AG, all rights reserved
If any of the limits proposed in S4F45 are invalid, all limits for all variables in this message
are rejected. The following message is sent in the event of an error:
S4F46 * H <- E
<L [2]
<B [1] VLAACK>
<L
<L [3]
<U4 VID>
<B [1] 0x00> * LVACK
<L [2]
<B [1] LIMITID>
<B [1] LIMITACK>
>
>
...
>
> .
Data item VLAACK reports to the Host the status of the request to define limits for the
requested variables.
VLAACK Description
0x00 OK. Limits successfully defined.
0x01 Limit attribute definition error.
