– 179 –
SINGLE CONVEYOR SECTION
2006-009
No.
Part No.
Part Name Qty. Detail
Yamaha Hitachi
1 KYX-M911J-00 BASE 1
2 KYX-M9169-01 ASSY-CV-VALVE 1 ‘-00’ Compatible
3 KYB-M913A-00 0921A059 AIR_LINE_EQPT 8
4 KYX-M9132-00 BRACKET,BASE 1
5 KYX-M917W-00 BRACKET L 2
6 KYB-M91BW-00 1012C09F AIR_BRACKET 2
7 KYX-M912R-00 BRACKET,BASE R 1
8 KYB-M9185-00 1012C088 CABLE_VEYOR 2
9 KYB-M91D4-00 226J2510 CABLE_VEYOR 4
10 KYB-M5806-13 STEPPER_DRV_BRD_ASSY 1 ‘-12’ Compatible (PU)
11 90990-66J012 221E0532 SCREW,TRUSS HEAD 18
12 91312-04035 221AA024 BOLT,HEX.SOCKET HEAD 4
13 91312-04006 221AA015 BOLT,HEX.SOCKET HEAD 4
14 90990-66J008 221E0529 SCREW,TRUSS HEAD 4
16 90990-11J014 221DA058 SCREW,PAN HEAD WW 4
17 KYB-M91F5-00 23L10024 ACCESSORY-PCB 4
18 KYB-M91F6-00 23L10025 ACCESSORY-PCB 4
19 90990-11J016 221DA053 SCREW,PAN HEAD WW 13
20 KYB-M65AW-00 23N30632 WIRING 13
21 KYX-M9187-00 GUIDE LINEAR 2
22 91312-04016 221AA020 BOLT,HEX.SOCKET HEAD 18
23 90563-03J100 SPACER,BOLT 4
24 90563-03J140 SPACER,BOLT 4
25 90990-11J009 221E0601 SCREW,PAN HEAD WW 4
26 KYB-M5806-03 STEPPER_DRV_BRD_ASSY 2 ‘-02’ Compatible
27 KYB-91AK-00 PCB_MOUNT 1
