SIPLACE 1 Assembly instructions Special design Stopper for placement area 1 (00166322-01) SIPLACE HF-series
06/2007 Edition
5
1 Assembly instructions
Special design Stopper for
placement area 1 (00166322-01)
SIPLACE HF-series
1.1 Functional description
Installing a mechanical stopper module allows the processing area to be varied as required. The
conveyor firmware special design deactivates the light barrier in the placement area and integra-
tes the stopper module with sonar sensor. 1
1.2 Requirements
Software: SR 505.03 SP1, SIPLACE Pro version 5.0, Conveyor firmware TS 610548.hex 1
Hardware: SIPLACE HF, dual conveyor 1
1.3 Restrictions
To calibrate the conveyor edges, the stopper module has to be removed because the minimum
conveyor width with stopper module is 55mm. 1
The maximum board length is reduced. Depending on the stopper setting it varies from 376mm –
347mm. 1
1.4 Scope of delivery
– Stopper module
– Assembly rail
– Socket screws M5 x 10mm
– Spacers M5 x 10mm
– Cable clips
– Cable ties
– Conveyor firmware (TS 610548.hex)
– Documentation.
1 Assembly instructions Special design Stopper for placement area 1 (00166322-01) SIPLACE HF-series SIPLACE
06/2007 Edition
6
1.5 Required tools
– Set of hexagon socket spanners
– Set of Philips screwdrivers
– Set of fork wrenches
–Side cutter
– Hose pliers.
SIPLACE 1 Assembly instructions Special design Stopper for placement area 1 (00166322-01) SIPLACE HF-series
06/2007 Edition
7
1.6 Safety instructions
WARNING
The safety instructions from the “Operational safety” chapter of the user manual and servicing in-
structions take precedence over these instructions. 1
The SIPLACE placement machines are supplied with mains voltage.
Consequently parts of these systems carry dangerous voltages! This voltage is present at certain
modules inside the machine base, even when the machine is switched off at the main power
switch.
Incorrect handling of the placement machine or touching live parts of the machine can result in
death or severe injury, and considerable damage to equipment.
BEFORE starting any work, shut down the operating system correctly, then switch the machine
OFF at the main power switch and disconnect from the main power supply. In addition, the com-
pressed air supply must be switched off at the compressed air unit's main valve in the machine
base and vented by actuating the needle valve on the compressed air unit.
There is DANGER for heart pacemaker wearers in the vicinity of the linear motors, as described
in detail in the "Special safety instructions for working in the vicinity of strong magnetic fields"
section of the user manual and service manual.
Always follow the accident prevention regulations, DIN or other standards and special safety
rules applicable in your country.
Pay attention to the information concerning residual voltages in the Operational Safety chapter.
Follow the ESD regulations as described in the operational safety section of the operating
instructions.
During the retrofit, always secure the machine to prevent access by other people and to prevent
it being switched on again. The procedure is described in the “Locking the machine…” section of
the user manual.
Working with the SITEST program further increases the risk of accident.
The SITEST program must only be used by authorized and trained personnel.
1
