DEK Galaxy
Machine Standard Configuration
Vision
Specification
Vision System
Cognex
Fiducial Recognition
Automatic fiducial teach and find incorporating 0.1mm fiducial capture
Fiducials
2 or 3
Fiducial Types
Synthetic fiducial library or unique pattern recognition
Fiducial Size
0.1mm to 3mm
Fiducial Locations
Anywhere on substrate
Fiducial Error Recovery
Auto lighting adjustment
Auto fiducial search
Camera Lighting
Software controlled programmable LED lighting
Operating Environment
Specification
Temperature
10° to 35° C (50° to 95° F)
Humidity
30% to 70% relative humidity (non-condensing)
Services
Specification
Voltage
100 Volts to 240 Volts +/- 10%. Single phase 50/60Hz
Maximum Current at 115V
15 Amps with vacuum pump
6 Amps without vacuum pump
Maximum Current at 230V
8 Amps with vacuum pump
3 Amps without vacuum pump
Over Current Protection
An external circuit breaker ≤ 20 Amps is required to be fitted in line with the
machine supply
Air Supply
To ISO 8573.1 Standard Quality Class 2.3.3
Pressure 5 bar to 8 bar
General usage 5 litres/minute at 5 bar to 8 bar
Maximum usage 226 litres/minute at 6 bar
Shipping Information
Specification
Approximate Weight
840kg boxed (dependent upon configured options selected with machine)
680kg unboxed (dependent upon configured options selected with machine)
Approximate Dimensions
2060mm x 1500mm x 1570mm (81.1” x 59” x 61.8”)
Certification
Specification
CE
98/37/EC
89/336/EEC
73/23/EEC
Subsequent amendments
SEMI S2/S8 Compliance
Certified
Acoustic Noise Level
Less than 70dB 2003/1/EC
5
DEK Galaxy
Machine Productivity Options
Process
Specification
Print Method
Paste Dispenser
Paste roll height monitor
Ball Placement
ProFlow® ATx
Printing Environments Control
Static – Air Ioniser
Temperature – Temperature Control Module (TCM)
Stencil Frame
VectorGuard®
Under Stencil Cleaning
Typhoon Under Stencil Cleaner (620mm, poly blade insert only)
Software & Communications
Specification
Substrate Handling
Flexible boards
Selective print pass through
Singulation
Topside Referencing System (TRS)
Virtual Panel Tooling (VPT)
Software & Communications
Off Line Printer Programming
GEM on TCP/IP
Remote Smart Factory (RSF)
Transport
Specification
Substrate Support
Vacuum tooling capability
Vacuum tooling sensor
Vacuum cups
Grid-Lok® Tooling
Universal wafer pallet
Precision wafer pallet
Substrate Transport
Single piece conveyor with flat belts (heavy boards)
High Throughput Conveyor (HTC) with round belts
Heavy pallet rails
Wafer Transport Solution (WTS)
Remote board stop (for use with heavy board option)
Substrate Fixture
Over Top Snuggers (OTS)
Snuggers (edge clamping)
Foil-less clamps
Vision
Specification
HawkEye®
HawkEye® Bridging
Other
Specification
Product Data Capture
Verification & Traceability
ProDEK closed loop
Camera Barcode Reader
6
DEK Galaxy
Machine Footprint without HTC
