Teilekatalog (Parts Catalog) Bebilderte Teileliste (Illustrated Parts) Bildtafel (Figure) 5 A usgabe (Edition) 11-03 Stamm Nr. Master Code Bezeichnung / Designation Stck. Qty. Pos.-Nr. Pos. No. Seiten-Nr. Page No. A rtik…

100%1 / 596
Teilekatalog (Parts Catalog) Bebilderte Teileliste (Illustrated Parts)
Bildtafel (Figure) 5
Ausgabe (Edition) 11-03
Stamm Nr.
Master Code
Bezeichnung / Designation
Stck.
Qty.
Pos.-Nr.
Pos. No.
Seiten-Nr.
Page No.
A
rtikel-Nr.
Item No.
FS
FS
Revolverkopf SP6 / DLM1 / Collect & place head SP6/DLM1
Order
123
00320962-01
1
5-14
VORSCHALLDAEMPFER
PRESILENCER
124
00320961S01
1
5-14
EDECKEL M.GEWINDEST.F.VAKUUMERTEUG. DLM1
COVER WITH SET SCREW F. VACUUM GENERATOR
125
00338012-01
1
5-14
GEWINDESTIFT /DLM1
SET SCREW /DLM1
126
00347857S02
1
5-14
EVAKUUMPLATINE II
VACUUM MEASURMENT BOARD II
127
00345074-01
2
5-14
ABSTANDSBOLZEN TYPE B I/A-M2.5X15-ST ZN
DISTANCE BOLT
128
00342868S03
1
5-14
ESCHLAUCH 26 /DLM1
HOSE, QUERY STOP CIRCUIT (HEAD)
129
00342869S03
1
5-14
ESCHLAUCH ABFRAGE BESTUECKKREIS
HOSE, QUERY PLACEMENT CIRCUIT
130
00337340S01
6
5-14
ESTECKVERSCHRAUBUNG 4,3 / 3
QUICK-RELEASE FASTENER 4.3/3
131
00342876-01
4
5-10
SCHNORRSCHEIBE 4,3 V2A HN 160
LOCK WASHER 4.3 V2A HN 160
132
00313069-01
4
5-10
DIN912-M4 X 10-A2 ZYLINDERSCHRAUBE
DIN912-M4 X 10-A2 HEXAGON SOCKET HEAD CAP SCREW
133
00341032-01
1
5-10
SOCKEL F. VAKUUMERZEUGER DLM1
PEDESTAL FOR VACUUM GENERATOR DLM1
134
00201462-01
3
5-10
DIN912-M3 X 10-A2 ZYLINDERSCHRAUBE
DIN912-M3 X 10-A2 HEXAGON SOCKET HEAD CAP SCREW
138
00344181-01
1
5-11
VERSTEIFUNGSSCHIENE
REINFORCING RAIL
139
00337719-01
2
5-11
DIN 965-M2.5 X 5-A2 SENKKOPFSCHRAUBE
DIN 965-M2.5 X 5-A2 CROSS RECESSED COUNTER-SUNK
140
00319824S03
1
5-9
EVAKUUMVERTEILER
VACUUM DISTRIBUTOR
141
00320057S01
1
5-15
E
O-RING 3*1,2 NBR 70 B
O-RING 3*1,2 NBR 70 B
142
00301001-01
2
5-15
DIN 6325 - 2M5 X 4-ST ZYLINDERSTIFT
DIN 6325 - 2M5 X 4-ST PARALLEL PIN
143
00349432S01
1
5-9
EVENTILSTELLANTRIEB ABWURFKREIS
VALVE DRIVE, REJECT SECTION
144
00319455-05
1
5-15
MOTORHALTER
MOTOR MOUNT
145
00201348-01
2
5-15
DIN 84-M1,6 X 4-A2 ZYLINDERSCHRAUBE
DIN 84-M1,6 X 4-A2 SLOTTED CHEESE HEAD SCREW
146
00845005-01
1
5-15
DIN912-M2 X 10-8.8 ZYLINDERSCHRAUBE
DIN912-M2 X 10-8.8 HEXAGON SOCKET HEAD CAP SCREW
147
00619841-01
2
5-15
DIN 6325 - 3M5 X 8-ST ZYLINDERSTIFT
DIN 6325 - 3M5 X 8-ST PARALLEL PIN
526 -
Teilekatalog (Parts Catalog) Bebilderte Teileliste (Illustrated Parts)
Bildtafel (Figure) 5
A
usgabe (Edition) 11-03
Stamm Nr.
