– 227 – DU AL CONVEY OR SE CT ION 2006-009 No. Part No. Part Name Qty . Detail Y amaha Hitachi 1 KYX-M9122-00 CHUTE2KL 1 2 KYX-M9123-00 CHUTE2KR 1 3 KYB-M918K-00 1012CA0M MOTOR_STEPPING 2 4 KYB-M91CV -00 223Q0663 PULLEY_…
– 227 –
DUAL CONVEYOR SECTION
2006-009
No.
Part No.
Part Name Qty. Detail
Yamaha Hitachi
1 KYX-M9122-00 CHUTE2KL 1
2 KYX-M9123-00 CHUTE2KR 1
3 KYB-M918K-00 1012CA0M MOTOR_STEPPING 2
4 KYB-M91CV-00 223Q0663 PULLEY_TIMING 4
5 KYB-M91CW-00 223Q0749 PULLEY_TIMING 2
6 KYB-M91C2-00 1012CA10 PULLEY_FLAT 4
7 KYB-M919F-00 223L0384 BELT_TIMING 2
8 KYB-M913G-00 0948C417 MBRACKET(2L) 1
9 KYB-M919U-00 0917C41H BRACKET_R1 1
10 KYB-M919T-00 0917C41G BRACKET_L1 1
11 KYB-M916U-00 101223B5 ASSY-PCB-SEN-LA 1
12 KYB-M916Y-00 101223B9 ASSY-PCB-SEN-RA 1
13 KYB-M913H-00 0948C418 MBRACKET(2R) 1
14 KYB-M919P-00 0917C41A BRACKET_LR 2
15 KYB-M919R-00 0917C41B BRACKET 2
16 KYY-M918W-21 BLOCK,CHUTE GUIDE 1 1
17 KYY-M918X-21 BLOCK,CHUTE GUIDE 2 1
18 KLF-M9135-01 PLATE,EDGE 2 2
19 90990-01J138 221AA099 BOLT,HEX.S/H WW 6
20 90990-01J139 221AA092 BOLT,HEX.S/H WW 4
21 91312-03008 221AA006 BOLT,HEX.SOCKET HEAD 4
22 91312-04010 221AA017 BOLT,HEX.SOCKET HEAD 4
23 91312-04016 221AA020 BOLT,HEX.SOCKET HEAD 4
24 91312-05025 221AA033 BOLT,HEX.SOCKET HEAD 2
25 91312-05030 221AA034 BOLT,HEX.SOCKET HEAD 2
26 92902-05200 221HA105 WASHER,PLAIN 2
27 90990-02J024 221CA005 SCREW,SET 4
28 95302-05600 221FA009 NUT,HEXAGON 4
29 90990-66J012 221DA207 SCREW,TRUSS HEAD 2
30 98702-03006 221DA106 SCREW,FLAT HEAD 4
