NO. PART󰚟NO. PART󰚟NAME Q'TY TYPE REMARK 1 J1301268 HOLE󰚟FIXER󰚟SENSOR󰚟 4 2 J66070079B LM_GUIDE 1 3 J7054022B CLAMP-MOTOR󰚟BRACKET󰚟 2 J7054022B 4 J7054068E SENSOR󰚟DOG-Y󰚟R.H. 1 J7054068E 5 J7054069C SENSOR󰚟DOG…

100%1 / 111
S AMS UNG TE CHWIN
5
9
2
7
16
5
4
3
8
9
3
1
1
17
14
13
11
10
12
10
NO. PART󰚟NO. PART󰚟NAME Q'TY TYPE REMARK
1 J1301268 HOLE󰚟FIXER󰚟SENSOR󰚟 4
2 J66070079B LM_GUIDE 1
3 J7054022B CLAMP-MOTOR󰚟BRACKET󰚟 2 J7054022B
4 J7054068E SENSOR󰚟DOG-Y󰚟R.H. 1 J7054068E
5 J7054069C SENSOR󰚟DOG-Y󰚟L.H. 1 J7054069C
6 J7054265B SIDE󰚟FRAME󰚟LEFT 1 J7054265B
7 J7154146E CARRIER-Y󰚟RL 1 J7154146E
8 J7154148D CARRIER-Y󰚟FL 1 J7154148D
9 J7054120D COVER-MOTOR󰚟BRACKET 2 J7054120D
󰚟10 J90830143D FEEDER󰚟UNLOCK󰚟SNS󰚟CABLE󰚟#11 1 SM310-MIB-02-31
J90830144D FEEDER󰚟UNLOCK󰚟SNS󰚟CABLE󰚟#21 1 SM310-MIB-02-41
11 J70540293C BKT󰚟FLOAT󰚟L 1 J70540293C
12 J70540294C BKT󰚟FLOAT󰚟R 1 J70540294C
13 J7054284A COVER-SENSOR-F 1 J7054284A
14 J7054285A COVER-SENSOR-R 1 J7054285A
15 J1300093 PHOTO󰚟SENSOR󰚟 1
16 J7054286B COLLISION󰚟FLAG-LH 1 J7054286B
17 J7052523B STAY-INNER󰚟COVER 6 J7052523B
18
19
20
21
22
23
24
25
26
S AMS UNG TE CHWIN
5
9
7
8
9
4
2
3
3
1
1
15
10
11
10
12
14
13
