Teilekatalog (Parts Catalog) Bebilderte Teileliste (Illustrated Parts) Bildtafel (Figure) 17 A usgabe (Edition) 11-03 Stamm Nr. Master Code Bezeichnung / Designation Stck. Qty. Pos.-Nr. Pos. No. Seiten-Nr. Page No. A rti…

100%1 / 596
Teilekatalog (Parts Catalog) Bebilderte Teileliste (Illustrated Parts)
Bildtafel (Figure) 17
Ausgabe (Edition) 11-03
Stamm Nr.
Master Code
Bezeichnung / Designation
Stck.
Qty.
Pos.-Nr.
Pos. No.
Seiten-Nr.
Page No.
A
rtikel-Nr.
Item No.
FS
FS
n
fachtransport feste Transportseite links / Single conveyor fixed transport side l
e
Order
229
00303193-01
6
17-14
DIN912-M3 X 8-A2 ZYLINDERSCHRAUBE
DIN912-M3 X 8-A2 HEXAGON SOCKET HEAD CAP SCREW
230
00200321-01
1
17-16
DU-STREIFEN
DU-STRIP
231
00303193-01
2
17-16
DIN912-M3 X 8-A2 ZYLINDERSCHRAUBE
DIN912-M3 X 8-A2 HEXAGON SOCKET HEAD CAP SCREW
232
00303193-01
2
17-15
DIN912-M3 X 8-A2 ZYLINDERSCHRAUBE
DIN912-M3 X 8-A2 HEXAGON SOCKET HEAD CAP SCREW
233
00845015-01
5
17-14
ZYLINDERSCHRAUBE M3*10 DIN912
HEXAGON SOCKET HEAD CAP SCREW M3*10
234
00324405S01
1
17-11
EDC-GETRIEBEMOTOR MIT SYNCHRONSCHEIBE
MOTOR WITH SYNCHRONIZING GEAR
235
00326032-01
1
17-18
KABEL: MOTOR EINGABEBAND 1
CABLE MOTOR INPUT BELT 1
237
00201462-01
5
17-11
DIN912-M3 X 10-A2 ZYLINDERSCHRAUBE
DIN912-M3 X 10-A2 HEXAGON SOCKET HEAD CAP SCREW
238
00303193-01
2
17-15
DIN912-M3 X 8-A2 ZYLINDERSCHRAUBE
DIN912-M3 X 8-A2 HEXAGON SOCKET HEAD CAP SCREW
239
00303193-01
2
17-12
DIN912-M3 X 8-A2 ZYLINDERSCHRAUBE
DIN912-M3 X 8-A2 HEXAGON SOCKET HEAD CAP SCREW
240
00303193-01
4
17-11
DIN912-M3 X 8-A2 ZYLINDERSCHRAUBE
DIN912-M3 X 8-A2 HEXAGON SOCKET HEAD CAP SCREW
241
00303193-01
2
17-13
DIN912-M3 X 8-A2 ZYLINDERSCHRAUBE
DIN912-M3 X 8-A2 HEXAGON SOCKET HEAD CAP SCREW
242
00200322-01
1
17-13
EDU-STREIFEN
DU-STRIPES
243
00317680-03
1
17-16
EKIPPHEBEL, RECHTS
ROCKING LEVER RIGHT
244
00328687-01
1
17-14
VERSTEIFUNGSLEISTE, LINKS FEST
REINFORCING RAIL, LEFT SIDE FIXED
245
00845027-01
5
17-14
DIN912-M4 X 16-8.8 ZYLINDERSCHRAUBE
DIN912-M4 X 16-8.8 HEXAGON SOCKET HEAD CAP SCREW
246
00303193-01
4
17-11
DIN912-M3 X 8-A2 ZYLINDERSCHRAUBE
DIN912-M3 X 8-A2 HEXAGON SOCKET HEAD CAP SCREW
247
00303193-01
2
17-13
DIN912-M3 X 8-A2 ZYLINDERSCHRAUBE
DIN912-M3 X 8-A2 HEXAGON SOCKET HEAD CAP SCREW
248
00200319-01
1
17-13
DU-STREIFEN
DU-STRIP
249
00324405S01
1
17-11
EDC-GETRIEBEMOTOR MIT SYNCHRONSCHEIBE
MOTOR WITH SYNCHRONIZING GEAR
250
00326031-02
1
17-18
KABEL: MOTOR MITTENBAND 1
CABLE MOTOR CENTER BELT 1
252
00317677-03
1
17-11
ESEITENTEIL: B
SIDE PANEL B
17 24 -
Teilekatalog (Parts Catalog) Bebilderte Teileliste (Illustrated Parts)
Bildtafel (Figure) 17
A
usgabe (Edition) 11-03
Stamm Nr.
Master Code
Bezeichnung / Designation
Stck.
Qty.
Pos.-Nr.
Pos. No.
Seiten-Nr.
Page No.
A
rtikel-Nr.
Item No.
FS
FS
n
fachtransport feste Transportseite links / Single conveyor fixed transport side l
e
Order
253
00200196-02
4
17-12
EZAHNRIEMEN BRECOFLEX 13T5/1105
TOOTHED BELT
254
00095304-01
4
17-12
SENKSCHRAUBE M3*6 DIN965
SLOTTED COUNTERSUNK HEAD SCREW
255
00200195-01
4
17-12
ESCHEIBE
WASHER
256
00200194-01
4
17-12
ESYNCHRONSCHEIBE AL 13 T5/13-0 N.ZCHNG.
