– 1 10 – E2 2006-009 6 Cover Cart 501 506 505 551 503 502 502 553 552 504 508 507
– 109 –
CUTTER SECTION
2006-009
No.
Part No.
Part Name Qty. Detail
Yamaha Hitachi
401 KYB-M3T00-00 0920H147 BASE 1
402 KYB-M3T1L-00 0920H13U LEVER_STOPPER 1
403 KYB-M3T0J-00 0920H12H PIN 1
404 KYB-M3T1A-00 0920H127 DISK 2
405 KYB-M3T1P-00 0920H14Z SHAFT 1
406 KYB-M3T0N-00 0920H15H GUIDE 1
407 KYB-M3T3V-00 222D0412 BEARING,RADIAL 2
408 KYB-M3T1B-00 0920H12A HOLDER 1
409 KYB-M3T1C-00 0920H12D COLLAR 1
410 KYB-M3T1S-00 0920H156 HOLDER 1
411 KYB-M3T1U-00 0920H159 SEAL 1
412 KYB-M3T1V-00 0920H15A SEAL_COVER 1
413 KYB-M3T2N-00 213A1411 SHAFT 1
414 KYB-M3T2T-00 213A1610 SHAFT 1
415 KYB-M3T0K-00 0920H12T GUIDE 1
416 90933-01J800 222D0376 BEARING,RADIAL 2
417 KYB-M3T34-00 222E0017 BEARING,THRUST 1
418 KYB-M3T2X-00 216B1514 HOLDER 1
419 KYB-M3T35-00 222M1378 SPRING,COMP 1
420 KYB-M3T2B-00 211DC026 PLATE 1
421 KYB-M3T2C-00 211DC027 PLATE 1
422 KYB-M3T2D-00 211DC028 PLATE 1
423 KYB-M3T2E-00 211DC029 PLATE 1
424 KYB-M3T1N-00 0920H14G LEVER 1
425 KYB-M3T1D-00 0920H12E BEARING 1
426 KYB-M3T1E-00 0920H12F COVER 1
427 KYB-M3T1F-00 0920H12G COVER 1
428 KYB-M3T1G-00 0920H12K SPRING 1
429 KYB-M3T1H-00 0920H12L GUIDE 1
430 KYB-M3T1K-00 0920H13F GUIDE 1
431 KYB-M3T1W-00 0920H15K COLLAR 2
432 KYB-M3T1X-00 0920H15L COLLAR 2
433 KYB-M3T1Y-00 0920H15M COLLAR 1
434 KYB-M3T20-00 0920H15N COLLAR 1
435 92012-05010 0920H11N BOLT,BUTTON HEAD 1 BUTTAN M5L10
436 90112-02J008 221AA115 BOLT,HEX.SOCKET HEAD 2 M2L8
437 90990-06J004 221A0231 BOLT,HEX-SCT 10 BUTTAN M3L4
438 KYB-M3T23-00 0920H16Z LOCKING_METAL 2
439 92A08-04004 221CB002 SCREW,SET 2 SET M4L4
440 90990-01J118 0920H158 BOLT,HEX.SOCKET HEAD 12 M1.6L5
441 90990-66J006 221DA218 SCREW,TRUSS HEAD 4 TRS M2L3
442 91312-04025 221AA022 BOLT,HEX.SOCKET HEAD 1 M4L25
443 91312-03008 221AA006 BOLT,HEX.SOCKET HEAD 2 M3L8
444 KYB-M4113-00 221HA301 ROHS_WASHER 1 BW3
445 90990-02J020 221CA001 SCREW,SET 1 SET M3L4
– 111 –
CUTTER SECTION
2006-009
No.
Part No.
Part Name Qty. Detail
Yamaha Hitachi
501 KYB-M3T5W-00 SUPPORT 1 SL-Cover
502 KYB-M3T18-00 0920H10K MECH_PARTS 2
503 KYB-M3T06-00 1010H23G DUSTCHUTE-CART 1
504 KYB-M3T09-00 1010020R ASSY_NAME_PLATE 1
505 KYB-M3T08-10 LABEL(SL) 1 SL-Cover
506 KYB-M3T29-00 1010H23U URETHANE_SHEET 2
507 KYB-M3T5W-03 SUPPORT 1 ST-Cover
508 KYB-M3T08-20 LABEL ST-A 1 ST-Cover
551 90990-01J144 221AA100 BOLT,HEX.S/H WW 4
552 90990-66J012 221DA207 SCREW,TRUSS HEAD 2
553 90990-66J017 221DA221 SCREW,TRUSS HEAD 4