Master Code
Bezeichnung / Designation
Stck.
Qty.
Pos.-Nr.
Pos. No.
Seiten-Nr.
Page No.
A
rtikel-Nr.
Item No.
FS
FS
Revolverkopf SP6 / DLM1 / Collect & place head SP6/DLM1
Order
148
00319825-02
1
5-15
STELLANTRIEB
ACTUATING DRIVE
149
00349433S01
1
5-9
EVENTILSTELLANTRIEB BESTUECKKREIS
VALVE DRIVE, PLACEMENT SECTION
150
00201462-01
2
5-9
DIN912-M3 X 10-A2 ZYLINDERSCHRAUBE
DIN912-M3 X 10-A2 HEXAGON SOCKET HEAD CAP SCREW
154
00319827S02
1
5-9
EVERTEILERSTUECK
DISTRIBUTOR PIECE
159
00201179S01
1
5-15
EO-RING 8*1 NBR 70 B
O-RING 8*1 NBR 70B
160
00322506S01
2
5-11
EKABELHALTER EINSEITIG
CABLE HOLDER, SINGLE-SIDED
161
00095300S01
2
5-11
ESENKSCHRAUBE M2*5 DIN965
COUNTERSUNK SCREW DIN965-M2X5-4.8
162
00322507S01
1
5-11
EKABELHALTER BEIDSEITIG
CABLE HOLDER, DOUBLE-SIDED
163
00095300S01
1
5-11
ESENKSCHRAUBE M2*5 DIN965
COUNTERSUNK SCREW DIN965-M2X5-4.8
164
00337990-01
4
5-3
DIN912-M4 X 16-A2 ZYLINDERSCHRAUBE
DIN912-M4 X 16-A2 HEXAGON SOCKET HEAD CAP SCREW
165
00330648S05
1
5-3
EZWISCHENVERTEILER SP6_12 DIGITAL
INTERMEDIATE DISTRIBUTER SP6/12 DIGITAL
166
00845013-01
1
5-3
DIN912-M3 X 6-8.8 ZYLINDERSCHRAUBE
DIN912-M3 X 6-8.8 HEXAGON SOCKET HEAD CAP SCREW
167
00316378-01
1
5-3
ABSTANDSBOLZEN TYPE B I/A-M3X10-ST ZN
DISTANCE BOLT
168
00317898-01
1
5-3
ABSTANDSBOLZEN M3*9 I/A 6KT5,5 ST CHROM
DISTANCE BOLT M3*9 I/A 6KT5.5 ST CHROM.
169
00324407-01
1
5-3
ABSTANDSBOLZEN M3*7 I/A 6KT5,5 ST VERZ
DISTANCE BOLT M3*7 I/A 6KT5.5 ST ZINC-C.
170
00324968S03
1
5-7
ERSF-DIG. DREHGEBER SP-6
RSF ROTARY TRANSDUCER SP6
171
00308108-01
2
5-7
DIN912-M2.5 X 8-A2 ZYLINDERSCHRAUBE
DIN912-M2.5 X 8-A2 HEXAGON SOCKET HEAD CAP SCREW
172
00334724-01
4
5-7
ABSTANDSBOLZEN TYPE B I/A-M2.5X5-ST ZN
DISTANCE BOLT
173
00322562-01
2
5-7
DIN912-M2,5 X 4-A2 ZYLINDERSCHRAUBE
DIN912-M2,5 X 4-A2 HEXAGON SOCKET HEAD CAP SCREW
174
00344772S02
1
5-3
RSTERN MONTIERT /DLM1
STAR MOUNTED SP-6 DLM1
175
00368123S01
1
5-16
EVERTEILERSCHEIBE PAS-LX-6 KPLT.
