5 Working with the machine User manual SIPLACE E
5.11 Setting up the feeder modules From software version SC 708.0 12/2014 Edition
238
5.11.4.4 Tape support for SIPLACE SmartFeeder 8 mm E module
5
Fig. 5.11 - 7 SIPLACE SmartFeeder 8 mm E - tape support
(1) Tape support, removable
(2) Oval opening in the tape support
The SIPLACE SmartFeeder E is equipped with a tape support (item 1 in fig. 5.11 - 7). It can easily
be removed if necessary.
Insert the tang of a watchmaker's screwdriver into the oval opening (item 2 in fig. 5.11 - 7) in
the tape support and pull the tape support out against the direction of travel of the tape.
When you insert the tape support, make sure that it engages in its desired position.
5
PLEASE NOTE
Constant Z pickup height and reduction of time used to correct pickup heights
For all components size 0402 and smaller, always insert the tape support (item 1 in
fig. 5.11 - 7) into the feeder module.
User manual SIPLACE E 5 Working with the machine
From software version SC 708.0 12/2014 Edition 5.12 Observing displays on the SIPLACE SmartFeeder E
239
5.12 Observing displays on the SIPLACE SmartFeeder E
5.12.1 LED display
The SIPLACE SmartFeeder E have a LED display, to indicate the operating states for each track.
5
Fig. 5.12 - 1 Buttons and LED display: example of SIPLACE SmartFeeder 2x8mm E module shown
(1) SET button
(2) FOIL button
(3) BACK button
(4) FORWARD button
(5) Track change button for switching between right and left
(6) LED L left track active
(7) LED 1 mm increment for left track
(8) LED 2 mm increment for left track
(9) LED 4 mm increment for left track
(10) LED 8 mm increment for left track
(11) LED R right track active
(12) LED 1 mm increment for right track
(13) LED 2 mm increment for right track
(14) LED 4 mm increment for right track
(15) LED 8 mm increment for right track
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
(9)
(10)
(15)
(14)
(13)
(12)
(11)
5 Working with the machine User manual SIPLACE E
5.12 Observing displays on the SIPLACE SmartFeeder E From software version SC 708.0 12/2014 Edition
240
5.12.2 Status display
–Green:
The feeder module is on standby and is contained in the current setup.
– Orange:
A warning is being signalized.
– Red:
A malfunction has occurred.
– Off:
The feeder module is not in the current setup.
5
5
5.12.2.1 Status display and possible meanings and and solutions
The following table containing the color of the status display, possible meanings and troubleshoot-
ing measures.
5
PLEASE NOTE
"Status display off" only for feeder modules contained in the setup
The machine controller switches off the status display of any feeder modules not included
in the setup.
The "Status display off" status only occurs when the programming system has preset a
job on the line. This takes some of the work away from the operator since he only has to
watch those feeder modules that are contained in the setup.
PLEASE NOTE
Setup procedure: Activation of the status display for each feeder module
For the actual setup process - no setup information at the station, no job sent from SI-
PLACE Pro to the station/line - the status display on each feeder module is activated after
the setup has been made. The operator is thus informed whether everything is OK.
Status
display
Possible Meaning Solution
Orange The selected function is not permit-
ted when the cover foil is tensioned
(foil rocker is pressed down).
If you wish to carry out that function, remove the foil from
the pair of gear wheels and cut it off to relieve the
pressure on the foil rocker.
Orange 24V supply voltage did not rise
above the switch-on threshold af-
ter switching on
Check the power supply
Red,
flashing
Feeder module software not jump-
ing to the application
Reload the application software
Load feeder module software
Red Feeder module was signaled, but
removal handle is not yet pushed in
Push in the removal handle
