– 43 –
ELECTRICAL SECTION 2
2006-009
No.
Part No.
Part Name Qty. Detail
Yamaha Hitachi
101 KYB-M6536-00 1010BA3N XY_PLATE 1
102 KYB-M650L-00 1010BA3P BRACKET XY 1
103 KYB-M652Y-00 1010BA1D UNIT-DRIVER 1
104 KYB-M6565-00 0914B32J UNIT-DRIVER 2
105 90990-11J022 221DA055 SCREW,PAN HEAD WW 8 PAN M5L12 SW+FW
106 KYB-M6579-00 1010BA0K EARTHBAR 1
107 90990-11J018 221DA052 SCREW,PAN HEAD WW 2 PAN M4L10 SW+FW
108 90990-11J016 221DA053 SCREW,PAN HEAD WW 6 PAN M4L6 SW+FW
109 91312-04008 221AA016 BOLT,HEX.SOCKET HEAD 4
110 92902-04200 221HA104 WASHER,PLAIN 4
111 KYB-M658X-00 6P450074 EARTH-MARK-SEAL 1
123 KYX-M653N-00 HNS,X-MOTOR-B 1
124 KYX-M653P-00 HNS,Y1-MOTOR-B 1
125 KYX-M653T-00 HNS,Y2-MOTOR-B 1
126 KYB-M654F-00 1010BC70 HNS,XY-ENC-B 1
135 KYB-M658H-00 23N30590 ACCESS-WIRING 3
