COVER SECTION
2006-009
No.
Part No.
Part Name Qty. Detail
Yamaha Hitachi
301 KYA-M1309-00 1005FB03 COVER F GUL SIDE L 1
302 KYA-M131A-00 1005FB05 GUM_CUSHION 1
303 KYA-M131C-00 1005FB07 GUM_CUSHION 1
304 KYA-M132E-00 0913F20X REAR_BLOCK_B 1
305 KYA-M132C-00 0913F20V UNDER_BLOCK_L 1
306 90990-11J015 221DA046 SCREW,PAN HEAD WW 4 M3L20 SW+FW
307 90990-11J010 221DA056 SCREW,PAN HEAD WW 9 M3L8 SW+FW
308 90990-66J010 221DA205 SCREW,TRUSS HEAD 2 TRS M3L12
309 KYC-M174N-00 0913F21E MG_CATCH_C9302 1
311 KYA-M1308-00 1005FB02 COVER F GUL SIDE R 1
312 KYA-M131A-00 1005FB05 GUM_CUSHION 1
313 KYA-M131C-00 1005FB07 GUM_CUSHION 1
314 KYA-M132D-00 0913F20W REAR_BLOCK_A 1
315 KYA-M132F-00 0913F21F UNDER_BLOCK_R 1
316 90990-11J015 221DA046 SCREW,PAN HEAD WW 4 M3L20 SW+FW
317 90990-11J010 221DA056 SCREW,PAN HEAD WW 9 M3L8 SW+FW
318 90990-66J010 221DA205 SCREW,TRUSS HEAD 2 TRS M3L12
319 KYC-M174N-00 0913F21E MG_CATCH_C9302 1
400 KYX-M130A-00 ASSY GUL-COVER 2
401 91312-05016 221AA031 BOLT,HEX.SOCKET HEAD 16 M5L16
402 92902-05100 221HA005 WASHER,SPRING 16
403 92902-05200 221HA105 WASHER,PLAIN 16
