CM602-L 2006.0515
- 17 -
■
Nozzle for Connector (2/3)
∗
The product number should be used for order placements. (Unit: mm)
Nozzle No. 1173 1180 1191
Product number
KXFX04T0A00 KXFX04TGA00 KXFX04U4A00
Nozzle unit
shape
(Unit: mm)
Max. component
height
21 mm 21 mm 21 mm
Remarks Nozzle length: 22.5 mm Nozzle length: 22.5 mm Nozzle length: 22.5 mm
Nozzle No. 1192 1202 1229
Product number
KXFX04U6A00 KXFX04UQA00 KXFX04W6A00
Nozzle unit
shape
(Unit: mm)
Max. component
height
21 mm 18.5 mm 16 mm
Remarks Nozzle length: 22.5 mm Nozzle length: 27.5 mm Nozzle length: 32.5 mm
Nozzle No. 1237 1248 1249
Product number
KXFX04WNA00 KXFX04X8A00 KXFX04XAA00
Nozzle unit
shape
(Unit: mm)
Max. component
height
21 mm 21 mm 18.5 mm
Remarks Nozzle length: 22.5 mm Nozzle length: 22.5 mm Nozzle length: 27.5 mm
φ
14
12
3
7
5
1.
5
φ
7.4
5.8
1.4
1
φ
9
0
.
8
2
3.5 0.4
8
φ
4
3.3
1.4
1
φ
7.4
5.8
1.4
1
11.6
0.8
φ
15
1.
5
4.5
3
φ
10
4.5
2.8
7.5
φ
7
1.
5
3
4.5
5
0.8
φ
15
1.4
4.5
3
13
1
CM602-L 2006.0515
- 18 -
■
Nozzle for Connector (3/3)
∗
The product number should be used for order placements. (Unit: mm)
Nozzle No. 1252 1272 1333
Product number
KXFX04XEA00 KXFX04YKA00 KXFX051JA00
Nozzle unit
shape
(Unit: mm)
Max. component
height
18.5 mm 21 mm 18.5 mm
Remarks Nozzle length: 27.5 mm Nozzle length: 22.5 mm Nozzle length: 27.5 mm
Nozzle No. 1404 1421 1528
Product number
KXFX0558A00 KXFX056AA00 KXFX05GZA00
Nozzle unit
shape
(Unit: mm)
Max. component
height
21 mm 21 mm 18.5 mm
Remarks
With a urethane rubber
Nozzle length: 22.5 mm
With a urethane rubber
Nozzle length: 22.5 mm
Nozzle length: 27.5 mm
Nozzle No. 1656 2405 2437
Product number
KXFX05MXA00 KXFX05BVA00 KXFX05DRA00
Nozzle unit
shape
(Unit: mm)
Max. component
height
21 mm 21 mm 21 mm
Remarks Nozzle length: 22.5 mm
With a urethane rubber
Nozzle length: 22.5 mm
With a urethane rubber
Nozzle length: 22.5 mm
φ
6
4
1.4
1
φ
2.7
2.1
1.2
0.6
φ
20
18
1
1.
8
4.5
3
Urethane
rubber
φ
10
8
2
4
φ
1.2
φ
1.6
φ
3
4.5
φ
12
11
1.8
1
Urethane
rubber
φ
5
1
2
3
Urethane
rubber
5
1.4
3
φ
7
Urethane rubber
φ
20
18
1.5
3
CM602-L 2006.0515
- 19 -
■
Nozzle for chip components / QFP
∗
The product number should be used for order placements. (Unit: mm)
Nozzle No. 1403 1479 1514
Product number
KXFX0556A00 KXFX05ASA00 KXFX05G9A00
Nozzle unit
shape
(Unit: mm)
Target
component
QFP QFP Volume
Max. component
height
21 mm 18.5 mm 21 mm
Remarks
With a urethane pad
Nozzle length: 22.5 mm
With a urethane rubber
Nozzle length: 27.5 mm
Nozzle length: 22.5 mm
Nozzle No. 1518 1580 1604
Product number
KXFX05GHA00 KXFX05KRA00 KXFX05L9A00
Nozzle unit
shape
(Unit: mm)
Target
component
Terminal LED
Melf
Φ
2.2
∼
Φ
2.5
Max. component
height
21 mm 21 mm 21 mm
Remarks Nozzle length: 22.5 mm Nozzle length: 22.5 mm Nozzle length: 22.5 mm
■
Correspondence between the pickup depth of electronic component and the nozzle length
The necessary nozzle length varies according to the pickup depth (distance from top of embossed tape to
pickup surface) of electronic component to be placed.
Pickup
depth B
0 mm
to below 3 mm
3 mm
to below 8 mm
8 mm
to below 13 mm
Nozzle
length A
22.5 mm 27.5 mm 32.5 mm
Pad
φ
6
φ
6
Urethane
rubber
φ
5
φ
3
φ
1.2
φ
2.5
φ
2
φ
2.5
φ
3
3.1
φ
0.9
φ
1.2
R1.25
φ
1.6
φ
2.2
φ
3
Emboss tape
Component
Nozzle
length A
Pickup
depth B
