HIGH SPEED HEAD SECTION
2006-009
No.
Part No.
Part Name Qty. Detail
Yamaha Hitachi
3 KYB-M7008-00 0914014W ASSY_WARNING-HH_1 1
4 KYB-M700B-00 1011300Z ASSY_PLATE_INDEX 1
14 KYB-M701J-00 1011D606 PCB-MOUNT 1 UC40
15 KYX-M701M-00 PCB-MOUNT 1 UC48
17 KYB-M701K-01 HNS,SLIP RING 1
18 KYB-M701L-00 1011D60B HNS,HEAD SENSOR 1
19 KYX-M700F-00 COVER_HEAD 1
20 KYX-M700E-00 BRACKET, MOVE 1
21 KYB-M701G-00 1011D21M BRACKET_CON-CAB 1
22 KYX-M7009-00 ASSY_CONNECTOR-BOX 1
22-01 KYB-M7011-00 1011300T ASSY-BLOW-VALVE 1
22-02 KYX-M700G-00 BRACKET_BOX 1
22-03 KYB-M91AJ-00 1005AB17 PIPE_FITTINGS 1
22-04 KYB-M703M-00 1011D20N PIPE_FITTINGS 1
22-05 KYB-M220P-00 1005AB0E PIPE_FITTINGS 1
22-06 90112-02J010 221AB014 BOLT,HEX.SOCKET HEAD 2 M2L10
22-07 90171-02J026 221HA101 WASHER,PLAIN 2 FW2
22-08 91312-03016 221AA010 BOLT,HEX.SOCKET HEAD 1 M3L16
22-09 92902-03200 221HA103 WASHER,PLAIN 1 FW3
31 KYB-M65AW-00 23N30632 WIRING 3
32 97602-03306 221DB002 SCREW,PAN HEAD WW 5 PAN M3L6 SW+FWS
33 91312-03006 221AA005 BOLT,HEX.SOCKET HEAD 9 M3L6
34 91312-03016 221AA010 BOLT,HEX.SOCKET HEAD 2 PAN M3L16 SW+FW
35 91312-04008 221AA016 BOLT,HEX.SOCKET HEAD 4 M4L8
36 90990-11J009 221DA051 SCREW,PAN HEAD WW 7 PAN M3L6 SW+FW
37 KYB-M700C-00 10113101 ASSY_WARNING-HH_2 1
– 143 –
HIGH SPEED HEAD SECTION
2006-009
No.
Part No.
Part Name Qty. Detail
Yamaha Hitachi
121 KYB-M703J-00 1011300Q ASSY_MOTOR_HL 1
121-01 KYB-M701F-00 1011D21K MOTOR_AC-SERVO 1
121-02 KYB-M702C-00 0916DK19 COUPLING 1
122 KYB-M703K-00 1011300R ASSY_STOPER_HL 1
122-01 KYB-M703T-00 1011D21U PLATE_HL-SP 1
122-02 KYB-M703S-00 1011D21C STOPPER_HL 1
122-03 95302-03700 221FA006 NUT,HEXAGON 1 M3
122-04 92902-03200 221HA103 WASHER,PLAIN 1 FW3
135 KYB-M703U-00 1011D21Z SPRING_COMP 1
136 KYB-M702K-00 0916DL21 PLATE_HL_SPRING 1
139 92902-03200 221HA103 WASHER,PLAIN 2 FW3
142 91312-03010 221AA007 BOLT,HEX.SOCKET HEAD 4 M3L10
144 90112-2AJ010 221AA321 BOLT,HEX.SOCKET HEAD 2 M2.5L10
158 91312-03008 221AA006 BOLT,HEX.SOCKET HEAD 6 M3L8
170 KYB-M700X-00 1011300D ASSY_OUT-BASE 1
170-01 KYB-M703L-00 10113013 ASSY_HL_BALL_SCREW 1
170-02 KYB-M704H-00 226J2537 STOPPER 1
170-03 KYB-M7018-00 1011D202 GUIDE_LINEAR_HL 2
170-04 KYB-M7006-00 1011D21S BASE_OUTSIDE 1
170-05 91312-03008 221AA006 BOLT,HEX.SOCKET HEAD 18 M3L8
171 KYB-M7010-00 1011300S ASSY-HL-SENSOR 1
172 KYB-M7045-00 221A0468 BOLT_HEX-SCT 4
173 92902-06200 221HA106 WASHER,PLAIN 4 FW6
174 KYB-M65AW-00 23N30632 WIRING 1
175 90990-11J009 221DA051 SCREW,PAN HEAD WW 1 PAN M3L6 SW+FW
