– 194 – H1 2006-009 10 L/R 19 16 19 15 19 15 19 16 4 18 17 17 18 18 17 18 17 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 13 13 13 7 7 13 12 12 6 6 10 8 9 1 1 1 1 1 1 4 4 4 4 4 4 1 1 2 2 20 14 20 14 3 3 3 4 3 5

100%1 / 258
– 193 –
SINGLE CONVEYOR SECTION
2006-009
No.
Part No.
Part Name Qty. Detail
Yamaha Hitachi
1 KYX-M911E-00 FRAME,CONVEYOR 2C 1
2 KYX-M911H-00 PLATE 1
3 KYB-M91CV-00 223Q0663 PULLEY_TIMING 2
4 KYX-M917N-00 BRACKET,CRAMP 1R2L 1
5 KYX-M917P-00 BRACKET,CRAMP 1L2R 1
6 KYX-M917R-00 BRACKET,CRAMP 1CR2CL 1
7 KYX-M917S-00 BRACKET,CRAMP 1CL2CR 1
8 KYB-M91F1-00 226A0144 SEAL 8
9 KYB-M91CE-00 213A1378 SHAFT 8
10 KYB-M91EY-00 226A0074 SEAL 8
11 KYB-M91EX-00 226A0001 SEAL 8
12 KYB-M91CN-00 216Q0044 BUSH_LOCATE 8
13 KYB-M91CS-00 222M1297 SPRING_COMP 8
14 $M-3AU-3 225F0421 PIPE_FITTINGS 8
15 $M-3UT 225F0330 PIPE_FITTINGS 4
16 $M-3ALU-3 225F0240 PIPE_FITTINGS 4
17 90990-01J127 221A0431 BOLT,HEX.SOCKET HEAD 12
18 KYB-M917Y-00 1012C075 CHUTE_COVER 2
19 KYB-M9198-00 222C0133 GUIDE_SLIDE 8
21 90990-02J020 221C0001 SCREW,SET 8
22 KYB-M91C4-00 211E1117 SPACER 10
23 90990-01J129 221A0443 BOLT,HEX.SOCKET HEAD 8
24 KYB-M91E9-00 221D0201 MACHINE_SCREW 8
25 98702-03006 221DA106 SCREW,FLAT HEAD 4
26 90990-02J019 221CA026 SCREW,SET 2
– 194 –
H1
2006-009
10 L/R
19
16
19
15
19
15
19
16
4
18
17
17
18
18
17
18
17
11
11
11
11
11
11
11
11
11
13
13
13
7
7
13
12
12
6
6
10
8
9
11
11
11
4
4
4
4
4
4
1
1
2
2
20
14
20
14
3
3
3
4
3
5
– 195 –
SINGLE CONVEYOR SECTION
2006-009
No.
Part No.
Part Name Qty. Detail
Yamaha Hitachi
1 KYX-M912S-00 FRAME,CONVEYOR 1R 2
2 KYX-M912V-00 FRAME,CONVEYOR 2 2
3 KYB-M917J-00 1012C00S CHUTE_BRACKET 4
4 KYB-M91AL-00 1007A097 PULLEY_TIMING 8
5 KYB-M919U-00 0917C41H BRACKET_R1 1
6 KYB-M919P-00 0917C41A BRACKET_LR 2
7 KYB-M919R-00 0917C41B BRACKET 2
8 KYB-M919T-00 0917C41G BRACKET_L1 1
9 KYB-M916A-00 10122303 ASSY-BOARD-DET 1
10 KYB-M916C-00 10122305 ASSY-BOARD-DET 1
11 91312-03006 221AA005 BOLT,HEX.SOCKET HEAD 12
12 90990-01J139 221AA092 BOLT,HEX.S/H WW 4
13 90990-01J138 221AA099 BOLT,HEX.S/H WW 6
14 90990-66J012 221E0532 SCREW,TRUSS HEAD 4
15 KYY-M918W-20 BLOCK,CHUTE GUIDE 1 2
16 KYY-M918X-20 BLOCK,CHUTE GUIDE 2 2
17 KLF-M9135-01 PLATE,EDGE 2 6
18 98702-03006 221DA106 SCREW,FLAT HEAD 8
19 91312-04016 221AA020 BOLT,HEX.SOCKET HEAD 8
20 KYB-M65AW-00 23N30632 WIRING 4