SYNCHRONIZING DISK AL13T5/13-0
257
00200334-01
4
17-12
ENADELHUELSE 6*10*9 HK0609 ST
NEEDLE SLEEVE
258
00300558-01
4
17-12
EDU-SCHEIBE
DU DISC
259
00303193-01
6
17-14
DIN912-M3 X 8-A2 ZYLINDERSCHRAUBE
DIN912-M3 X 8-A2 HEXAGON SOCKET HEAD CAP SCREW
260
00200185-02
2
17-14
EFLANSCH
FLANGE
261
00200198-01
2
17-14
EDU-SCHEIBE
DU-WASHER
262
00095488-01
2
17-14
SICHERUNGSRING 12*1 DIN471
RETAINING RING
263
00200337-01
2
17-14
ERILLENKUGELLAGER 12*21*5 61801-2Z
BALL BEARING 12*21*5 61801-2Z
264
00200193-02
2
17-14
ESYNCHRONSCHEIBE ST 24 T5/13-0 N.ZCHNG.
SYNCHRONIZING GEAR
265
00200183-01
2
17-14
ESCHEIBE
WASHER
267
00098617S01
4
17-11
ERILLENKUGELLAGER 7*19*6 607-2Z
BALL BEARING
268
00200191-02
2
17-11
ESYNCHRONSCHEIBE AL 8 T2,5/25-0 N.ZCHNG.
SYNCHRONIZING GEAR
271
00200192-02
2
17-12
ESYNCHRONSCHEIBE AL 13,5 T5/13-0 N.ZCHNG
SYNCHRONIZING GEAR
272
00303193-01
2
17-15
DIN912-M3 X 8-A2 ZYLINDERSCHRAUBE
DIN912-M3 X 8-A2 HEXAGON SOCKET HEAD CAP SCREW
273
00200181-01
4
17-12
EBOLZEN
BOLT
274
00095485-01
4
17-12
SICHERUNGSRING 9*1 DIN471
RETAINING RING
275
00200338-01
4
17-12
ERILLENKUGELLAGER 9*26*8 629-2Z
BALL BEARING 9 * 26 * 8 629-2Z
276
00327902-01
8
17-16
DU-STREIFEN 1MM DICK
DU STRIP 1MM THICKNESS
277
00095304-01
16
17-16
SENKSCHRAUBE M3*6 DIN965
SLOTTED COUNTERSUNK HEAD SCREW
17 25 -
Teilekatalog (Parts Catalog) Bebilderte Teileliste (Illustrated Parts)
Bildtafel (Figure) 17
Ausgabe (Edition) 11-03
Stamm Nr.
Master Code
Bezeichnung / Designation
Stck.
Qty.
Pos.-Nr.
Pos. No.
Seiten-Nr.
Page No.
A
rtikel-Nr.
Item No.
FS
FS
n
fachtransport feste Transportseite links / Single conveyor fixed transport side l
e
Order
278
00317679-04
1
17-13
ENIEDERHALTER, LINKS: B
RETAINER - LEFT SIDE B
279
00200177-02
2
17-14
ESTANGE, SECHSKANT-
SHAFT
280
00317678-04
1
17-16
ENIEDERHALTER, RECHTS
HOLDING-DOWN DEVICE RIGHT
281
00200305-01
4
17-16
EKLOTZ
BLOCK
282
00095304-01
8
17-16
SENKSCHRAUBE M3*6 DIN965
SLOTTED COUNTERSUNK HEAD SCREW
283
00200342-01
4
17-16
EDRUCKFEDER 0,8*8,8*32 V2A
COMPRESSION SPRING VD-125
284
00200347-01
4
17-16
ZYLINDERSTIFT 5M5*14 DIN6325
PARALLEL PIN
285
00326022-01
1
17-11
ESONARBERO EINGABEBAND 1
SONAR PROXIMITY SWITCH INPUT BELT 1
288
00333665-01
1
17-2
LP-STOPPER, FESTE SEITE LINKS
PCB STOPPER FIXED SIDE LEFT
289
00313885-08
1
17-8
ESTOPPER-GRUNDMODUL
PLUG BASE UNIT
292
00201152-01
1
17-8
EO-RING 18*1 NBR 70 B
O-RING 18*1 NBR 70 B
294
00310028-01
1
17-8
3/2-WEGEVENTIL MICRO 10 FKT. NO
3/2 WAY VALVE MICRO 10 FKT.
295
00336762-01
1
17-8
SCHALLDAEMPFER U-M3
SILENCER U-M3
297
00347173-01
1
17-8
REDUZIERNIPPEL M3 I/A
REDUCING NIPPLE M3 I/O
298
00342532-01
1
17-8
EINSCHRAUBWINKEL M-3ALU-4RT
SCREW-IN ANGLE M-3ALU-4RT
301
00201141-01
1
17-8
EO-RING 3*1 NBR 70 B
O-RING 3*1 NBR 70 B
306
00201130-04
1
17-8
EPUFFER FUER LP-STOPPER
BUFFER
310
00201148S01
2
17-8
EDICHTRING O-M5 PVC HART
SEALING RING M5 PVC HARD
313
00201149-01
1
17-8
EQUADRING 10,77*2,62 NBR 70 SHORE
QUAD RING 10,77*2,62 NBR 70 SHORE
315
00201150-01
1
17-8
EQUADRING 8,20*1,78 NBR 70 SHORE
QUADRING 8,20 *2,62 NBR 70 SHORE
325
00326026-02
1
17-8
EKABEL: VENTIL STOPPER 1
CABLE VALVE STOPPER 1
326
00326025-02
1
17-8
EBERO STOPPER 1
BERO STOPPER 1
17 26 -
