Settings 5.8.3 Setting the Nozzle Reject and Station Height Other Settings Service Manual SIPLACE SX4/DX4 269 5.8.3 5 . 8 . 3 S e t t in g t h e N o z z le R e je c t a n d S t a t io n H e ig h t Setting the Nozzle Reje…

Settings

Other Settings 5.8.2 Calibration

268 Service Manual SIPLACE SX4/DX4

5.8.2.2

5.8.2.2 Calibration Procedure

Calibration Procedure

C&P calibration procedure

Settings

5.8.3 Setting the Nozzle Reject and Station Height Other Settings

Service Manual SIPLACE SX4/DX4 269

5.8.3

5.8.3 Setting the Nozzle Reject and Station Height

Setting the Nozzle Reject and Station Height

Parts, equipment and tools

▪ Depth measuring gauge (300 mm) [03079617-xx]

▪ Adjusting plates for nozzle reject device [03039514-xx]

▪ Screws DIN 7991-M4 x 20-8.8 [00333782-xx]

▪ Plastic sheet (to keep the depth measuring gauge away from the magnets).

Setting

1. Position upper edge of measuring scale on the linear

guidance.

2. Bottom end of measuring gauge on the assembly sur-

face of the nozzle station

► Push the placement head to be measured outwards.

► Place a plastic plate in front of the magnets.

► Position the measuring gauge on the upper edge of

the nozzle station assembly surface and measure the

distance to the upper edge of the lower X axis linear

guidance.

CAUTION!

Hold the measuring scale vertically!

1. Adjusting plates

2. Slot

► Set a distance of 139.0±0.2 mm for all placement

heads.

If the distance is too large, insert shim plates: Shim

plates for nozzle stripping device [03039514-xx,

Screws DIN7991 M4x20-8.8 [00333782-xx].

Settings

Other Settings 5.8.4 DIP Switch for Camera Types 25 and 33

270 Service Manual SIPLACE SX4/DX4

5.8.4

5.8.4 DIP Switch for Camera Types 25 and 33

DIP Switch for Camera Types 25 and 33

Setting

► Switch off the machine, disconnect it from the power supply and secure it to prevent unauthorized

reactivation. Observe the instructions in section "1.2 Preparatory Work..." [ ➙ 12].

► Remove the camera upper part and the cover on the lower part, to gain access to the DIP switches.

► Set the DIP switches. (see below)

► Fit all parts by following the above instructions in the reverse order.

DIP switch

Boards with version status 01 and 02 are fitted with a TQ module. In this case, the DIP switching block

is 8 pin.

Boards with version status 03 or higher do not have a TQ module. In this case, the DIP switching block

is 6 pin.

Version state 01 and 02: DIP switch settings (8 pin)

* Not all gantries may be available, depending on the machine type.

Version state 03 and higher: DIP switch settings (6 pin)

* Not all gantries may be available, depending on the machine type.
