– 90 – E1 3 X Beam Unit 2 1509-002 206 237 239 235 219 230 207 220 220 220 220 233 233 234 234 212 213 209 229 226 234 221 221 214 214 217 237 236 219 204 245 215 215 219 229 228 223 253 251 257 220 243 250 256 255 252 2…
– 89 –
BEAM SECTION
No.
Part No.
Part Name Qty. Detail
Yamaha Hitachi
104 KYA-M2208-00 1005DC1M COVER_X_GREASE 1
105 KYA-M2206-01 1006D70D HEAD_BOX14C 1
107 KYA-M220S-00 1005DC2W HEAD_PLATE_CA 1
108 KYA-M220K-00 1005DC2U X_SCALEBKT_CA 1
109 KYA-M220D-00 1005DC10 X_URETHANE_L 1
111 KYA-M222N-00 10053C6C ASSY,LINEAR MOTOR X 1
112 KYA-M220M-00 1005DC08 X_MAGNET1 1
113 KYA-M220N-00 1005DC09 X_MAGNET2 1
114 KYA-M220P-00 1005DC38 X_GUIDEA 2
115 KYA-M220E-00 1005DC33 X_SCALE01 2
116 KYA-M220J-00 1005DC8F BEAM_ASSY_14_YG 1
118 91312-03010 221AA007 BOLT,HEX.SOCKET HEAD 2
119 91312-04010 221AA017 BOLT,HEX.SOCKET HEAD 30
120 91312-04016 221AA020 BOLT,HEX.SOCKET HEAD 5
121 91312-04020 221AA021 BOLT,HEX.SOCKET HEAD 13
122 91312-05006 221AA027 BOLT,HEX.SOCKET HEAD 4
123 91312-05012 221AA030 BOLT,HEX.SOCKET HEAD 6
126 91312-05030 221AA034 BOLT,HEX.SOCKET HEAD 1
128 90990-11J018 221DA052 SCREW,PAN HEAD WW 1
129 92902-05200 221HA105 WASHER,PLAIN 6
130 92902-04600 221HA204 WASHER,PLAIN 20
133 91380-05012 221A1042 BOLT,HEX.SOCKET HEAD 2
134 91380-05016 221A1045 BOLT,HEX.SOCKET HEAD 18
135 KYA-M220G-00 10063206 ASSY,NAME PLATE 1
136 KYB-M65AW-00 23N30632 WIRING 21
137 90990-11J017 221DA062 SCREW,PAN HEAD WW 17
138 KYB-M131T-00 1010FG03 EDGING 2
139 KYB-M65AB-00 226J0373 MOUNTING_BASE 6
140 90990-11J016 221DA053 SCREW,PAN HEAD WW 9
143 92902-04200 221HA104 WASHER,PLAIN 2
145 KYA-M220U-00 1005A0A7 URETHANE_SHEET 1
150 KYA-M730B-00 10053C64 ASSY_KCAMERAR_2 2
151 KYB-M731C-00 221E0456 BOLT 3
152 KYB-M730A-00 0914G0AA P_RCG_LIGHT 1
153 KYB-M730B-00 0914G0AB P_RCG_SCOPE 1
155 KYB-M730N-00 1010DC2Z CMR_BLOCK 1
156 91312-03008 221AA006 BOLT,HEX.SOCKET HEAD 3
157 91312-04016 221AA020 BOLT,HEX.SOCKET HEAD 1
1509-002
– 91 –
BEAM SECTION
No.
Part No.
Part Name Qty. Detail
Yamaha Hitachi
204 KYA-M2208-00 1005DC1M COVER_X_GREASE 1
206 KYA-M2207-01 1006D70E HEAD_BOX23C 1
207 KYA-M220S-00 1005DC2W HEAD_PLATE_CA 1
208 KYA-M220K-00 1005DC2U X_SCALEBKT_CA 1
209 KYA-M220D-00 1005DC10 X_URETHANE_L 1
211 KYA-M222N-00 10053C6C ASSY,LINEAR MOTOR X 1
212 KYA-M220M-00 1005DC08 X_MAGNET1 1
213 KYA-M220N-00 1005DC09 X_MAGNET2 1
214 KYA-M220P-00 1005DC38 X_GUIDEA 2
215 KYA-M220E-00 1005DC33 X_SCALE01 2
217 KYA-M220T-00 1005DC8G BEAM_ASSY_23_YG 1
218 91312-03010 221AA007 BOLT,HEX.SOCKET HEAD 2
219 91312-04010 221AA017 BOLT,HEX.SOCKET HEAD 30
220 91312-04016 221AA020 BOLT,HEX.SOCKET HEAD 3
221 91312-04020 221AA021 BOLT,HEX.SOCKET HEAD 13
222 91312-05006 221AA027 BOLT,HEX.SOCKET HEAD 4
223 91312-05012 221AA030 BOLT,HEX.SOCKET HEAD 6
226 91312-05030 221AA034 BOLT,HEX.SOCKET HEAD 1
228 90990-11J018 221DA052 SCREW,PAN HEAD WW 1
229 92902-05200 221HA105 WASHER,PLAIN 6
230 92902-04600 221HA204 WASHER,PLAIN 20
233 91380-05012 221A1042 BOLT,HEX.SOCKET HEAD 2
234 91380-05016 221A1045 BOLT,HEX.SOCKET HEAD 18
235 KYA-M220G-00 10063206 ASSY,NAME PLATE 1
236 KYB-M65AW-00 23N30632 WIRING 2
237 90990-11J017 221DA062 SCREW,PAN HEAD WW 2
238 KYB-M131T-00 1010FG03 EDGING 2
239 KYB-M65AB-00 226J0373 MOUNTING_BASE 6
240 90990-11J016 221DA053 SCREW,PAN HEAD WW 9
243 92902-04200 221HA104 WASHER,PLAIN 2
245 KYA-M220U-00 1005A0A7 URETHANE_SHEET 1
250 KYA-M730A-00 10053C63 ASSY_KCAMERAF_2 2
251 KYB-M731C-00 221E0456 BOLT 3
252 KYB-M730A-00 0914G0AA P_RCG_LIGHT 1
253 KYB-M730B-00 0914G0AB P_RCG_SCOPE 1
255 KYB-M730N-00 1010DC2Z CMR_BLOCK 1
256 91312-03008 221AA006 BOLT,HEX.SOCKET HEAD 3
257 91312-04016 221AA020 BOLT,HEX.SOCKET HEAD 1
1509-002
