Installing the CPP Placement Head
Final Work Option Verify Reject Bin
76 Assembly Instructions / Montageanleitung Head Reconfiguration Kit CPP
Option Verify Reject Bin
3.5.2 Option Verify Reject Bin
► For installing and removing the option Verify component reject bin please refer to the Assembly In
-
structions "Reject Bin SX1/2" [00196615-xx].
Option Stationary Camera
3.5.3 Option Stationary Camera
► For installing and removing the option Stationary Camera please refer to the Assembly Instructions
"Stationary Camera SIPLACE SX" [00196608-xx] or "Stationary Camera Type 25 SIPLACE X Se
-
ries, SX1/SX2, D3 and D1 [00194554-xx].
Final Work
3.6 Final Work
► Switch the placement machine on at the main switch.
The head exchange will be indicated after the startup of the machine.
► Confirm the new configuration.
► Check the firmware version for the placement head and the HCU and perform a download, if needed.
► Apply the data (zero point correction star and Z axis) from the placement head.
► If the placement head is installed on a machine for the first time, it does not contain any calibration
data.
► Calibrate the placement head.
If the placement head has already been used on another machine, you can use the calibration data
from the memory of the placement head.
► Measure the nozzle changers and, if necessary, the stationary camera.
► Perform the mapping procedure if necessary.
► Perform another restart.
The conversion is completed with that.
NOTICE
The CPP head can only be used with stationary cameras of function status -04 or higher.
NOTICE
Two "DIN 913 - M 6 x 50-ST" [03005958-xx] screws for securing the mark caul before removing
the camera are included in the parts set.
NOTICE
If a stationary camera is retrofitted, the COT insert must be loosened and moved outwards.
Read the applicable service manual for this. After completion of work, this needs to be fixed into
place again and all attached parts (nozzle changer) must be remeasured.
