KGC-YV100XTg_PL - 第33页
1 8 Multi Camera & Light Assy. Camera KGC-1 107 5 1 4 3 4 3 2 No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati. 1 KGA-M73C0-31X C+L FOV35-H266-F-U/D 1 Front KGC-M73C0-32X C+L FOV35-H266-R-U…
10
7
Moving Conveyor 2
Conveyor
KGC-081014
40
15
26
41
45
29
40
18
31
35
35
43
23
16
34
29
25
41
44
31
28
43
4
3
32
33
14
34
25
27
17
2
7
8
4
20
5
35
19
5
12
11
13
9
2
21
29
24
21
25
26
29
31
1
25
27
3
30
39
4
30
30
36
43
39
39
35
35
10
6
31
37
42
31
6
6
5
5
3
38
21
24
23
22
28
22
23
OLD
No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati.
1 KV1-M9131-01X BASE,CONVEYOR 1
1-1 KV1-M9131-02X BASE,CONVEYOR 1 (2003/4/9) M340020 OK
2 KV1-M9132-00X BALL, SCREW M-CONV 2
3 90933-01J200 BEARING 3
4 KV1-M9136-00X COVER, BEARING 3
5 KH2-M9105-11X PULLEY, MOTOR 4 P30-3GT
6 KV1-M9137-00X WASHER 3 M4 13D 2T
6-1 90990-28J070 WASHER,PLAIN 3 (2007/12/18) MDX0125 OK
7 90K55-4W476W AC SERVO MOTOR 1
8 KV1-M9138-00X BRKT., MOTOR W 1
9 KG7-M9113-01X PULLEY 3 1
10 KV1-M913K-00X BELT, W AXIS 1
11 KV1-M913A-00X BRKT., TENSION 1
12 90933-03J608 BEARING 2
13 KV7-M9149-00X COLLAR,BRG. 1
13-1 90990-41J057 COLLAR 1 (2008/4/17) ME20197 OK
14 KV1-M913B-00X SPLINE 1
15 KV1-M913C-00X PULLEY, MOTOR 1
16 KV1-M9135-00X PULLEY 1, SPLINE 1
17 KG2-M9108-11X COLLAR, CONVEYOR 1
18 KV1-M913E-00X BELT 1 315-3GT-9
19 KV1-M4886-00X MOTOR ASSY 6-1 1
20 KV1-M913F-00X BRKT., MOTOR CONV. 1
21 KH2-M9121-00X BEARING 3
22 KGF-M179S-00X SHAFT, SPCON 2 L=101
22-1 KV1-M914A-10X SHAFT, SPCON 2 L=80 (2003/9/30) M390120 Set
23 KV1-M914B-00X BRKT., SPCON 2
23-1 KV1-M914B-10X BRAKET SPCON 2 (2003/9/30) M390120 Set
24 $SSU4 SPEED CONTROLLER 8
24-1 $SSU4 SPEED CONTROLLER 6 (2003/9/30) M390120 OK
25 KV1-M914C-01X STOPPER, DAMPER 4
26 KV1-M914D-00X SPACER, DAMPER 2
27 91317-03010 BOLT HEX. SOCKET HEAD 10
28 95304-03600 NUT,HEXAGON 4
28-1 95302-03600 NUT HEXAGON 4 (2006/1/16) MBY0167 OK
29 98907-04008 SCREW BINDING HEAD 8
30 91317-04006 BOLT HEX. SOCKET HEAD 6
31 91317-04008 BOLT HEX. SOCKET HEAD 23
32 91317-04012 BOLT HEX. SOCKET HEAD 1
33 91317-04016 BOLT HEX. SOCKET HEAD 24
34 91317-04030 BOLT HEX. SOCKET HEAD 12
35 92A08-04006 SET SCREW 12 M4X6
35-1 92A08-04306 SET SCREW 12 M4X6 (2001/12/13) M1Y0048 OK
36 91317-05010 BOLT HEX. SOCKET HEAD 8
37 91317-05020 BOLT HEX. SOCKET HEAD 20
38 91317-05050 BOLT HEX. SOCKET HEAD 4
39 92903-05200 WASHER PLAIN 8
40 91317-06010 BOLT HEX. SOCKET HEAD 4
41 91317-06016 BOLT HEX. SOCKET HEAD 8
42 KV1-M914G-00X NUT,SQUARE 4
42-1 KV1-M914G-00X NUT,SQUARE 2 (2005/6/21) MB60107 OK
43 KG7-M9110-01X COLLAR W 3
43-1 90990-41J006 COLLAR 3 (2008/4/15) ME20075 OK
44 KV1-M913M-01X GUIDE HARNESS 1
45 KV1-M913P-10X BRKT. HARNESS 1
1
8
Multi Camera & Light Assy.
