1-15 1 Maintenance 2.3 Required tools Prepare the following tools and items necessary for maintenance. n T ool list : Supplied with machine, : Options Name Description Oil syringe for nozzle buffing Used to supply turbine…
1-14
1
Maintenance
2.2.3 Special tool
n
Special tool (Optional purchase part)
Special tool
Optional purchase part
Leaf spring installation tool Cleaning wire
0.7mm
Special hex wrench (0.7)
Hex 0.7mm
53108-L1-10
Product Name Parts List Designation Parts No. Note
Leaf spring installation tool TOOL, LEAF SPRING KGS-M8810-00X
For details about how to use the
tool, see "2. Replacing nozzle leaf
springs" in Chapter 4.
Cleaning wire NEEDLE, PIERCE
φ
0.7mm KM4-M3801-40X
Used to clean the nozzle block hole.
See "2.2 Cleaning FNC nozzles" in
Chapter 3
Special hex wrench DRIVER, HEX KHW-M88EA-00X
Used to remove the FNC locate pin.
See "2.2 Cleaning FNC nozzles" in
Chapter 3.
n
NOTE
Use of the leaf spring installation tool makes it possible to install the leaf springs more uniformly. If you have this tool, it is
recommended to install the leaf springs with this tool.
n
NOTE
Removal of the FNC locate pin can be conducted also with a hex wrench (0.7) commercially available as alternative;
however, it can be performed easier by using the special hex wrench (0.7).
c
CAUTION
The part Nos. given in this manual are the original part Nos. which were assigned to the parts when this manual was
issued. Because these part Nos. may be changed without prior notice, be sure to verify the latest part Nos. before
ordering parts.
1-15
1
Maintenance
2.3 Required tools
Prepare the following tools and items necessary for maintenance.
n
Tool list
: Supplied with machine, : Options
Name Description
Oil syringe for nozzle buffing
Used to supply turbine oil (VG32).
Used for greasing of the bevel gear, etc.
Nozzle cleaning wire Used to clean nozzle holes.
Phillips screwdriver Large, small
Slotted (flat-blade) screwdriver Large, small
Phillips precision screwdriver #0, #1 (Used to replace nozzle leaf springs and air valves.)
Flathead precision screwdriver Used when replacing the O-ring
Hex wrench set 1 set
Precision wrench set Used for maintenance of spline shafts.
Grease gun Used to supply grease
Air blow tool Used for cleaning
Ultrasonic cleaner Used to clean nozzles.
Vacuum ASSY Used to clean top surface of feeder plate.
Special hex wrench
Used to remove the FNC locate pin. A hex wrench (0.7) can be also used as
alternative.
n
Other tool list
: Supplied with machine, : Optional purchase part
Name Description
Grease (lithium-based grease: NSL) Used to lubricate X, Y and W axes.
Turbine oil (VG32) Used to lubricate nozzles.
Lint-free cloth Prepare a cloth that does not raise dust.
Square cloth Used to prevent parts from being lost or contaminated. (2 sheets)
Cleaning alcohol Use IPA (isopropyl alcohol) or ethanol.
Paper cup or tray Used for cleaning the inside of spline shaft.
Permanent marker Used for marking when replacing conveyor belt.
Cotton swab stick (15 cm) Used to clean camera prism and lighting unit.
Lens cleaner, Cleaning paper Used to clean camera righting unit.
Blower brush Used to clean camera righting unit.
Cleaning kit Used for cleaning the inside of spline shaft.
Leaf spring installation tool Used to install the leaf springs.
Cleaning wire Used for cleaning nozzle block.
n
Safety goggles and mask
Name Description
Dust-proof goggles
Always wear these goggles and mask when using an Air blow tool or
IPA.
Dust-proof mask
Protective gloves Use when applying lubricant as needed.
