User manual SIPLACE E 2 Operational safety From software version SC 708.0 12/2014 Edition 2.2 Warning label s 47 2.2.1.5 Warning label EMS (US) 2 W arning label EMS (US) in fig. 2.2 - 4 , page 44 item no. 03113900-01 Qua…
2 Operational safety User manual SIPLACE E
2.2 Warning labels From software version SC 708.0 12/2014 Edition
46
2.2.1.3 Warning label W 209
2
W 209 in fig. 2.2 - 1, page 41, 2.2 - 2, page 42 and 2.2 - 3, page 43, item no. 03009349-01
Quantity per machine:
SIPLACE E double sided: 2 2
SIPLACE E single sided: 1 2
2.2.1.4 Warning label EMS (China)
2
Warning label EMS (China) in fig. 2.2 - 4, page 44 item no. 03113523-01
Quantity per machine:
SIPLACE E double sided: None 2
SIPLACE E single sided: One on location 2 2
2
2
2
2
2
2
Warning label on the EMERGENCY STOP button.
2
2
2
2
2
2
2
2
2
2
2
2
Warning label on the EMERGENCY STOP button on location 1
and 2 for single sided machines. For China.
User manual SIPLACE E 2 Operational safety
From software version SC 708.0 12/2014 Edition 2.2 Warning labels
47
2.2.1.5 Warning label EMS (US)
2
Warning label EMS (US) in fig. 2.2 - 4, page 44 item no. 03113900-01
Quantity per machine:
SIPLACE E double sided: None 2
SIPLACE E single sided: One on location 2 2
2.2.1.6 Warning label W203
2
W203 in fig. 2.2 - 1, page 41 and 2.2 - 2, page 42, item no. 03009342-01
Quantity per machine:
SIPLACE E double sided: 4 2
SIPLACE E single sided: 4 2
2
2
2
Warning label on the EMERGENCY STOP button on location 1
and 2 for single sided machines. For Australia, Canada, Mexico
and USA.
2
2
2
DANGER OF CRUSHING!
Reaching in here can lead to injuries to the arms and hands.
Do not reach into the machine while it is running!
2 Operational safety User manual SIPLACE E
2.2 Warning labels From software version SC 708.0 12/2014 Edition
48
2.2.1.7 Warning label W204
2
W204 in fig. 2.2 - 1, page 41 and 2.2 - 2, page 42, item no. 03009343-01
Quantity per machine:
SIPLACE E double sided: 4 2
SIPLACE E single sided: 4 2
2.2.1.8 W-General warning, label on the monitor
2
W-General warning label in fig. 2.2 - 1 on page 41, 2.2 - 2 on page 42, 2.2 - 3 on page 43
and 2.2 - 4 on page 44
Quantity per machine:
SIPLACE E double sided: 2 2
SIPLACE E single sided: 1 2
2
2
2
2
DANGER OF CRUSHING!
Reaching in here can lead to injuries to the arms and hands.
Do not reach into the machine while it is running
2
2
2
GENERAL WARNING -
RISK OF ABRASION AND PART DAMAGE!
Remove the USB from the side port after loading the pro-
gram.
Failure to remove may cause abrasion/minor cuts or damage to
USB port when come into contact.
