– 205 –
SINGLE CONVEYOR SECTION
2006-009
No.
Part No.
Part Name Qty. Detail
Yamaha Hitachi
1 KYX-M911A-10 PLATE,BASE L 1
2 KYB-M9191-00 BRACKET,MOTOR 1
3 KYB-M913X-00 1007A007 MOTOR_STEPPING 1
4 KYB-M91BL-00 1012C085 PULLEY_TIMING 1
5 KYB-M91BE-02 1012C07R DISK 1
6 KYB-M91BD-00 1012C07Q BRACKET 1
7 KYB-M261N-00 23G10001 SENSOR-PHOTO 2
8 KYB-M9130-000 HOLDER 2
9 KYB-M919C-001 BALL SCREW 2
10 KYB-M919G-001 PULLEY_TIMING 2
11 KYB-M912N-00 BLOCK,DISK 2
12 KYB-M919X-00 0948C203 BLOCK(BACKUP) 2
13 KYB-M91C5-00 BRACKET 1
14 90933-03J608 222D0343 BEARING_RADIAL 2
15 KYB-M91CH-00 216A1552 COLLAR 1
16 KYB-M91CJ-00 216A1586 COLLAR 1
17 KYB-M91CL-00 COLLAR 1
18 KYX-M91BC-00 TIMING BELT 1
19 KYX-M91BY-00 BLOCK,STOPPER 2
20 91312-05016 221AA031 BOLT,HEX.SOCKET HEAD 4
21 KYB-M65AA-00 221HA303 ROHS_WASHER 4
22 91312-04010 221AA017 BOLT,HEX.SOCKET HEAD 10
23 90990-02J026 221CA007 SCREW,SET 4
24 91312-04006 221AA015 BOLT,HEX.SOCKET HEAD 3
25 97602-03312 221DA047 SCREW,PAN HEAD WW 4
26 91312-06016 BOLT,HEX.SOCKET HEAD 6
27 91312-04012 BOLT,HEX.SOCKET HEAD 6
28 91312-04016 BOLT,HEX.SOCKET HEAD 8
29 92902-04600 221HA204 WASHER,PLAIN 8
30 91312-04020 221AA021 BOLT,HEX.SOCKET HEAD 4
31 91312-03006 221AA005 BOLT,HEX.SOCKET HEAD 4
32 92902-03200 221HA103 WASHER,PLAIN 2
33 91312-08055 221AA336 BOLT,HEX.SOCKET HEAD 1
34 92902-08200 221HA107 WASHER,PLAIN 1
35 92902-04200 221HA104 WASHER,PLAIN 3
36 90132-10J055 221BB008 BOLT,HEXAGON 1
37 90189-02J106 221FA015 NUT,HEXAGON 1
