2 Assembly Instructions: Component Sensor (Option) for RV12-DLM1 Placement Head SIPLACE S-25 HM
2.6 Work Sequence 04/2007 Edition
44
2.6.7 Activating the Optional Component Sensor and Trial Placement
DANGER
There is a higher risk of accident when working with the SITEST program.
The SITEST program is only to be started by personnel who have been trained in its use at Sie-
mens Dematic AG and are therefore authorized to do so.
The component changeover tables (mobile changeover tables on S-25 HM / HS-50) must ALL be
moved into the machine, properly docked, and completely equipped. 2
NOTE:
The component sensor has a control LED that is visible from the operator’s side (see Abb. 2.6.3)
The display function is as follows:
-LED lit: The Sensor is ready for operation AND the beam of the sensor ist not interrupted.
-LED does not light up: The light beam ist covered (interrupted) >
50 %.
The "Component sensor" button is always active in SITEST, even if the sensor has been deacti-
vated under Hardware Options. 2
: Use the "Manual for the Placement of 0201 Components" (Item no.: see Abschn. 2.5.4) and
perform all of the work steps described there.
In brief:
– Create the prerequisites for placement (0201, 0402,...) at the station.
– Perform all work steps in the SITEST program.
– Perform all works steps at the line computer. These include activating the optional compo-
nent sensor for the assembling gantry and configuring the component sensor.
– Check the function of the component sensor at the station; measure components (0201,
0402,...) with the component sensor and place them.
