Error ID ltem Description
4b0308 ILLEGAL OPERATION P.C.B. WAS TOOK ON INPUT BUFFER CONVEYOR.
Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
4b0309 ILLEGAL OPERATION P.C.B. WAS TOOK ON INPUT CONVEYOR.
(Cause 1) An improper P.C.B. exists on the transfer conveyor.
(Remedy 1) Remove the improper P.C.B. on the transfer conveyor and re-start the production.
4b030a ILLEGAL OPERATION P.C.B. WAS TOOK ON OUTPUT CONVEYOR.
(Cause 1) An improper P.C.B. exists on the output conveyor.
(Remedy 1) Remove the improper P.C.B. on the output conveyor and re-start the production.
4b030b ILLEGAL OPERATION P.C.B. REMOVE FROM INPUT BUFFER CONVEYOR.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
4b030c ILLEGAL OPERATION P.C.B. REMOVE FROM INPUT CONVEYOR.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
01 10-003 2-127 AFO01ETRP
3.3 Error IDs and Remedial Procedures
Error ID ltem Description
4b030d ILLEGAL OPERATION P.C.B. REMOVE FROM OUTPUT CONVEYOR.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
4c0101 B.B.R. All unit P.C.B.’s ware detected as defective. (P.C.B. on
XY-Table)
4c0102 B.B.R. All unit P.C.B.’s ware detected as defective. (P.C.B. on
Transfer Conveyor)
4c0201 Unit P.C.B. B.B.R. Information Not exist available information.(P.C.B. on Transfer Conveyor)
4c0202 Unit P.C.B. B.B.R. Information Not exist available information.(P.C.B. on Transfer XY-Table)
4c0203 Unit P.C.B. B.B.R. Information Communication data is illegal information.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Follow the described instructions and reset the machine to its normal condition
.
01 10-003 2-128 AFO01ETRP
3.3 Error IDs and Remedial Procedures
Error ID ltem Description
4f0101 PROGRAM ERROR Error in Sequence Controller! Operation Not Secured
4f0201 PROGRAM ERROR Error in Polling Task (CPU2)! Operation Not Secured
4f0202 PROGRAM ERROR Error in Polling Task (CPU2)! Operation Not Secured
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
600101 Nozzle Recog. Recognition Error Code.
Ref.: Refer to “4.3.4 Nozzle Recognition Errors” for the detailed error display.
600201 Nozzle Skip Nozzle Down Error.(L)
600202 Nozzle Skip Nozzle Down Error.(H)
600203 Nozzle Skip Recognition Teach Error.
(Cause 1) When the selected nozzle reached the L or H level during operation, the optical
beam of the sensor was shielded (not received).
The sensor may be defective.
(Remedy 1) Remove the dirt on the nozzle end and insert the nozzle deep inside.
The sensor may be defective. If necessary, replace the sensor with a new one.
Before replacing the sensor, contact our service personnel for some advice.
600204 Nozzle Skip Teach Error Data.
(Cause 1) Dirt and dust adhere to the nozzle and an error is found in the nozzle teaching
operation.
(Remedy 1) Remove dirt and dust from the nozzle end and re-perform the nozzle teaching
operation.
600205 Nozzle Skip Lighting Check.
(Cause 1) The diffusion plate of the nozzle may be dusty and dirty or scratched.
(Remedy 1) Clean the diffusion plate or replace it with a new one.
01 10-003 2-129 AFO01ETRP
