3 Technical data and assemblies User manual SIPLACE E
3.1 Overview of technical data From software version SC 708.0 12/2014 Edition
100
3.1.3 Component camera configuration
3.1.4 Component feeding
3
Placement
head 1
Component
Camera 1
Placement
head 2
Stationary
Component
Camera 1
*a
*)a Optional, type 33 GigE
Stationary
Component
Camera 2
*b
*)b Optional
SIPLACE CP14 Type 23 GigE -- -- --
SIPLACE CP12 Type 30 GigE -- -- --
SIPLACE CP12 Type 30 GigE SIPLACE PP Type 36 GigE Type 25 GigE
SIPLACE CP6 Type 30 GigE SIPLACE PP Type 36 GigE Type 25 GigE
-- -- SIPLACE TH Type 36 GigE Type 25 GigE
Feeder locations
Changeover table with 60 tracks
Fixed table with 60 tracks
60 feeders with SIPLACE SmartFeeder 8mm E
60 feeders with SIPLACE SmartFeeder 8mm E
Changeover table changeover time < 1 minute
Max. component feeding
SIPLACE E double sided
SIPLACE E single sided
120 locations for feeders with SIPLACE SmartFeeder 8mm E
60 locations for feeders with SIPLACE SmartFeeder 8mm E
Feeder module types
(SIPLACE E)
SIPLACE SmartFeeder E
SIPLACE StickFeeder E
Manual Tray holder E (Speed)
Manual Tray holder E (Flex)
SIPLACE JTF-MW
Feeding capacity
(2 change over tables on the
SIPLACE E)
120 tape feeder modules, SIPLACE SmartFeeder 8 mm E
60 tape feeder modules, SIPLACE SmartFeeder 2x8 mm E
60 tape feeder modules, SIPLACE SmartFeeder 12 mm E
60 tape feeder modules, SIPLACE SmartFeeder 16 mm E
40 tape feeder modules, SIPLACE SmartFeeder 24 mm E
30 tape feeder modules, SIPLACE SmartFeeder 32 mm E
24 tape feeder modules, SIPLACE SmartFeeder 44 mm E
20 tape feeder modules, SIPLACE SmartFeeder 56 mm E
User manual SIPLACE E 3 Technical data and assemblies
From software version SC 708.0 12/2014 Edition 3.1 Overview of technical data
101
3.1.5 PCB conveyor - data
3
3
Single conveyor
Standard dimensions (length x width)
With buffering
Without buffering
*a
*)a Availible at 04/2015
50 mm x 50 mm to 460 mm x 460 mm
50 mm x 50 mm to 490 mm x 460 mm
With “Long Board”option 1030 (length x width)
Single step mode
Two step mode
a
50 mm x 50 mm to 610 mm x 460 mm
50 mm x 50 mm to 1030 mm x 460 mm
With “Long Board”option 1200 (length x width) 70 mm x 50 mm to 1200 mm x 460 mm
Stationary conveyor side Right, Left
Automatic electrical width adjustment Standard
PCB thickness
Standard 0.3 mm to 4.5 mm
PCB warpage See page
137
PCB weight
*b
Standard
*)b The board weight value refers to the weight of the board plus the weight of the components.
max. 2.0 kg
Clearance on PCB underside
*c
*)c The free positioning of support pins is limited by the stop bar.
25 mm
PCB conveyor height
Standard
Option
900 mm to 930 mm
950 mm
Type of interface:
Standard: SMEMA
Component-free PCB handling edge 3.0 mm
PCB changeover time
Single conveyor < 1.5 seconds
Important notes
When setting up a machine (S; F-, HS-, HF-, X- or D-Series) next to a SIPLACE E, be aware that there is limited room between the two
machines. In these cases, use suitable conveyor extensions to create room of 0.5m for the operator between the two machines.
3 Technical data and assemblies User manual SIPLACE E
3.2 Ambient conditions and connection values From software version SC 708.0 12/2014 Edition
102
3.2 Ambient conditions and connection values
3.2.1 Ambient conditions for packaging, transportation and storage
3
3.2.2 Ambient conditions for machine operation
3
3.2.3 Electrical ratings
3
Temperature range Between -25°C and 55°C
Atmospheric humidity Up to 95%
Ambient pressure Up to 3000 m height without pressure equalization
Room temperature Between 15°C and 35°C
Atmospheric humidity 30% to 75 % (no higher than 45% on average to prevent any
possibility of condensation on the machine)
Ambient pressure > 890 mbar (corresponds to 1000 m above mean sea level)
Electrical ratings
Supply voltage Fuse
Main power supply 3 x 200 V~ up to 3 x 230 V~; ± 10 %; 50/60 Hz)
*a
3 x 380 V~ up to 3 x 415 V~; ± 10 %; 50/60 Hz
3 x 16 A characteristic C
3 x 16 A characteristic C
Mains power connection Cable 4 x 4 mm² with CEKON connector
Energy consumption
Energy consumption
with
vacuum pump
Nominal active power
1.8 kW
Nominal apparent power
2.3 kVA
*)a with adapter kit (US option)
