S A MS U N G T E C H W I N TH-VIS-01 CN2 DOWN CAMERA FLSO J1 15V CN3 TH-HD-03-01 CN3 I/F#1 CN4 TH-HD-03-01 CN5 SMPS CN2 LASS󰚟II CTRL󰚟. DC󰚟PWR RT󰚟PC PCI󰚟Slot TH-VIS-01 CN5 I/F#2 J5 HEAD CN4 X1CP MIB󰚟#2 RLSO #1 FLSO …

100%1 / 111
NO. PART󰚟NO. PART󰚟NAME Q'TY TYPE REMARK
55 J9075456B INLET󰚟WIDTH󰚟SERVO󰚟MOTOR󰚟ASS'Y HP-TSV-05-2
56 J9075457B FRONT󰚟WORK󰚟WIDTH󰚟SERVO󰚟MOTOR󰚟ASS'Y HP-TSV-05-3
57 J9075458B REAR󰚟WORK󰚟WIDTH󰚟SERVO󰚟MOTOR󰚟ASS'Y HP-TSV-05-4
58 J9075459B OUTLET󰚟WIDTH󰚟SERVO󰚟MOTOR󰚟ASS'Y HP-TSV-05-5
59 J9075474D OUTLET󰚟WIDTH󰚟MOTOR󰚟POWER󰚟EXT󰚟CABLE󰚟B HP-TSV-06-52
60 J9075476C OUTLET󰚟WIDTH󰚟MOTOR󰚟ENCODER󰚟EXT󰚟CABLE󰚟B HP-TSV-06-54
61 J9075473B OUTLET󰚟WIDTH󰚟MOTOR󰚟POWER󰚟EXT󰚟CABLE󰚟A HP-TSV-06-51
62 J9075475A OUTLET󰚟WIDTH󰚟MOTOR󰚟ENCODER󰚟EXT󰚟CABLE󰚟A HP-TSV-06-53
63 J9075460A OUTLET󰚟SHUTTLE󰚟SERVO󰚟MOTOR󰚟ASS'Y HP-TSV-05-6
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
S AMS UNG TE CHWIN
TH-VIS-01
CN2
DOWN
CAMERA
FLSO
J1
15V
CN3
TH-HD-03-01
CN3
I/F#1
CN4
TH-HD-03-01
CN5
SMPS
CN2
LASS󰚟II
CTRL󰚟.
DC󰚟PWR
RT󰚟PC
PCI󰚟Slot
TH-VIS-01
CN5
I/F#2
J5
HEAD
CN4
X1CP
MIB󰚟#2
RLSO
#1
FLSO
FLSO
DIS󰚟B/D
J1
#2
CN4
FRONT
ILL󰚟B/D
CN4
CN2
SM310-VIS-03-2
AC220V
HP-TH-PS-0B-3
CS-PCI5
#3
HP-TH-MIB-0D-2
(+15V/-15V/24V)
HP-TH-VIS-08-01
#3
RLSO
GUI󰚟PC
PCI󰚟Slot
HP-TH-HD-05-11
SM310-VIS-01-3
PWR
REAR
ILL
B/D
PWR
HP-TH-VIS-10-01
X2CP
CN3
PXC200AF
SM310-VIS-04-1
#2
RLSO
CN4
SM310-VIS-04
HP-TH-HD-05-22
DOWN
CAMERA
MIB󰚟#1
HP-TH-VIS-02
HP-TH-HD-05-21
#1
CN3
HEAD
SM310-VIS-03-1
#1
#2
CS-PCI5
SM310-TRIG-01
CN1 CN2
HP-TH-HD-05-12
CN1
P4
P4
J6
SM310-TRIG-02
NO. PART󰚟NO. PART󰚟NAME Q'TY TYPE REMARK
1 J9083127B DOWN󰚟CAMERA󰚟CABLE SM310-VIS-01
2 J9080339A HEAD󰚟ILLUMINATOR󰚟CABLE󰚟#31 CP60HP-TH-HD-03-01
3 J9083006B CAMERA󰚟CABLE󰚟#3 SM310-VIS-01-3
4 J9080955D FRONT󰚟LSO󰚟SIGNAL󰚟CABLE SM310-VIS-04
5 J9080956C REAR󰚟LSO󰚟SIGNAL󰚟CABLE SM310-VIS-04-1
6 J90800411F LSO󰚟CAMERA󰚟POWER󰚟CABLE󰚟#1 CP60HP-TH-VIS-02
7 J9080957C LSO󰚟CAMERA󰚟POWER󰚟CABLE󰚟(FRONT) SM310-VIS-03-1
8 J90800958D LSO󰚟CAMERA󰚟POWER󰚟CABLE󰚟(REAR) SM310-VIS-03-2
9 J9083011B FRONT󰚟TRIGGER󰚟IF󰚟CABLE SM310-TRIG-01
10 J9083012B REAR󰚟TRIGGER󰚟IF󰚟CABLE SM310-TRIG-02
11 J9083104A LSO󰚟FRONT󰚟ILL󰚟CABLE󰚟#1 SM310-VIS-08-01
12 J9083105A LSO󰚟REAR󰚟ILL󰚟CABLE󰚟#1 SM310-VIS-10-01
13 J90800531C ILLUMINATOR󰚟POWER󰚟CABLE CP60HP-TH-MIB-0D-2
14 J90800541C HEAD󰚟ILLUMINATOR󰚟CABLE󰚟#22 CP60HP-TH-HD-05-22
15 J90800540C HEAD󰚟ILLUMINATOR󰚟CABLE󰚟#21 CP60HP-TH-HD-05-21
16 J9080636B HEAD󰚟ILLUMINATOR󰚟CABLE󰚟#11 CP60HP-TH-HD-05-11
17 J9080637C HEAD󰚟ILLUMINATOR󰚟CABLE󰚟#12 CP63HP-TH-HD-05-12
18 J90800519E 15V󰚟P/S󰚟AC󰚟POWER󰚟CABLE CP60HP-TH-PS-0B-3