Camera
KGC-1107
5
1
4
3
4
3
2
No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati.
1
KGA-M73C0-31X C+L FOV35-H266-F-U/D 1 Front
KGC-M73C0-32X C+L FOV35-H266-R-U/D 1 Rear
2 KV7-M652G-00X SENSOR,CYLINDER 1
3 91317-06020 BOLT HEX. SOCKET HEAD 4
4 92907-06200 WASHER, PLAIN 4
5 KGA-M66F0-01X C. CABLE ASSY 1
1
9
MAin Box
Controller
KGC-090312
2
18
3
3
5
8
9
14
15
6
10
13
10
11
10
12
1
7
16
19
17
OLD
4
17
No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati.
1 KGA-M4110-00X BOX ASSY. C/R 1
2 KGA-M4510-00X MOTHER BOARD ASSY. 1
3 KM5-M5840-03X SERVO BOARD ASSY 2
3-1 KM5-M5840-04X SERVO BOARD ASSY 2 2002/5/9 M100113 OK
4
KW3-M4209-00X SYSTEM UNIT ASSY. 1 S.T.D (2003/9/24) M390061
KW3-M4209-10X SYSTEM UNIT ASSY. 1 IT OPTION without CLI FEEDER (2003/9/24) M390061
KW3-M4209-21X SYSTEM UNIT ASSY. 1 IT OPTION with CLI FEEDER (2004/2/10) M420003
4-1
KW3-M4209-30X SYSTEM UNIT ASSY. 1 IT OPTION without CLI FEEDER 2007/6/6 MD30054 NG
KW3-M4209-40X SYSTEM UNIT ASSY. 1 IT OPTION with CLI FEEDER (2007/3/22) MD30054 NG
4-2
KW3-M4209-31X SYSTEM UNIT ASSY 1 IT OPTION without CLI FEEDER (2008/5/26) ME50031 OK
KW3-M4209-40X SYSTEM UNIT ASSY. 1 IT OPTION with CLI FEEDER
5 KJ0-M5810-E4X DRIVER BOARD ASSY. 1 (1B)
5-1 KJ0-M5810-E5X DRIVER BOARD ASSY. 1 H010235 (2007/1/12) MCY0115 Set
6 KJ0-M5810-K4X DRIVER BOARD ASSY. 1 (1A)
6-1 KJ0-M5810-K5X DRIVER BOARD ASSY. 1 H010235 (2007/1/12) MCY0115 Set
7 KM5-M5882-11X D.POWER BOARD ASSY. 1
8 KJ0-M4134-10X PANEL NO SERVO 1
9 KJ0-M4132-10X PANEL, NO DRIVER 1
10 KGA-M4185-10X FAN MOTOR ASSY. 3
11 KGA-M5303-00X SW POWER DC5 1 PAA150F-5
11-1 KGS-M5303-00X SW POWER DC5 1 PBA150F-5 2007/6/20 MCY0159 NG
12 KW7-M5303-10X SW POWER DC12 1 PAA150F-12
12-1 KGS-M5303-10X SW POWER DC12 1 PBA150F-12 2007/6/20 MCY0159 NG
13 KGA-M53E2-00X TRANS 1 ASSY. KGA 1
14 KV1-M441H-17X VISION UNIT ASSY. 1
14-1 KV1-M441H-187X VISION UNIT ASSY. 1 (2009/3/9) MF30012 OK
15 KW3-M4220-10X APPL BOARD ASSY 1
15-1
KW3-M4220-11X APPL BOARD ASSY 1 *OK : after VGOS V1.21 R1.000 (2008/4/11) ME30249 *NG
16 KGA-M4136-10X PANEL, NO VISION 1
17 KW3-M4255-00X FLASH DISK 1
17-1 KGN-M4255-00X FLASH DISK 1 256MB W/ ADAPTER 2003/6/27 M230020 OK
17-2 KGN-M4255-20X FLASH DISK 1 256MB W/O ADAPTER (2003/11/13) M3X0032 NG
18 KW3-M4256-00X CD-ROM DRIVE 1
17 KW3-M4255-00X FLASH DISK 1
17-1 KGN-M4255-00X FLASH DISK 1 With ADAPTER 2003/6/7 M230020 OK
17-2 KGN-M4255-20X FLASH DISK 1 Without ADAPTER (2003/11/13) M3X0032 NG
18 KW3-M4256-00X CD-ROM DRIVE 1
19 KW3-M4230-00X FLASH BOARD ASSY 1
19-1 KGN-M4230-00X FLASH BOARD ASSY 1 (2003/11/13) M3X0032
19-2 Delete (2007/3/27) MD30054
