DECAN_S1_TRM(Ver1.2_CS19.11) - 第51页
Page +$1:+$ 49 DE CA N S 1
Page
+$1:+$
48
DECAN
S1
Base Frame (Front)
NO. PART NO. PART NAME Q'TY Old No. Supply Supply LT Reference
34 HP06-900046 JOINT 1
35 HP06-001070 FITTING 1
36 HP06-000234 FITTING 1
37 HP13-900086 AIR TUBE(POLYYRETHANE)[U2-4-6*4(YELLOW)] 0.32
38 J91741042A AXIS_SENSOR_BOARD_ASSY VER1.0 1
39 AM03-027373A CABLE ASSY-D-S1_MAIN_SW_TRANS 1
40 EP06-002955A POWER_SUPPLY 6
41 FC09-009435A BRACKET-FRONT_ELEC_PANEL 1
42 FC09-003509A FRONT CABLE BKT 1
43 EP07-901339 CONTACTOR 1
44 EP07-901345 DEVICES,SAFETY 1
45 RM01-000080 RAIL-DIN RAIL 35MM 1
46 EP21-900002 STOPPER 2
47 FC09-003446A RIGHT DC BKT 1
48 J71520028E GROUND BASE(2) 1
49 FC09-004599A OUTLET FAN BKT 2 FC09-003435A
50 FC09-003430A BKT NOISE FILTER 1
51 AM03-011573B ASSY,ELECTRIC-NOISE_FILTER_MODULE 1
52 EP23-001003A TRANSFORMER 1
53 FC09-003483A BKT SIDE COVER 2
55 EP07-901528 FAN FILTER 2
61 FC09-003480A BOTTOM FL 1
62 FC09-003475A BOTTOM FR 1
63 FC09-003436B DUCT HANGER 4 FC09-003436A
64 HP13-900084 AIR TUBE (POLYURETHANE) 2.3
69 HP13-900086 AIR TUBE(POLYYRETHANE)[U2-4-6*4(YELLOW)] 1
70 HP13-900081 AIR TUBE (POLYURETHANE) 1
71 FC09-009611A BRACKET-REAR_FB_REPLACEMENT 1
72 J70571005A FB_REPLACEMENT_POST 6
Page
+$1:+$
49
DECAN
S1
Page
+$1:+$
50
DECAN
S1
Base Frame (Rear)
13
42
50
40
41
17
48
20
31
32
33
56
21
15
43
44
49
29
30
54
55
56
22
51
52
34
56
55
56
16
45
18
68
14
19
57
6
12
23
24
25
8
9
10
3
60
47
7
1
26
27
62
5
28
58
61
59
4
11
2
35
46
63
39
36
