NO. PART󰚟NO. PART󰚟NAME Q'TY TYPE REMARK
1 J9060352A FEEDER󰚟BASE󰚟RIGHT󰚟COVER󰚟PCB,󰚟NON󰚟DOCKING 1 REV󰚟1.0
2 J9060351A FEEDER󰚟BASE󰚟LEFT󰚟COVER󰚟PCB,󰚟NON󰚟DOCKING 1 REV󰚟1.0
3 J1301188 FITTING 2
4 J6711245A COUPLER 60
5 J6001503050 SOCKET󰚟HEAD󰚟CAP󰚟SCREW 13
6 J7057213A SIDE󰚟CABLE󰚟COVER-FB 2 J7057213A
S AMS UNG TE CHWIN
2
3
3-A
3-A
3-B
1
4
3-B
3-C
NO. PART󰚟NO. PART󰚟NAME Q'TY TYPE REMARK
1 J7159182A BLOCK-LSO󰚟FID󰚟 1 J7159182A
2 J9076004D CAMERA󰚟LSO403 1 J9076004D
3 J9059187A LSO403󰚟ILLUMINATOR󰚟ASSY 1 J9059187A
2-A J7259049A CLAMP-COVER-GLASS-1 2 J7259049A
2-B J7259050A CLAMP-COVER-GLASS-2 2 J7259050A
2-C J7459008C COVER_GLASS 1 J7459008C
4 J9059174C LINE󰚟CCD󰚟CAMERA 3
J9059175A LENS󰚟ASSY(LSO403) 3 J9059175A
J7159373A CAMERA󰚟HOLDER 1 J7159373A
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
