MODEL TIM-5000 9905-001 TT- 2 Key No. PART No. PART NAME Q'ty REMA RKS 188 411 040 7803 SCR PAN 3X 12 16 M3X 12 PAN 191 630 000 8951 SET SCREW 4 M5X 8 SET 192 630 000 8944 SET SCREW 8 M5X 6 SET NOTE
MODEL TIM-5000
9905-001
TT- 2
Key No. PART No. PART NAME Q'ty REMARKS
101 630 001 1418 BEARING,RADIAL 8
102 630 009 5869 MOTOR,STEPPING 2
103 630 071 7099 PULLEY,TIMING 2
104 630 069 1818 PULLEY,TIMING 4
105 630 071 7631 BELT,TIMING 2
106 630 071 6849 GUIDE,LINEAR 1
107 630 072 1614 CAM FOLLOWER 4
108 630 005 0851 BEARING,PARTS 4
109 630 071 7655 SPRING,TORSION 1
110 630 071 7679 PLATE 2
112 630 000 0252 SENSOR,PHOTO 8
113 630 000 0269 SENSOR,PHOTO(CONNECTOR) 8
116 411 000 9809 RING E 3 1
117 630 074 2152 BRACKET 2
118 630 071 7785 BRACKET 2
120 630 071 7808 BLOCK 2
121 630 071 7815 BLOCK 4
122 630 071 7822 PIN,GUIDE 4
123 630 071 7839 BRACKET 2
124 630 071 7846 BRACKET 4
125 630 071 7853 BLOCK,LOCATE 4
126 630 071 7860 BLOCK 2
127 630 073 9923 PLATE 2
128 630 071 8904 PLATE 4
129 630 074 5498 PLATE 2
130 630 071 7907 BRACKET 1
131 630 071 7914 BRACKET 1
132 630 071 7921 BRACKET 1
133 630 071 7938 ROD 1
137 630 074 0080 FRAM 1
138 630 071 8768 COLLAR 4
156 411 141 4800 WASHER V 12X24X2.5 4 FW12
157 411 141 3308 WASHER SPR 12 4 SW12
161 411 141 4305 WASHER V 6X12.5X1.6 20 FW6
162 411 141 3001 WASHER SPR 6 20 SW6
163 630 000 7909 BOLT,HEX-SCT 20 M6X25
166 411 141 4107 WASHER V 5X10X1 24 FW5
167 411 141 6705 WASHER SPR 5 24 SW5
168 630 000 7749 BOLT,HEX-SCT 8 M5X10
169 630 000 7763 BOLT,HEX-SCT 16 M5X16
170 630 000 7770 BOLT,HEX-SCT 4 M5X35
171 411 141 4008 WASHER V 4X9X0.8 28 FW4
172 411 141 2905 WASHER SPR 4 28 SW4
173 630 000 7626 BOLT,HEX-SCT 28 M4X10
174 630 000 7657 BOLT,HEX-SCT 29 M4X16
175 630 000 7664 BOLT,HEX-SCT 8 M4X20
176 411 141 3902 WASHER V 3X7X0.5 1 FW3
180 411 140 9905 NUT HEX 3 1 M3
186 411 119 1909 WASHER V 3X7X0.5 16 FW3 F
187 411 086 4408 WASHER SPR 3 16 SW3 F
NOTE
MODEL TIM-5000
9905-001
TT- 2
Key No. PART No. PART NAME Q'ty REMARKS
188 411 040 7803 SCR PAN 3X12 16 M3X12 PAN
191 630 000 8951 SET SCREW 4 M5X8 SET
192 630 000 8944 SET SCREW 8 M5X6 SET
NOTE
MEMO
