Error ID ltem Description
490101 CPU1 Board
490201 CPU2 Board
490202 CPU2 Board Memory allocation error.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
490301 Recognition Board Recognition board was not detected.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
490401 HLSC2 Board HLSC2 board was not detected.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
490402 HLSC2 Board H1 board was not detected.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
01 10-003 2-122 AFO01ETRP
3.3 Error IDs and Remedial Procedures
Error ID ltem Description
490501 EB005 Board EB005 board was not detected.
490502 EB005 Board Flash write error
490503 EB005 Board RAM read/write error
490504 EB005 Board Init Flash write error
490505 EB005 Board Flash read/write error
490506 EB005 Board Binary data error
490601 Serial I/O Board Serial I/O Board was not detected.
490701 HLS Satellite HLS Satellite H1 was not detected.
490702 HLS Satellite HLS Satellite H2 was not detected.
490703 HLS Satellite HLS Satellite H3 was not detected.
490704 HLS Satellite HLS Satellite ETC1 was not detected.
490705 HLS Satellite HLS Satellite ETC2 was not detected.
490706 HLS Satellite HLS Satellite F12 was not detected.
490707 HLS Satellite HLS Satellite F34 was not detected.
490708 HLS Satellite HLS Satellite T1 was not detected.
490709 HLS Satellite HLS Satellite XY was not detected.
49070a HLS Satellite HLS Satellite FR was not detected.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
01 10-003 2-123 AFO01ETRP
3.3 Error IDs and Remedial Procedures
Error ID ltem Description
4a0101 Camera X/Y Camera Through Picture Display
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
4a0201 Camera Sensitivity Check Lighting Data Transmission
4a0202 Camera Sensitivity Check Camera Sensitivity
4a0203 Camera Sensitivity Check Display initialization
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
4a0301 Comp Recognition Lighting Comp Recognition Lightingj
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
4a0401 Comp Recognition Camera Lighting Data Transmission
4a0402 Comp Recognition Camera Camera Through Picture Display
4a0403 Comp Recognition Camera Camera Offset
4a0404 Comp Recognition Camera Camera Magnification Data Transmission
4a0405 Comp Recognition Camera Dot Recognition
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
3.3 Error IDs and Remedial Procedures
