– 237 –
DUAL CONVEYOR SECTION
2006-009
No.
Part No.
Part Name Qty. Detail
Yamaha Hitachi
1 KYB-M913L-00 0948C41J BLOCK(2L3RT) 1
2 KYB-M913M-00 0948C41K BLOCK(2R3LT) 1
3 KYB-M91AA-00 0948C41U BRACKET(3L) 1
4 KYB-M91C6-00 211FD659 BRACKET 2
5 KYB-M917A-00 101223BL ASSY-BU-SEN-3 1
6 KYB-M91C8-00 211FD666 BRACKET 2
7 KYB-M91CX-00 223Q0755 PULLEY_TIMING 1
8 KYB-M919E-00 223L0383 BELT_TIMING 1
9 KYB-M918K-00 1012CA0M MOTOR_STEPPING 1
10 KYB-M91CW-00 223Q0749 PULLEY_TIMING 1
11 KYB-M91C2-00 223M0059 PULLEY_FLAT 1
12 90933-03J693 222D0016 BEARING_RADIAL 2
13 90990-01J131 221AB008 BOLT,HEX.SOCKET HEAD 4
14 91312-03016 221AA010 BOLT,HEX.SOCKET HEAD 2
15 90990-02J024 221CA005 SCREW,SET 2
16 91312-03008 221AA006 BOLT,HEX.SOCKET HEAD 4
17 91312-04008 221AA016 BOLT,HEX.SOCKET HEAD 2
18 90166-02J210 221DA004 SCREW,PAN HEAD 4
19 92902-05100 221HA005 WASHER,SPRING 5
20 92902-03100 221HA003 WASHER,SPRING 1
21 95302-03600 221FA005 NUT,HEXAGON 1
22 95302-05600 221FA009 NUT,HEXAGON 1
23 90171-02J026 221H0307 WASHER,PLAIN 8
24 92902-03600 221HA203 WASHER,PLAIN 1
25 92902-05200 221HA105 WASHER,PLAIN 5
