– 213 –
DUAL CONVEYOR SECTION
2006-009
No.
Part No.
Part Name Qty. Detail
Yamaha Hitachi
1 KYB-M912F-00 0992C40Q BLOCK(KL) 1
2 KYB-M912E-00 0992C40E BLOCK(KR) 1
3 KYB-M913N-00 0948C41L BLOCK(KLT) 1
4 KYB-M913P-00 0948C41M BLOCK(KRT) 1
5 KYB-M91BH-00 1012C07X BRACKET_LRI 1
6 KYB-M916X-00 101223B8 ASSY-PCB-SEN-MB 1 L-R
7 KYB-M916X-10 ASSY-PCB-SEN-MB-FL 1 R-L
8 KYB-M917E-00 101223BQ ASSY-STOPPER-RB 1 L-R
9 KYB-M917E-10 ASSY-STOPPER-RB-FL 1 R-L
10 KYB-M91CD-00 211G5843 BLOCK 1
11 KYB-M91CB-00 211FE532 BRACKET 1
12 $M-3ALU-3 225F0240 PIPE_FITTINGS 2
13 KYB-M91CC-00 211FE801 BRACKET 1
14 KYB-M918K-00 1012CA0M MOTOR_STEPPING 1
15 KYB-M91CW-00 223Q0749 PULLEY_TIMING 1
16 KYB-M91CX-00 223Q0755 PULLEY_TIMING 1
17 KYB-M919E-00 223L0383 BELT_TIMING 1
18 KYB-M91C2-00 1012CA10 PULLEY_FLAT 1
19 90933-03J693 222D0016 BEARING_RADIAL 2
20 KYB-M91C7-00 211FD663 BRACKET 1
21 KYB-M91AD-00 0992C40G BLOCK 2
22 KYB-M919S-00 0917C41F BRACKET 1
23 91312-05020 221AA032 BOLT,HEX.SOCKET HEAD 4
24 91312-05016 221AA031 BOLT,HEX.SOCKET HEAD 4
25 91312-05012 221AA030 BOLT,HEX.SOCKET HEAD 2
26 91312-05010 221AA029 BOLT,HEX.SOCKET HEAD 2
27 91312-04008 221AA016 BOLT,HEX.SOCKET HEAD 2
28 91312-03008 221AA006 BOLT,HEX.SOCKET HEAD 4
29 91312-04012 221AA018 BOLT,HEX.SOCKET HEAD 2
30 91312-03006 221AA005 BOLT,HEX.SOCKET HEAD 2
31 91312-06030 221AA046 BOLT,HEX.SOCKET HEAD 4
32 90990-01J138 221AA099 BOLT,HEX.S/H WW 1
33 90990-07J007 221B1015 BOLT,HEXAGON 1
34 90990-06J008 221A0229 BOLT,BUTTON HEAD 2
35 90990-02J024 221CA005 SCREW,SET 2
36 95302-03600 221FA005 NUT,HEXAGON 1
37 95302-04600 221FA007 NUT,HEXAGON 1
38 95302-05600 221FA009 NUT,HEXAGON 1
39 92902-03100 221HA003 WASHER,SPRING 1
40 92902-05100 221HA005 WASHER,SPRING 3
41 92902-03600 221HA203 WASHER,PLAIN 1
42 92902-05200 221HA105 WASHER,PLAIN 5
