Brief Description
Reconfiguration Kit CPP SX1/2 [00519983-xx] Scope of Delivery
Assembly Instructions / Montageanleitung Head Reconfiguration Kit CPP 47
Brief Description
2 Brief Description
Scope of Delivery
2.1 Scope of Delivery
▪ Reconfiguration Kit CPP, SX1/2 [00519983-xx]
▪ Placement head CPP without camera [03053528-xx]
▪ Depending on customer request:
Component camera C&P (type 29) 27x27 digital RK [03018637] or
01005 camera for CPP head [00119783-xx]
▪ When exchanging a TwinHead by a CPP head:
Additional parts set for TwinHead to CPx
Reconfig uration Kit CPP SX1/2 [00519983-xx]
2.1.1 Reconfiguration Kit CPP SX1/2 [00519983-xx]
Additional Parts Set TwinHead t o CPx
NOTICE
The camera type is added during the configuration query of the head reconfiguration kit.
The C&P component camera (type 29) 27x27 digital RK [03018637-xx] is the default.
1 x 00196430-xx Assembly Instr. Head Reconf.Kit CPP, SX 1/2
1 x 03053528-xx CPP placement head without camera
1 x 03083927-xx
includes
Parts set CP20 to CPP
3 x 03066107-xx Nozzle magazine type 20xx
1 x 03065782-xx Nozzle magazine type 28xx
2 x 03063238-xx Bin left
1 x 03065971-xx Cable set CPP / B series
2 x 00201583-xx DIN 125-A 2.7-140HV-A2
2 x 03042531-xx ISO 4762 - M 2.5 x 4-A2-70
8 x 03042541-xx ISO4762-M3x6-A2-70
2 x 03069093-xx ISO 4762 - M 3 x 50-8.8, zinc, TFP
1 x 03077179-xx
includes
Hose system FHE / CPP SX1/2
2 x 03077181-xx Air hose FHE / CPP SX1/2
2 x 00330249-xx Plug QSC-4H
1 x 03015210-xx Plug QSC-12H
1 x 03006728-xx Cover cap D Di8,0 H15 soft PVC
2 x 03079581-xx
includes
Downholder left cplt, SX1/2
1 x 03079173-xx Downholder left, SX1/2
2 x 00313069-xx DIN912-M4 x 10-A2-70
2 x 03042552-xx ISO 4762 - M 4 x 10-A2-70
Brief Description
Scope of Delivery Options for CPP
48 Assembly Instructions / Montageanleitung Head Reconfiguration Kit CPP
2.1.2 Additional Parts Set TwinHead to CPx
Options for CPP
2.1.3 Options for CPP
1 x 03055516-xx PCB / B-Base adapter C+P
8 x 03042541-xx ISO4762-M3x6-A2-70
2 x 03069093-xx ISO 4762 - M 3 x 50-8.8, zinc, TFP
1 x 03048638-xx Bin
4 x 03062378-xx Component reject bin up to 6x6 f. P001
1 x 03073328-xx Nozzle station CPx cplt. / X, B Series
3 x 030395514-xx Shim plate for nozzle reject device
1 x
includes:
03051467-xx Piping of nozzle station / with valve
1 x 03055785-xx Valve for nozzle station cplt.
2 x 00350291-xx DIN912-M2.5 x 16-A2-70
1 x 03055792-xx Press-fit connection with push-on socket QSY-6H-4
1 x 00330249-xx Plug QSC-4H
1 x 03056097-xx PUN-CM 4x0.75 / 135mm
1 x 03056096-xx PUN-CM 4x0.75 / 200mm
00519841-xx Nozzle changer CPP SX1/2
00519842-xx Nozzle changer CPP SX1/2 (Pos.3o.4)
00519902-xx Stationary camera for CPP head, SX1/2
00519848-xx Verify reject bin, SX1/2
03071171-xx Starter kit for maintenance CPx and TwinHead
03076791-xx Service box nozzle 20-Segm. CPP Head
Brief Description
Options for CPP Tools and Equipment Required
Assembly Instructions / Montageanleitung Head Reconfiguration Kit CPP 49
Tools and Equipment Required
2.2 Tools and Equipment Required
Designation Item No.
Torque wrench 03078400-xx (old version: 00376504-xx)
Extension with joint (170 x SK3) 03042635-xx
Extension straight (170 x SK3) 03043440-xx
Tool extension straight TX20 03073256-xx
Bit holder for TorqueVario screwdriver 03078706-xx
Depth measuring gauge 200 mm 03079617-xx
Pressure test device with measurement cable 00313523-xx
Conversion kit COT insert X 00378465-xx
Mapping Plate SX 560x460 Set
or
Alu Mapping Plate 560 x 460 D, SX1/2
03076118-xx
03076765-xx
Calibration tool version 3 CPP 03010565-xx
Calibration tool version SST23 C&P20 03034148-xx
Assembly Instructions Stationary Camera SX Series 00196608-xx
Assem Assembly Intructions SIPLACE SX 1/2 Noz
-
zle Changer
00196578-xx
Assembly Instructions Reject Bin SIPLACE SX Se
-
ries
00196615-xx
Assembly Instructions Stationary Camera Type 25
SIPLACE X Series, SX1/2, D3 and D1
00194554-xx
Service Manual SX1/2 00196496-xx
