7 Cleaning and Checking User manual SIPLACE E 7.2 Cleaning and Checking Intervals SIPLACE CP14 P From software version SC 708.0 12/2014 Edition 302 7.2 Cleaning and Checking Intervals SIPLACE CP14 P 7 Cleaning and C heck…

100%1 / 308
User manual SIPLACE E 7 Cleaning and Checking
From software version SC 708.0 12/2014 Edition 7.1 Cleaning and Checking Intervals Base Machine
301
7
7
7
a) This value is for 3 shift operation (7500 hours of operation). Longer intervals can be planned for other operation setups.
Cleaning and Checking tasks
Component Docking Unit
Duration
[min]
Each
week
Every 3
months
Every 6
months
Every 12
months
– Function Test of Used Tape Cutter
2X
– Greasing the Tape Cutter
5X
– Greasing the Cutting Blade
2X
– Greasing the COT Insert
1X
– Greasing the Locator Bearing on the Component Trol-
ley for SIPLACE SmartFeeder E
1X
Cleaning and Checking tasks
Optical systems
Duration
[min]
Each
week
Every 3
months
Every 6
months
Every 12
months
– Cleaning the IC and FC Cameras
4X
– Cleaning the PCB Barcode Scanner
*a
2X
*)a If availible
Cleaning and Checking tasks
Vacuum pump
Duration
[min]
Each
week
Every 3
months
Every 6
months
Every 12
months
– Checking/Replacing the Filter Insert
15 X
a
7 Cleaning and Checking User manual SIPLACE E
7.2 Cleaning and Checking Intervals SIPLACE CP14 P From software version SC 708.0 12/2014 Edition
302
7.2 Cleaning and Checking Intervals SIPLACE CP14 P
7
Cleaning and Checking tasks
SIPLACE CP14
Duration
[min]
Each
week
Every 3
months
Every 6
months
Every 12
months
– Preparing the Placement Head
5X
– Replacing the Pressure Control Valve
3X
– Cleaning the Z Axis
6X
– Oiling the DP Segment Guide
15 X
– Oiling the Z Axis Linear Guide
3X
– Oiling the DP Driver Bearing
4X
– Checking/Replacing the Vacuum-Conducting Parts
– Reflecting ring and cover
or 7
– Holding circuit and silencer
5X
– Cleaning the Raceway and the Jaw
2X
– Replacing the Filter Disks
15 X
– Checking/Cleaning/Replacing the Switching Disks
1 x X
– Cleaning the Component Sensor
1X
User manual SIPLACE E 7 Cleaning and Checking
From software version SC 708.0 12/2014 Edition 7.3 Cleaning and Checking Intervals SIPLACE TH/PP
303
7.3 Cleaning and Checking Intervals SIPLACE TH/PP
7
7.4 Cleaning and Checking Intervals SIPLACE CP12/CP6
7
Cleaning and Checking tasks
SIPLACE TH/PP
Duration
[min]
Each
week
Every 3
months
Every 6
months
Every 12
months
– Preparing the Placement Head
5X
– Replacing the Pressure Control Valve
3X
– Cleaning the Sleeve and Nozzle Seat
2X
– Cleaning/Replacing the Additional Volume Filter
2X
Cleaning and Checking tasks
SIPLACE CP12/CP6
Duration
[min]
Each
week
Every 3
months
Every 6
months
Every 12
months
– Removing the Valve Plungers
2/4 X
– Cleaning the Valve Casings
1/2 X
– Cleaning the Valve Plungers
3/6 X
– Greasing the Valve Plungers
3/6 X
– Inserting the Valve Plungers
2/4 X
– Checking, Cleaning and Greasing the Sleeves
20/40 X
– Cleaning the Turning Station Read Unit
2/2 X
–Z axis:
– Clean the toothed belt
– Clean the rollers and toothed wheels
– Check the toothed belt
– Grease the toothed belt
– Check the Z axis guide
– Check the jaws
– Grease the Z axis guide
6/6 X
