KGT_5_4.pdf
4 5 Head Spare Head KGT -1 107 18 37 19,20 2 BLACK GRA Y bit type non bit type 1 18 19, 20 27 26 28 24 24 24 24 24 30 22 21 26 27 29 23 25 23 25 31 31 23 2 7 5 1 1 1 1 15 13 16 14 12 10 6 4 3 9 9 8 8 36 32 STD. Shaft 1, …
4
5
Head Spare
Head
KGT-1107
18
37
19,20
2
BLACK
GRAY
bit type
non bit type
1
18
19, 20
27
26
28
24
24
24
24
24
30
22
21
26
27
29
23
25
23
25
31
31
23
2
7
5
11
11
15
13
16
14
12
10
6
4
3
9
9
8
8
36
32
STD. Shaft 1, 2
EJECTOR
VALVE
FNC Shaft
33
11
34, 35
17
No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati.
1
KGB-M7163-A0X EJECTOR 1 non bit type(YG200)
KGB-M71G2-00X EJECTOR 1 bit type(YG200)
KGS-M7171-A0X EJECTOR 1 non bit type(YG200-Blow)
KHW-M71G2-00X EJECTOR 1 bit type(YG200-Blow)
2 KM1-M7163-20X VALVE 1
3 KGT-M7163-L0X END BLOCK L 1
4 KGT-M7163-R0X END BLOCK R 1
5 KM5-M7174-C1X EJECTOR BASE 1
6 KM5-M7174-J0X AIR JOINT 1
7 KGT-M7163-B0X JOINT BAR 1
8 KM5-M7174-Y0X BOLT H. S. H 1
9 KM5-M7174-V1X BOLT H. S. H 1
10 90200-10J030 O-RING 1
11 90990-17J009 O-RING 1
12 KM0-M3416-00X GASKET 1
13 KM5-M7174-G0X FILTER CAP 1
14 K46-M8527-C0X FILTER (SZ65111) 1
15 KM5-M7174-H0X SPACER 1
16 90990-17J010 O-RING 1
17 KGB-M7163-B0X EJECTOR ,SPARE 1 Blow specications are excluded
18 KM1-M7163-30X VALVE 1
19 KM5-M7174-70X PACKING SET 1 1 H1, 6
20 KM5-M7174-80X PACKING SET 2 1 H2-5
21 KV8-M7162-10X VALVE 1
22 KV8-M7162-20X VALVE 1
23 90990-17J012 O-RING 1
24 90990-17J011 O-RING 1
25 KGT-M7162-B0X JOINT BAR 1
26 KM5-M7188-Y0X BOLT H. S. H 1
27 KM5-M7188-X0X BOLT H. S. H 1
28 KM5-M7188-L1X END BLOCK L 1
29 KM5-M7188-R1X END BLOCK R 1
30 KM5-M7188-C1X VALVE BASE 1
31 KM5-M7188-G0X NUT HEXAGON 1
32 KGT-M712S-A1X STD. SHAFT 1, SPARE 1
33 KGT-M713S-A1X STD. SHAFT 2, SPARE 1 Normal
34 KGT-M711S-B0X FNC SHAFT, SPARE 1 FNC Circle Nozle
35 KGT-M711S-A0X FNC SHAFT, SPARE 1 FNC S.T.D Nozzle
36 KGT-M71S0-00X HOLDER INDEX SPARE 1 1 FNC
37 KHW-M71G4-00X BIT 1
