Teilekatalog (Parts Catalog) Bebilderte Teileliste (Illustrated Parts) Bildtafel (Figure) 25 A usgabe (Edition) 11-03 Stamm Nr. Master Code Bezeichnung / Designation Stck. Qty. Pos.-Nr. Pos. No. Seiten-Nr. Page No. A rti…

100%1 / 596
Teilekatalog (Parts Catalog) Bebilderte Teileliste (Illustrated Parts)
Bildtafel (Figure) 25
Ausgabe (Edition) 11-03
Stamm Nr.
Master Code
Bezeichnung / Designation
Stck.
Qty.
Pos.-Nr.
Pos. No.
Seiten-Nr.
Page No.
A
rtikel-Nr.
Item No.
FS
FS
IC-Kopf für CAN-Bus / Pick & place-head f. CAN-BUS
Order
23
00304044-01
1
25-4
SYNCHRONSCHEIBE AL 6,3 T2/15-0 N.ZCHNG.
SYNCHRONIZING DISK ACCORDING TO DRAWING
24
00304057-04
1
25-4
LAGERGEHAEUSE
BALL BEARING HOUSING
25
00304055-01
1
25-4
SCHRAEGKUGELLAGER 8*22*11 30/8.2Z ZWEIR
ANGULAR BALL BEARING
26
00329391-01
2
25-4
SPEZIALSCHRAUBE FUER ZAHNRIEMEN
SPECIAL SCREW FOR TOOTHED BELT
27
00316142-01
1
25-4
SECHSKANTMUTTER M8*1 DIN439B
HEXAGON NUT
28
00309319-01
1
25-4
PASSSCHEIBE 8*14*0,5 DIN988
ADJUSTING SHIM
29
00304069S01
1
25-4
EZAHNRIEMEN-SYNCHROFLEX 6 T2/220
TOOTHED BELT SYNCHROFLEX 6 T2/220
30
00304081S01
1
25-2
ESYNCHRONSCHEIBE AL 10 T2/26-0 N.ZCHNG.
SYNCHRONIZING DISK
31
00304070S01
2
25-2
EMINIATURKUGELLAGER 6*13*5 686 ZZS
MINIATURE BALL BEARING 6*13*5 686 ZZS
32
00304083-01
1
25-2
BOLZEN
BOLT
33
00304090-01
1
25-2
FEDERSCHEIBE FS 6*8
SPRING WASHER
34
00048326-01
1
25-2
SICHERUNGSSCHEIBE 4*0,7 DIN6799
LOCK WASHER
35
00306385S02
1
25-2
EMOTOR / TACHO / BERO (Z-ACHSE)
MOTOR WITH GEAR WASHER
36
00306432S01
1
25-2
EBERO 3RG4 / 6,5MM / SN=1,5MM / 1S
BERO 3RG4 / 4,5MM / SN=1,5MM / 1S
37
00304084-02
1
25-3
KLEMMSTUECK
CLAMPING PIECE
38
00304085-03
1
25-3
KLEMMTEIL
CLAMPING PIECE
39
00304091S01
1
25-3
ELINEARKUGELLAGER 5*10*14 L 510 X
BALL BEARING 5*10*14 L 510X
40
00304092-01
1
25-3
GENAUIGKEITSWELLE 5*76,5
PRECISION SHAFT
41
00304086S04
1
25-2
EKUGELKAEFIG
BALL CAGE
42
00304093-01
3
25-2
KUGEL 3,5 DIN5401 GUETE 3 WAELZLAGERSTAH
BALL 3.5 QUALITY 3 ROLLER BEARING STEEL
43
00304094S01
1
25-2
EO-RING 11*2,5 NBR 70 B
O-RING 11*2,5 NBR 70 B
44
00304099-01
3
25-2
ZYLINDERSCHRAUBE M2*5 DIN84
HEXAGON SOCKET HEAD CAP SCREW
25 10 -
Teilekatalog (Parts Catalog) Bebilderte Teileliste (Illustrated Parts)
Bildtafel (Figure) 25
A
usgabe (Edition) 11-03
Stamm Nr.
Master Code
Bezeichnung / Designation
Stck.
Qty.
Pos.-Nr.
Pos. No.
Seiten-Nr.
Page No.
A
rtikel-Nr.
Item No.
