Page HANWHA TECHWIN 216 SM451DH Gripper Nozzle NO. LEVEL PA R T N O . P ART NAME Q'TY Old N o. Old No. St o c k Apply Reference 1 J90551444A DUAL_GRIPPER_B L_ASSY 1 2 J90551445A DUAL_GRIPPER_F L_ASSY 1 3 J90551428A …
Page
HANWHA TECHWIN
214
SM451DH
Articles of Consumption
NO. LEVEL PART NO. PART NAME Q'TY Old No. Old No. Stock Apply Reference
28 PM02-900009A HDD_PACKAGE_ASSY PM02-900009A
29 J9055276A LIGHT MAPPING TOOL ASSY[J9055276A]
30 J9055249A LIGHT MAPPING TOOL ASSY[J9055249A]
31 J9055250A LIGHT MAPPING TOOL ASSY[J9055250A]
32 HP14-900026 SOLENOID VALVE [K180-4E1-21-DC24V] 2 Years
33 MC05-900068 BELT_410_1 Inspect and replace (6 months)
34 MC05-900069 BELT_410_F MAM-5P-1517-7W Inspect and replace (6 months)
35 MC05-900070 BELT_410_R Inspect and replace (6 months)
Page
HANWHA TECHWIN
215
SM451DH
Articles of Consumption
NO. LEVEL PART NO. PART NAME Q'TY Old No. Old No. Stock Apply Reference
Page
HANWHA TECHWIN
216
SM451DH
Gripper Nozzle
NO. LEVEL PART NO. PART NAME Q'TY Old No. Old No. Stock Apply Reference
1 J90551444A DUAL_GRIPPER_BL_ASSY 1
2 J90551445A DUAL_GRIPPER_FL_ASSY 1
3 J90551428A TWIN_RUBBER_NOZZLE_ASSY_VD1 1
4 J90551429A TWIN_RUBBER_NOZZLE_ASSY_VD2 1
5 J90551417A NOZZLE_RN12_ASSY 1
6 J90551459A DUAL_2POINT_JAW_ASSY 1
7 J70551704A JAW_FL_D_1606_2P 2
8 J70551707A JAW_BL_D_1004_2P 2
9 J70551703A JAW_FL_D_0708_2P 2
10 J70551682A JAW_FL_D_2908_2P 2
11 J70551681A JAW_FL_D_2006_2P 2
12 J70551680A JAW_FL_D_1007_2P 2
13 J70551679A JAW_FL_D_0911_2P 2
14 J90551461A DUAL_2POINT_RUBBER_JAW_ASSY 1
15 J70551705A JAW_FL_D_3409_2R 2
16 J70551702A JAW_BL_D_1407_2R 2
17 J90551462A DUAL_4POINT_JAW_ASSY 1
18 J70551677A JAW_BL_D_0916_4P 2
