yg200_mpl_je - 第13页
8 17 7 2 3 2 3 1 1 15 15 10 19 9 19 7 17 8 14 5 4 2 2 3 16 16 3 6 11 18 12,13 KGT -1 103 3 2 Y -axis Moving-axis
No. Part No. Part Name Q'ty Remarks Rank Level No. Part No. Part Name Q'ty Remarks Rank Level
1 KGT-M2220-00X COUPLING, X-AXIS 4 /
Í
39
2 90933-01J000 BEARING 8 /
Í
40
3 99009-10400 CIRCLIP 4 /
Í
41
4 KGT-M2271-00X SCREW BALL X AXIS 4 A
r
42
5 KV7-M2604-00X SUPPORT UNIT 4 /
Í
43
6 90K63-711403 AC SERVO MOTOR 4 B
Í
44
7
KGT-M220D-00X
SENSOR, ORG (L=350) 4
B
Í
45
8 KGT-M220E-00X
SENSOR, OT (L=350)
4
B
Í
46
9
KGT-M2267-A1X CABLE, DUCT
4
B
Í
47
10 KGT-M221A-A0X COVER, DUCT ASSY 4 /
Í
48
11 KGT-M220A-30X TAPE X-AXIS 6 /
Í
49
12 KGT-M2291-00X BRACKET, SENSOR F-L 1 /
Í
50
13 KGT-M2291-10X BRACKET, SENSOR F-R 1 /
Í
51
14 KGT-M2291-20X BRACKET, SENSOR R-L 1 /
Í
52
15 KGT-M2291-30X BRACKET, SENSOR R-R 1 /
Í
53
16 KGT-M2248-00X DAMPER 1 8 /
54
17 KGT-M2249-A0X DAMPER 100 ASSY 4 /
Í
55
18 90990-01J023
BOLT HEX. SOCKET HEAD
40
/
Í
56
19
KGT-M2268-00X BRACKET 1, TAPE
4
/
Í
57
20
KGT-M2269-00X
BRACKET 2, TAPE 4
/
Í
58
21 KGT-M220A-00X TAPE , X DUCT 4 /
Í
59
22 KGT-M220B-00X TAPE 2, X DUCT 4 /
Í
60
23 KGT-M220C-00X TAPE 3, X DUCT 4 /
Í
61
24 KGT-M2266-10X PLATE, NUT 8 /
Í
62
25 KGT-M2240-00X SLEEVE, BRG. 4 /
Í
63
26 91317-04008 BOLT HEX. SOCKET HEAD 2 64
27 91317-04010 BOLT HEX. SOCKET HEAD 6 65
28 91317-05014 BOLT HEX. SOCKET HEAD 4 66
29 91317-05016 BOLT HEX. SOCKET HEAD 4 67
30 91317-06012 BOLT HEX. SOCKET HEAD 8 68
31 98902-03006 SCREW BINDING HEAD 4 69
32 91317-05018 BOLT HEX. SOCKET HEAD 4 70
33 71
34 72
35 73
36 74
37 75
38 76
KGT-081105
3
1
X-axis
Moving-axis
8
17
7
2
3
2
3
1
1
15
15
10
19
9
19
7
17
8
14
5
4
2
2
3
16
16
3
6
11
18
12,13
KGT-1103
3
2
Y-axis
Moving-axis
No. Part No. Part Name Q'ty Remarks Rev. Rank Level No. Part No. Part Name Q'ty Remarks Rev. Rank Level
1
KGT-M2671-B0X Y AXIS B.S.SUB ASSY 2 Angular BRG
A
r
38
KGT-M2671-A0X
Y AXIS B.S.SUB ASSY 2 Radial BRG
A
r
39
2 KGT-M2654-00X
PLATE, DUMPER
6
/
Í
40
3
KV7-M2651-00X
DAMPER, STOPPER 6
/
Í
41
4
KGT-M2691-00X BRACKET, SENSOR
2
/
Í
42
5 KGA-M260A-10X SENSOR, ORG (L=400) 2 B
Í
43
6 KGA-M260B-10X SENSOR, OT (L=400) 2 B
Í
44
7 90K63-611404 AC SERVO MOTOR 2 B
Í
45
8 KM5-M2611-00X COUPLING, Y-AXIS: LCD 2 /
Í
46
9 KGT-M2621-00X COVER R, Y AXIS 1 /
47
10 KGT-M2622-00X COVER L, Y AXIS 1 /
48
11
KGT-M36A1-00X DUMP BOX 4 /
49
12 KGT-M36A2-00X PLATE 1, DUMP BOX 2 FRONT /
50
13
KGT-M36A3-00X PLATE 2, DUMP BOX
2 REAR
/
51
14
91314-04010
BOLT HEX. SOCKET HEAD 3
52
15
91317-04014 BOLT HEX. SOCKET HEAD
8
53
16 91317-05018 BOLT HEX. SOCKET HEAD 8 54
17 91317-06018 BOLT HEX. SOCKET HEAD 8 55
18 91317-05010 BOLT HEX. SOCKET HEAD 2 56
19 90990-12J001 SCREW BIN.HEAD W/W 12 57
20 58
21 59
22 60
23 61
24 62
25 63
26 64
27 65
28 66
29 67
30 68
31 69
32 70
33 71
34 72
35 73
36 74
37 75
KGT-1103
Rev. :It had a change without the compatibility. Please be careful at the time of the parts ordering.
Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。
3
2
Moving-axis
Y-axis
