MODEL TIM-5000 9905-001 MB-5 Key No. PART No. PART NAME Q'ty REMA RKS 401 630 078 9980 BLOCK 1 402 630 067 8598 LEVER 2 403 630 074 2817 SPRING,CO MP 2 404 630 067 7188 PIN,HING E 2 405 630 067 7195 ROD 2 406 630 06…
MODEL TIM-5000
9905-001
異形ヘッドＬ部 DEFORM HAED L SECTION
Fig. MB-5ノズルクランプ部 Nozzle Cramp Section
409
410
402
405
410
406
412
411
407
409
408
409
410
408
409
410
405
409
410
402
409
403
401
403
404
408
409
410
404
408
409
410
410
MODEL TIM-5000
9905-001
MB-5
Key No. PART No. PART NAME Q'ty REMARKS
401 630 078 9980 BLOCK 1
402 630 067 8598 LEVER 2
403 630 074 2817 SPRING,COMP 2
404 630 067 7188 PIN,HINGE 2
405 630 067 7195 ROD 2
406 630 067 7164 NUT 1
407 630 076 5106 CAP 1
408 630 068 6982 RING 4
409 630 007 1740 BEARING,RADIAL 8
410 616 900 0172 RING E 1 8
411 630 076 5090 SWAL 1
412 630 069 5816 AIR LINE EQPT 1
NOTE
2 unit/1 machine
MODEL TIM-5000
9905-001
異形ヘッドＬ部 DEFORM HAED L SECTION
Fig. MB-8ヘッド照明部 Head Lighting Section
779
See Fig.MB-2
Key No.101
See Fig.MB-2
Key No.113
702
780
780
780
711
703
754
712
712
776
777
778
701
