– 23 –
FEEDER CART SECTION
2006-009
No.
Part No.
Part Name Qty. Detail
Yamaha Hitachi
203 91312-04010 221AA017 BOLT,HEX.SOCKET HEAD 3 M4L10
204 92902-04200 221HA104 WASHER,PLAIN 3 FW4
205 91312-05010 221AA029 BOLT,HEX.SOCKET HEAD 4 M5L10
211 KYX-M3702-00 BOX_COVER 1
212 KYB-M370E-00 1010E10H EL_BOX 1
213 KYB-M372D-00 1010E10L HINGE 3
214 KYB-M372J-00 1015A110 STEEL-SPACER 1
215 KYB-M371G-00 1014A100 PCB-MOUNT 2
216 KYB-M371H-00 1014A101 PCB-MOUNT 1
217 KYB-M65AW-00 23N30632 WIRING 4
218 KYB-M3724-00 0920E30U ACCESSORY-P-C-B 16
219 KYB-M65AB-00 226J0373 MOUNTING_BASE 1
220 KYB-M3739-00 4W204901 HNS,DRAWER 30
221 KYB-M372X-00 2.21E0298 BOLT 60
231 90990-66J022 221DA220 SCREW,TRUSS HEAD 32 TRS M3L5
232 90990-66J008 221DA203 SCREW,TRUSS HEAD 12 TRS M3L6
233 90990-11J009 221DA051 SCREW,PAN HEAD WW 1 TRS M3L6
234 90990-11J015 221DA046 SCREW,PAN HEAD WW 5 PAN M3L20
235 90990-11J016 221DA053 SCREW,PAN HEAD WW 13 PAN M4L6
236 92902-03200 221HA103 WASHER,PLAIN 1
237 KYB-M3737-00 4W204583 HNS,FLAT 2
238 KYB-M3738-00 4W204584 HNS,FLAT 2
– 24 –
C1
2006-009
4 Lower Base
319
319
319
319
314
314
312
313
325
325
323
323
320
321
309
302
311
311
307
306
See Fig C1-5
Key No.401
316
305-04
305-03
305-02
305-01
324
304-02
304-01
304
304-04
304-03
305
315
303-05
303-07
303-08
303-06
303-07
303-08
303-09
303-07
303-10
303-03
303-04
303-11
303-02
303-01
303-12
304-13
303-14
303-15
303-16
303-19
321
322
310
318
303
308
