Teilekatalog (Parts Catalog) Bebilderte Teileliste (Illustrated Parts) Bildtafel (Figure) 43 Ausgabe (Edition) 11-03 Stamm Nr. Master Code Bezeichnung / Designation Stck. Qty. Pos.-Nr. Pos. No. Seiten-Nr. Page No. A rtik…
Teilekatalog (Parts Catalog) Bebilderte Teileliste (Illustrated Parts)
Bildtafel (Figure) 43
A
usgabe (Edition) 11-03
Stamm Nr.
Master Code
Bezeichnung / Designation
Stck.
Qty.
Pos.-Nr.
Pos. No.
Seiten-Nr.
Page No.
A
rtikel-Nr.
Item No.
FS
FS
USV-Option / UPS Option
Order
00117310-01
1USV OPTION S20/F4 S23/F5 FUER STATION
UPS OPTION S20/F4 S23/F5 FOR STATION
2
00343175-01
1
43-1
USV BEFESTIGUNG
UPS MOUNTING
3
00343176-01
1
43-2
USV BLECHWINKEL
UPS SHEET METAL BRACKET
4
00845075-01
2
43-2
ZYLINDERSCHRAUBE M8*16 DIN912
HEXAGON SOCKET HEAD CAP SCREW M8*16
5
00095475-01
2
43-2
SCHEIBE 8,4 DIN125-A
WASHER 8.4
6
00348145-01
1
43-1
SPANNGURT B=25MM L=0,75M M. KLEMMSCHLOSS
TURN BUCKLE W=25MM L=0.75MM W.LOCKING CLAMP
7
00348233-01
1
43-1
USV MIT VERKABELUNG FUER S20/F4 S23/F5
UPS WITH CABLING FOR S20/F4 S23/F5
00348374-01
1USV SMART-UPS SU700INET
UPS SMART UPS SU700INET
00344539-01
1KABEL:KLEMMENFELD ZU USV
CABLE: TERMINAL BOARD TO UPS
00344540-01
1KABEL:KLEMMENFELD VON USV
CABLE: TERMINAL BOARD FROM UPS
00347852-01
1KABEL: USV - STATIONSRECHNER (V24-SCHN.)
CABLE: UPS - STATION COMPUTER (V24-INT.)
43 3 -
Teilekatalog (Parts Catalog) Bebilderte Teileliste (Illustrated Parts)
Bildtafel (Figure) 43
Ausgabe (Edition) 11-03
Stamm Nr.
Master Code
Bezeichnung / Designation
Stck.
Qty.
Pos.-Nr.
Pos. No.
Seiten-Nr.
Page No.
A
rtikel-Nr.
Item No.
FS
FS
USV-Option / UPS Option
Order
43 4 -
Teilekatalog (Parts Catalog) Bebilderte Teileliste (Illustrated Parts)
Bildtafel (Figure) 44
A
usgabe (Edition) 11-03
Kopf-Crash-Sicherung
Anti-crash protection
44 1 -
