– 135 –
PANEL, CENTER FRAME SECTION
2006-009
No.
Part No.
Part Name Qty. Detail
Yamaha Hitachi
105 KYB-M130X-00 10105G2L ROOF_FAN_1_ASSY 1
105-01 KYB-M130R-00 10105A02 ASSY-TOP-FAN-L 1
105-02 KYB-M1312-00 1010FB0N FAN_PLATE 1
105-03 KYB-M131Y-00 23M00070 ACCESSORY-MOT-M 2
105-04 90990-01J149 221AA105 BOLT,HEX.S/H WW 6 M4L18 SW+FW
105-05 95302-04600 221FA007 NUT,HEXAGON 6 M4
105-06 92902-04200 221HA104 WASHER,PLAIN 6 FW4
106 KYB-M130Y-00 10105G2M ROOF_FAN_2_ASSY 1
106-01 KYB-M130S-00 10105A03 ASSY-TOP-FAN-R 1
106-02 KYB-M1312-00 1010FB0N FAN_PLATE 1
106-03 KYB-M131Y-00 23M00070 ACCESSORY-MOT-M 2
106-04 90990-01J149 221AA105 BOLT,HEX.S/H WW 6 M4L18 SW+FW
106-05 95302-04600 221FA007 NUT,HEXAGON 6 M4
106-06 92902-04200 221HA104 WASHER,PLAIN 6 FW4
109 KYB-M130U-10 ASSY-PILOT-LAMP 1
110 KYB-M130T-00 10105A04 ASSY-MATERIAL-LIGHT 2