DISTRIBUTOR DISC ASSY, PAS-LX-6
176
00320023S01
1
5-16
EO-RING 2,5*1 NBR 70 B
O-RING 2.5X1 NBR 70 B
527 -
Teilekatalog (Parts Catalog) Bebilderte Teileliste (Illustrated Parts)
Bildtafel (Figure) 5
Ausgabe (Edition) 11-03
Stamm Nr.
Master Code
Bezeichnung / Designation
Stck.
Qty.
Pos.-Nr.
Pos. No.
Seiten-Nr.
Page No.
A
rtikel-Nr.
Item No.
FS
FS
Revolverkopf SP6 / DLM1 / Collect & place head SP6/DLM1
Order
177
00319352S02
6
5-16
ELUFTZUFUHR
AIR COMPRESSION
178
00303338-01
2
5-16
DIN 6325 - 1.5M5 X 5-ST ZYLINDERSTIFT
DIN 6325 - 1.5M5 X 5-ST PARALLEL PIN
179
00201348-01
12
5-16
DIN 84-M1,6 X 4-A2 ZYLINDERSCHRAUBE
DIN 84-M1,6 X 4-A2 SLOTTED CHEESE HEAD SCREW
180
00324955S02
6
5-16
EVENTIL SP-6
VALVE SP6
181
00351500-01
6
5-16
EVENTILSTOESSEL KPL. DLM1-6
VALVE LIFTER COMPL. SP6
182
00351499-02
6
5-16
VENTILSTOESSEL DLM1-6
VALVE PLUNGER SP-6
183
00345127-01
6
5-16
EO-RING 3*1 VMQ 70 SHORE A ROT
O-RING 3*1 VMQ 70 SHORE A RED
184
00328805-01
6
5-16
SEGMENT KPL. SP6
SEGMENT SP6
185
00322912-01
6
5-16
DIN912-M2 X 8-A2 ZYLINDERSCHRAUBE
DIN912-M2 X 8-A2 HEXAGON SOCKET HEAD CAP SCREW
186
00304316-01
6
5-16
DIN912-M2 X 3-A2 ZYLINDERSCHRAUBE
DIN912-M2 X 3-A2 HEXAGON SOCKET HEAD CAP SCREW
187
00341183S01
6
5-16
EVERB.-SCHLAUCH /DLM1
CONNECTION HOSE, DLM1
188
00303193-01
3
5-4
DIN912-M3 X 8-A2 ZYLINDERSCHRAUBE
DIN912-M3 X 8-A2 HEXAGON SOCKET HEAD CAP SCREW
00334284-04
1STOERLICHTABDECKUNG
STRAY LIGHT COVER
190
00346264S02
1
5-2
RBE-KAMERA - 39X39 KST
PCB-CAMERA 39X39 KST
191
00325049S01
1
5-17
ESCHUTZABDECKUNG
PROTECTION COVER
192
00332915S01
1
5-17
EKABELHALTER DIG.
CABLEHOLDER
193
00313069-01
4
5-2
DIN912-M4 X 10-A2 ZYLINDERSCHRAUBE
DIN912-M4 X 10-A2 HEXAGON SOCKET HEAD CAP SCREW
194
00352957S01
6
5-3
EPINOLE MIT KUGELRASTUNG KOMPL. DLM1 / 6
SHAFT DLM1 / 6
196
00325972-04
6
5-18
EPIPETTE TYP 720/920 KOMPLETT
NOZZLE TYPE 720/920 COMPLETE
197
00336425-01
2
5-3
BLENDKRAGEN DLM1/6
ANTI-GLARE SHIELD DLM1/6
198
00845001-01
4
5-3
DIN912-M2 X 4-A2 ZYLINDERSCHRAUBE
DIN912-M2 X 4-A2 HEXAGON SOCKET HEAD CAP SCREW
00345365S03
1EBEIPACK /DLM1_S23
FITTING /DLM1_S23
528 -