FS
FS
IC-Kopf für CAN-Bus / Pick & place-head f. CAN-BUS
Order
45
00304068-01
2
25-2
ZYLINDERSTIFT 1,5M5*4 DIN6325
PARALLEL PIN
46
00304088S05
1
25-2
EHUELSE
SLEEVE
47
00304100S01
1
25-2
EDRUCKFEDER 1,5*22*19
COMPRESSION SPRING 1,5*22*19
48
00304102S03
1
25-2
EBUNDBUCHSE
FLANGE SLEEVE
49
00304118S01
2
25-2
EQUADRING 25*3,53 NBR 70 SHORE
QUADRING 25*3,53 NBR 70 SHORE
50
00304104-06
1
25-2
HALTER
HOLDER
51
00306387S02
1
25-2
EVENTIL (KLEMMUNG DR-ACHSE)
VALVE REVOLVING AXIS SIPLACE IC-HEAD
52
00300875-01
1
25-2
ESTECKVERSCHRAUBUNG CS-M5-PK-3
QUICK RELEASE FASTENER
53
00305483-01
2
25-2
ZYLINDERSCHRAUBE M1,6*14 DIN84
HEXAGON SOCKET HEAD CAP SCREW
54
00306383S02
1
25-2
EMOTOR / TACHO (DR-ACHSE)
MOTOR TACHO DR-AXIS
56
00304109S01
1
25-3
EREIBRAD SIPLACE IC-KOPF
RUB WHEEL FOR IC-HEAD
57
00201426-01
3
25-3
ZYLINDERSCHRAUBE M3*6 DIN84 A2
HEXAGON SOCKET HEAD CAP SCREW
58
00304126-01
3
25-2
ABSTANDSBOLZEN M3*15 I/A 6KT5,5 ALU GEB
DISTANCE BOLT
59
00304116-01
1
25-2
EABDECKUNG
COVER
60
00304127-06
1
25-2
PLATTE
PLATE
61
00845016-01
3
25-2
ZYLINDERSCHRAUBE M3*12 DIN912
HEXAGON SOCKET HEAD CAP SCREW M3*12
62
00304128-07
1
25-3
GEHAEUSE-IC-PINOLE
HOUSING IC-PINOLE
63
00303970S01
2
25-3
ELINEARKUGELLAGER 10*17*22 ZA
BALL-BEARING 10*17*22 ZA
64
00304132-01
1
25-3
RILLENKUGELLAGER 20*32*7 61804
DEEP-GROOVE BALL BEARING
66
00845013-01
8
25-2
DIN912-M3 X 6-8.8 ZYLINDERSCHRAUBE
DIN912-M3 X 6-8.8 HEXAGON SOCKET HEAD CAP SCREW
67
00325349-01
5
25-2
DIN912-M3 X 16-A2 ZYLINDERSCHRAUBE
DIN912-M3 X 16-A2 HEXAGON SOCKET HEAD CAP SCREW
68
00304134-01
2
25-3
DIN912-M2,5 X 12-A2 ZYLINDERSCHRAUBE
DIN912-M2,5 X 12-A2 HEXAGON SOCKET HEAD CAP
25 11 -
Teilekatalog (Parts Catalog) Bebilderte Teileliste (Illustrated Parts)
Bildtafel (Figure) 25
Ausgabe (Edition) 11-03
Stamm Nr.
Master Code
Bezeichnung / Designation
Stck.
Qty.
Pos.-Nr.
Pos. No.
Seiten-Nr.
Page No.
A
rtikel-Nr.
Item No.
FS
FS
IC-Kopf für CAN-Bus / Pick & place-head f. CAN-BUS
Order
69
00845013-01
3
25-2
DIN912-M3 X 6-8.8 ZYLINDERSCHRAUBE
DIN912-M3 X 6-8.8 HEXAGON SOCKET HEAD CAP SCREW
70
00095368-01
1
25-2
DIN 914 - M4 X 8-45H GEWINDESTIFT
DIN 914 - M4 X 8-45H SET SCREW
71
00305932-01
1
25-2
DECKEL
COVER
72
00305934S03
1
25-3
EDECKEL
COVER TOP
73
00305935-02
1
25-2
DECKEL
COVER
74
00305938-01
3
25-2
ABSTANDSBOLZEN M3*30 I/A 6KT5,5 A2
DISTANCE BOLT
75
00845012-01
6
25-2
ZYLINDERSCHRAUBE M3*5 DIN912
HEXAGON SOCKET HEAD CAP SCREW
76
00305939-01
4
25-3
ABSTANDSBOLZEN M3*23 I/A 6KT5,5 ST CHROM
DISTANCE BOLT
78
00845013-01
4
25-3
DIN912-M3 X 6-8.8 ZYLINDERSCHRAUBE
DIN912-M3 X 6-8.8 HEXAGON SOCKET HEAD CAP SCREW
79
00325349-01
3
25-2
DIN912-M3 X 16-A2 ZYLINDERSCHRAUBE
DIN912-M3 X 16-A2 HEXAGON SOCKET HEAD CAP SCREW
80
00845018-01
1
25-2
ZYLINDERSCHRAUBE M3*20 DIN912
HEXAGON SOCKET HEAD CAP SCREW
82
00316786-01
1
25-2
SCHUTZBLECH
PROTECTION PLATE
83
00845012-01
2
25-2
ZYLINDERSCHRAUBE M3*5 DIN912
HEXAGON SOCKET HEAD CAP SCREW
84
00319226S01
1
25-4
EVERDREHSICHERUNG
LOCKING ELEMENT
85
00845004-01
2
25-4
ZYLINDERSCHRAUBE M2*8 DIN912 A2
HEXAGON SOCKET HEAD CAP SCREW
86
00301541-01
2
25-4
SCHEIBE 2,2 DIN125-A-A2
WASHER
87
00303965-01
1
25-3
ENCODERFLANSCH IC-KOPF
ENCODER FLANGE IC-HEAD
88
00303966-02
1
25-6
FLANSCH
FLANGE
89
00306384-04
1
25-6
INKREMENTALGEBER (DR-ACHSE)
INCREMENTAL SHAFT ENCODER (DR-AXIS)
90
00303970S01
1
25-6
ELINEARKUGELLAGER 10*17*22 ZA
BALL-BEARING 10*17*22 ZA
92
00305378S01
1
25-7
EVAKUUMERZEUGER IC-KOPF
VACUUM GENERATOR
93
00305379-02
1
25-7
VAKUUMANSCHLUSS
VACUUM CONNECTION BLOCK
25 12 -
