– 200 – H1 2006-009 13 Back-up Plate, Pin 8 8 9 7 5 10 2 3 4 1-03 1-03 1-02 1-01 1 4 4 4 1 1 12 13 9 6 5 10 4

– 199 –

SINGLE CONVEYOR SECTION

2006-009

No.

Part No.

Part Name Qty. Detail

Yamaha Hitachi

1 KYX-M9140-00 HNS,CONV-POW 1

2 KYB-M9147-00 1010CA28 HNS,CONV-VALVE 1

3 KYX-M9145-00 HNS,FIBER-AMP 1

4 KYB-M9148-00 1010CA29 HNS,STOPPER-L 1

5 KYB-M9149-00 1010CA2A HNS,STOPPER-R 1

6 KYB-M914L-00 1010CA2N HNS,STOPPER 1

7 KYB-M914A-00 1010CA2B HNS,BU-PIN-R 1

8 KYX-M914B-00 HNS,BU-PIN-T 1

10 KYX-M9141-00 HNS,CONV-MOT-L 1

11 KYX-M9142-00 HNS,CONV-MOT-M 1

12 KYX-M9143-00 HNS,CONV-MOT-R 1

13 KYX-M9144-00 HNS,WIDTH-MOT 1

14 KYX-M914J-00 HNS,BOARD-DET 1

15 KYX-M914K-00 HNS,BOARD-DET 1

16 KYX-M9146-00 HNS,CHUTE-ORG 1

17 KYX-M914G-00 HNS,AELINK-N1 1

18 KYX-M914H-00 HNS,AELINK-N2 1

19 KYX-M914C-00 HNS,BU-MOT-L 1

20 KYX-M914D-00 HNS,BU-MOT-R 1

21 KYX-M914E-00 HNS,SEN-BU-MOT 1

22 KYX-M914F-00 HNS,SEN-BU-MOT 1

23 KYX-M91P9-00 - HNS,CLAMP-SENSOR 1

24 KYB-M91AK-00 1005CA00 PCB-MOUNT 1

25 KYB-M5806-03 STEPPER DRV BRD ASSY 2

– 200 –

H1

2006-009

13 Back-up Plate, Pin

8

8

9

7

5

10

2

3

4

1-03

1-03

1-02

1-01

1

4

4

4

11

12

13

9

6

5

10

4

– 201 –

SINGLE CONVEYOR SECTION

2006-009

No.

Part No.

Part Name Qty. Detail

Yamaha Hitachi

1 KYX-M910M-10 BACK UP ASSY. 1

1-01 KYX-M910A-10 BASE R ASSY. 1

1-02 KYX-M910B-10 BASE L ASSY. 1

1-03 91317-08016 1012C0AE BOLT,HEX.SOCKET HEAD 16

2 KYX-M911F-00 PLATE L 1

3 KYX-M911G-00 PLATE R 1

4 91312-04010 221AA017 BOLT,HEX.SOCKET HEAD 20

5 KYB-M916K-00 101223A2 ASSY-BU-PIN-SENS 1

6 KYX-M91BG-00 BRACKET R 1

7 KYX-M91BF-00 BRACKET L 1

8 90166-02J210 221DA004 SCREW,PAN HEAD 4

9 90171-02J026 221H0307 WASHER,PLAIN 4

10 KYB-M91C8-00 211FD666 BRACKET 2

11 KYA-M3802-00 0974J00U BACK_UP_PIN 20

12 KYA-M7740-A0 0974900Y NOZZLE PK01C ASSY. 1

13 KYX-M91AM-00 BUP-DET-SENSOR ASSY. 1
