Page HANWHA TECHWIN 23 SM451DH Conveyor Ass’y (5/7) NO. P ART NO. P ART NAME Q'TY Old No. Sto ck Apply Reference 1 FC18-902674 SOCKET HEAD CAP S CREW M5*18 (NI/ZN) 10 2 FC07-000030A BLOCK-MOVE_FRAME;ME1:S teel 2 3 M…
Page
HANWHA TECHWIN
22
SM451DH
Conveyor Ass’y (5/7)
30
32
28
23
23
23
19
22
18
15
14
22
21
21
8
7
20
34
34
34
20
31
33
27
6
25
A
37
C
A
B
26
B
22
23
24
23
18
22
22
23
24
18
21
7
7
6
24
23
14
5
2
B
C
29
29
16
16
17
17
19
13
12
27
11
12
35
10
36
9
1
1
4
4
Page
HANWHA TECHWIN
23
SM451DH
Conveyor Ass’y (5/7)
NO. PART NO. PART NAME Q'TY Old No. Stock Apply Reference
1 FC18-902674 SOCKET HEAD CAP SCREW M5*18 (NI/ZN) 10
2 FC07-000030A BLOCK-MOVE_FRAME;ME1:Steel 2
3 MC14-000070 BELT,CONVEYOR-MAM-5P-1490-7W;PA 1 MC05-900070
4 FC18-902685 SOCKET HEAD CAP SCREW M5*35 (NI/ZN) 2
5 FC09-005024A BRACKET-SENSOR_DOG;ME1:Steel 1 FC09-000017A
6 MC05-900068 BELT_410_1 2
7 J7153111A TEP MOTOR PULLEY [J7153111A] 3
8 70531741A MOVE_MOTOR_BKT J70531741A 1
9 J7253008B STOPPER[J7253008B] 2
10 J7153010B ADJUST SHAFT [J7153010B] 2
11 J7153033A BUSH SPACER 2
12 MC06-900006 BALL_BUSH LMU5 4
13 J7153034A CLAMP SHAFT 2
14 HP06-900047 ELBOW FITTING 2
15 HP09-900109 REGULATOR 1
16 J70531021A IDLER_SHAFT_M J70531021A 2
17 J7053048A IDLER_SPACER_M 3
18 J7053184A SQUARE NUT M4 5
19 MC13-900013 LM SLIDE 4
20 J70531106A BRACKET_BELT_MOTOR_S J70531106A 2
21 EP08-900073 STEP_MOTOR 2S56Q-01842SR2 3
22 J2101818 IDLER SHAFT-S [0135-641105] 8
23 J7253007A IDLER 2 8
24 J7053047A IDLER SPACER-S 7
25 FC18-903195 PROFILE MOUNT [DIA4.0] 11
26 FC39-000005A FRAME-CONV_REAR;ME6:Aluminum 1
27 J7253009B STOPPER 2 [J7253009B] 2
Page
HANWHA TECHWIN
24
SM451DH
Conveyor Ass’y (5/7)
NO. PART NO. PART NAME Q'TY Old No. Stock Apply Reference
28 J71530400C CLAMP REAR FRAME 1
29 J71531048B PCB_GUIDE_END 2
30 FC15-000013A COVER-REAR_PCB;ME1:Steel 1
31 J7153373A FIDUCIAL DISK[J7153373A] 1
32 HP03-900039 EDGE CYLINDER[CQ2B6-CJJC2948] 1
33 HP06-900047 ELBOW FITTING 1
34 FC18-902843 SOCKET SET SCREW [M3*5 (BL/ZN)] 6
35 FC18-901355 C-RING DIA11(HOLE) 1
36 FC18-900900 HEX NUT 1
37 MC05-900070 BELT_410_R 1
